Marantz SR4300 - Power Amplifier PCB Parts List (Part 1)

74
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
SWF123 *SR000220R *SR000220R POTENTIOMETER NON SHORT R1612E-25FB1-24-P EVAR1612E25FB124P
VFF101 *HQ300580R *HQ300580R FL DISPLAY VFD29-1403FS VSLVFD291403FS
POWER AMP PCB
CM101 OA10706320 OA10706320 ELECT. CAP. 100µF,63V CD1101J101S5S1011 ECEA1JDE101MP
CM102 OA47502550 OA47502550 ELECT. CAP. 4.7µF,16V CD1101C4R7T5S0511 ECEA1CAE4R7MB
CM103 nsp nsp CERAMIC CAP. 50V,470pF±5%,SL CC1-50V-08a-SL-470pFJ ECCR1H471JY
CM104 OA10706320 OA10706320 ELECT. CAP. 100µF,63V CD1101J101S5S1011 ECEA1JDE101MP
CM105 OA10602550 OA10602550 ELECT. CAP. 10µF,16V CD1101C100T5S0511 ECEA1CAE100MB
CM106 nsp nsp CERAMIC CAP. 50V,68pF,SL CC1-50V-06a-SL-68pFJ ECCR1H680JY
CM107 nsp nsp CERAMIC CAP. 50V,68pF,SL CC1-50V-06a-SL-68pFJ ECCR1H680JY
CM108 *OF100310R *OF100310R FILM CAP. 63V,0.10µF CL23B-63V-0.10uF-J-T ECQQ1J104JZ
CM109 *OF100310R *OF100310R FILM CAP. 63V,0.10µF CL23B-63V-0.10uF-J-T ECQQ1J104JZ
CM110 *OF100310R *OF100310R FILM CAP. 63V,0.10µF CL23B-63V-0.10uF-J-T ECQQ1J104JZ
CM201 OA10706320 OA10706320 ELECT. CAP. 100µF,63V CD1101J101S5S1011 ECEA1JDE101MP
CM202 OA47502550 OA47502550 ELECT. CAP. 4.7µF,16V CD1101C4R7T5S0511 ECEA1CAE4R7MB
CM203 nsp nsp CERAMIC CAP. 50V,470pF±5%,SL CC1-50V-08a-SL-470pFJ ECCR1H471JY
CM204 OA10706320 OA10706320 ELECT. CAP. 100µF,63V CD1101J101S5S1011 ECEA1JDE101MP
CM205 OA10602550 OA10602550 ELECT. CAP. 10µF,16V CD1101C100T5S0511 ECEA1CAE100MB
CM206 nsp nsp CERAMIC CAP. 50V,68pF,SL CC1-50V-06a-SL-68pFJ ECCR1H680JY
CM207 nsp nsp CERAMIC CAP. 50V,68pF,SL CC1-50V-06a-SL-68pFJ ECCR1H680JY
CM208 *OF100310R *OF100310R FILM CAP. 63V,0.10µF CL23B-63V-0.10uF-J-T ECQQ1J104JZ
CM301 OA10706320 OA10706320 ELECT. CAP. 100µF,63V CD1101J101S5S1011 ECEA1JDE101MP
CM302 OA47502550 OA47502550 ELECT. CAP. 4.7µF,16V CD1101C4R7T5S0511 ECEA1CAE4R7MB
CM303 nsp nsp CERAMIC CAP. 50V,470pF±5%,SL CC1-50V-08a-SL-470pFJ ECCR1H471JY
CM304 OA10706320 OA10706320 ELECT. CAP. 100µF,63V CD1101J101S5S1011 ECEA1JDE101MP
CM305 OA10602550 OA10602550 ELECT. CAP. 10µF,16V CD1101C100T5S0511 ECEA1CAE100MB
CM306 nsp nsp CERAMIC CAP. 50V,68pF,SL CC1-50V-06a-SL-68pFJ ECCR1H680JY
CM307 nsp nsp CERAMIC CAP. 50V,68pF,SL CC1-50V-06a-SL-68pFJ ECCR1H680JY
CM308 *OF100310R *OF100310R FILM CAP. 63V,0.10µF CL23B-63V-0.10uF-J-T ECQQ1J104JZ
