Marantz SR4300 - Power Amplifier PCB Parts List (Part 3)

76
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
QM505 *HT100650R *HT100650R TRANSISTOR 2SA1038RS OTR2SA1038RS
QM506 *HT100650R *HT100650R TRANSISTOR 2SA1038RS OTR2SA1038RS
QM507 *HT100650R *HT100650R TRANSISTOR 2SA1038RS OTR2SA1038RS
QM508 *HT100670R *HT100670R TRANSISTOR 2SC2389RS OTR2SC2389RS
QM509 *HX300080R *HX300080R TRANSISTOR 2SC5248E OTR2SC5248E
QM510 *HT800020R *HT800020R TRANSISTOR 9014C OTR9014C
QM511 *HT100660R *HT100660R TRANSISTOR 2SA1964E OTR2SA1964E
QM512 HT351981A0 HT351981A0 TRANSISTOR 2SC5198O OTR2SC5198O
QM513 HT119411A0 HT119411A0 TRANSISTOR 2SA1941O OTR2SA1941O
QM514 HT322402A0 HT322402A0 TRANSISTOR 2SC2240 OTR2SC2240
QM601
*HT100670R *HT100670R TRANSISTOR 2SC2389RS OTR2SC2389RS
QM604
QM605 *HT100650R *HT100650R TRANSISTOR 2SA1038RS OTR2SA1038RS
QM606 *HT100650R *HT100650R TRANSISTOR 2SA1038RS OTR2SA1038RS
QM607 *HT100650R *HT100650R TRANSISTOR 2SA1038RS OTR2SA1038RS
QM608 *HT100670R *HT100670R TRANSISTOR 2SC2389RS OTR2SC2389RS
QM609 *HX300080R *HX300080R TRANSISTOR 2SC5248E OTR2SC5248E
QM610 *HT800020R *HT800020R TRANSISTOR 9014C OTR9014C
QM611 *HT100660R *HT100660R TRANSISTOR 2SA1964E OTR2SA1964E
QM612 HT351981A0 HT351981A0 TRANSISTOR 2SC5198O OTR2SC5198O
QM613 HT119411A0 HT119411A0 TRANSISTOR 2SA1941O OTR2SA1941O
QM614 HT322402A0 HT322402A0 TRANSISTOR 2SC2240 OTR2SC2240
QM615 HT109701A0 HT109701A0 TRANSISTOR 2SA970GR OTR2SA970GR
RGND1
nsp nsp RES.
10:,1/6W RT13-10:-T26B
ERD16TJ100T
RGND6
RM101 nsp nsp RES.
2.2k:,1/6W RT13-2.2K:-T26B
ERD16TJ222T
RM102 nsp nsp RES.
4.7k:,1/6W RT13-4.7K:-T26B
ERD16TJ472T
RM103 nsp nsp RES.
100:,1/6W RT13-100:-T26B
ERD16TJ101T
RM104 nsp nsp RES.
62k:,1/6W RT13-62K:-T26B
ERD16TJ623T
RM105 nsp nsp RES.
4.7k:,1/6W RT13-4.7K:-T26B
ERD16TJ472T
RM106 *RA001050R *RA001050R TRIMMING RES. PA0630-VA1-200 EVN2BF000B201
RM107 nsp nsp RES.
560:,1/6W RT13-560:-T26B
ERD16TJ561T
RM108 nsp nsp RES.
2.2k:,1/6W RT13-2.2K:-T26B
ERD16TJ222T
RM109 nsp nsp RES.
10k:,1/6W RT13-10K:-T26B
ERD16TJ103T
RM110 nsp nsp RES.
10k:,1/6W RT13-10K:-T26B
ERD16TJ103T
RM111 nsp nsp RES.
270:,1/6W RT13-270:-T26B
ERD16TJ271T
RM112 nsp nsp RES.
2.2k:,1/6W RT13-2.2K:-T26B
ERD16TJ222T
RM113 nsp nsp RES.
820:,1/6W RT13-820:-T26B
ERD16TJ821T
RM114 *RA001060R *RA001060R TRIMMING RES. PA0630-VA1-220 EVN2BF000B221
RM115 nsp nsp RES.
150:,1/6W RT13-150:-T26B
ERD16TJ151T
RM116 nsp nsp RES.
150:,1/6W RT13-150:-T26B
ERD16TJ151T
RM117 nsp nsp METAL FILM RES.
180:,1W M0-180:-J-1W
ERYC01J181B
RM118 nsp nsp RES.
0.25:, 5W RX27-6/B-5W-0.25:
ERBGR25J05
RM119 nsp nsp RES.
0.25:, 5W RX27-6/B-5W-0.25:
ERBGR25J05
RM120 nsp nsp RES.
62k:,1/6W RT13-62K:-T26B
ERD16TJ623T
RM121 nsp nsp RES.
1k:,1/6W RT13-1K:-T26B
ERD16TJ102T
RM122 nsp nsp RES.
10:,1/6W RT13-10:-T26B
ERD16TJ100T
RM123 nsp nsp RES.
1k:,1/6W RT13-1K:-T26B
ERD16TJ102T
RM124 nsp nsp RES.
22k:,1/6W RT13-22K:-T26B
ERD16TJ223T
RM125 nsp nsp RES.
390:,1/6W RT13-390:-T26B
ERD16TJ391T
RM126 nsp nsp METAL FILM RES.
8.2:,3W M0-8.2:-J-3W
ERYC03J8R2B
RM127 nsp nsp RES.
22k:,1/6W RT13-22K:-T26B
ERD16TJ223T
RM128 nsp nsp RES.
22k:,1/6W RT13-22K:-T26B
ERD16TJ223T
RM129 nsp nsp METAL FILM RES.
22:,1/2W M0-22:-J-T52B
ERYC12J220V
RM130 nsp nsp METAL FILM RES.
22:,1/2W M0-22:-J-T52B
ERYC12J220V
RM131
nsp nsp RES.
10:,1/6W RT13-10:-T26B
ERD16TJ100T
RM134
RM201 nsp nsp RES.
2.2k:,1/6W RT13-2.2K:-T26B
ERD16TJ222T
RM202 nsp nsp RES.
4.7k:,1/6W RT13-4.7K:-T26B
ERD16TJ472T
RM203 nsp nsp RES.
100:,1/6W RT13-100:-T26B
ERD16TJ101T
RM204 nsp nsp RES.
62k:,1/6W RT13-62K:-T26B
ERD16TJ623T