CM309 OA22505020 OA22505020 ELECT. CAP. 50V,2.2µF CD1101H2R2T5S0511 ECEA1HAE2R2MB
CM401 OA10706320 OA10706320 ELECT. CAP. 100µF,63V CD1101J101S5S1011 ECEA1JDE101MP
CM402 OA47502550 OA47502550 ELECT. CAP. 4.7µF,16V CD1101C4R7T5S0511 ECEA1CAE4R7MB
CM403 nsp nsp CERAMIC CAP. 50V,470pF±5%,SL CC1-50V-08a-SL-470pFJ ECCR1H471JY
CM404 OA10706320 OA10706320 ELECT. CAP. 100µF,63V CD1101J101S5S1011 ECEA1JDE101MP
CM405 OA10602550 OA10602550 ELECT. CAP. 10µF,16V CD1101C100T5S0511 ECEA1CAE100MB
CM406 nsp nsp CERAMIC CAP. 50V,68pF,SL CC1-50V-06a-SL-68pFJ ECCR1H680JY
CM407 nsp nsp CERAMIC CAP. 50V,68pF,SL CC1-50V-06a-SL-68pFJ ECCR1H680JY
CM408 *OF100310R *OF100310R FILM CAP. 63V,0.10µF CL23B-63V-0.10uF-J-T ECQQ1J104JZ
CM501 OA10706320 OA10706320 ELECT. CAP. 100µF,63V CD1101J101S5S1011 ECEA1JDE101MP
CM502 OA47502550 OA47502550 ELECT. CAP. 4.7µF,16V CD1101C4R7T5S0511 ECEA1CAE4R7MB
CM503 nsp nsp CERAMIC CAP. 50V,470pF±5%,SL CC1-50V-08a-SL-470pFJ ECCR1H471JY
CM504 OA10706320 OA10706320 ELECT. CAP. 100µF,63V CD1101J101S5S1011 ECEA1JDE101MP
CM505 OA10602550 OA10602550 ELECT. CAP. 10µF,16V CD1101C100T5S0511 ECEA1CAE100MB
CM506 nsp nsp CERAMIC CAP. 50V,68pF,SL CC1-50V-06a-SL-68pFJ ECCR1H680JY
CM507 nsp nsp CERAMIC CAP. 50V,68pF,SL CC1-50V-06a-SL-68pFJ ECCR1H680JY
CM508 *OF100310R *OF100310R FILM CAP. 63V,0.10µF CL23B-63V-0.10uF-J-T ECQQ1J104JZ
CM601 OA10706320 OA10706320 ELECT. CAP. 100µF,63V CD1101J101S5S1011 ECEA1JDE101MP
CM602 OA47502550 OA47502550 ELECT. CAP. 4.7µF,16V CD1101C4R7T5S0511 ECEA1CAE4R7MB
CM603 nsp nsp CERAMIC CAP. 50V,470pF±5%,SL CC1-50V-08a-SL-470pFJ ECCR1H471JY
CM604 OA10706320 OA10706320 ELECT. CAP. 100µF,63V CD1101J101S5S1011 ECEA1JDE101MP
CM605 OA10602550 OA10602550 ELECT. CAP. 10µF,16V CD1101C100T5S0511 ECEA1CAE100MB
CM606 nsp nsp CERAMIC CAP. 50V,68pF,SL CC1-50V-06a-SL-68pFJ ECCR1H680JY
CM607 nsp nsp CERAMIC CAP. 50V,68pF,SL CC1-50V-06a-SL-68pFJ ECCR1H680JY
CM608 *OF100310R *OF100310R FILM CAP. 63V,0.10µF CL23B-63V-0.10uF-J-T ECQQ1J104JZ
CM609 OA22505020 OA22505020 ELECT. CAP. 50V,2.2µF CD1101H2R2T5S0511 ECEA1HAE2R2MB
DM102
*HD201710R *HD201710R DIODE 1N4148 ODI1N4148
DM605
JFM01 nsp nsp CONNECTOR 12Pin,2.0mm,UL PH12A-20E VJS12PH01E
JFM02 nsp nsp CONNECTOR 3Pin,4.0mm,UL VH03A-40E VJS03VH01E
JFM03 nsp nsp CONNECTOR 3Pin,4.0mm,UL VH03A-40E VJS03VH01E
JFM04 nsp nsp CONNECTOR 4Pin,3.96mm,UL VH4A-40E VJS04VH01E
JFM05 nsp nsp CONNECTOR 2Pin,2.0mm,UL PH02-20A VJS02PH01E
