Marantz SR4300 - Power Amplifier PCB Parts List (Part 4)

77
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
RM205 nsp nsp RES.
4.7k:,1/6W RT13-4.7K:-T26B
ERD16TJ472T
RM206 *RA001050R *RA001050R TRIMMING RES. PA0630-VA1-200 EVN2BF000B201
RM207 nsp nsp RES.
560:,1/6W RT13-560:-T26B
ERD16TJ561T
RM208 nsp nsp RES.
2.2k:,1/6W RT13-2.2K:-T26B
ERD16TJ222T
RM209 nsp nsp RES.
10k:,1/6W RT13-10K:-T26B
ERD16TJ103T
RM210 nsp nsp RES.
10k:,1/6W RT13-10K:-T26B
ERD16TJ103T
RM211 nsp nsp RES.
270:,1/6W RT13-270:-T26B
ERD16TJ271T
RM212 nsp nsp RES.
2.2k:,1/6W RT13-2.2K:-T26B
ERD16TJ222T
RM213 nsp nsp RES.
820:,1/6W RT13-820:-T26B
ERD16TJ821T
RM214 *RA001060R *RA001060R TRIMMING RES. PA0630-VA1-220 EVN2BF000B221
RM215 nsp nsp RES.
150:,1/6W RT13-150:-T26B
ERD16TJ151T
RM216 nsp nsp RES.
150:,1/6W RT13-150:-T26B
ERD16TJ151T
RM217 nsp nsp METAL FILM RES.
180:,1W M0-180:-J-1W
ERYC01J181B
RM218 nsp nsp RES.
0.25:, 5W RX27-6/B-5W-0.25:
ERBGR25J05
RM219 nsp nsp RES.
0.25:, 5W RX27-6/B-5W-0.25:
ERBGR25J05
RM220 nsp nsp RES.
62k:,1/6W RT13-62K:-T26B
ERD16TJ623T
RM221 nsp nsp RES.
1k:,1/6W RT13-1K:-T26B
ERD16TJ102T
RM222 nsp nsp RES.
10:,1/6W RT13-10:-T26B
ERD16TJ100T
RM223 nsp nsp RES.
1k:,1/6W RT13-1K:-T26B
ERD16TJ102T
RM224 nsp nsp RES.
22k:,1/6W RT13-22K:-T26B
ERD16TJ223T
RM225 nsp nsp RES.
390:,1/6W RT13-390:-T26B
ERD16TJ391T
RM226 nsp nsp METAL FILM RES.
8.2:,3W M0-8.2:-J-3W
ERYC03J8R2B
RM227 nsp nsp RES.
22k:,1/6W RT13-22K:-T26B
ERD16TJ223T
RM228 nsp nsp RES.
22k:,1/6W RT13-22K:-T26B
ERD16TJ223T
RM229 nsp nsp METAL FILM RES.
22:,1/2W M0-22:-J-T52B
ERYC12J220V
RM230 nsp nsp METAL FILM RES.
22:,1/2W M0-22:-J-T52B
ERYC12J220V
RM231
nsp nsp RES.
10:,1/6W RT13-10:-T26B
ERD16TJ100T
RM234
RM301 nsp nsp RES.
2.2k:,1/6W RT13-2.2K:-T26B
ERD16TJ222T
RM302 nsp nsp RES.
4.7k:,1/6W RT13-4.7K:-T26B
ERD16TJ472T
RM303 nsp nsp RES.
100:,1/6W RT13-100:-T26B
ERD16TJ101T
RM304 nsp nsp RES.
62k:,1/6W RT13-62K:-T26B
ERD16TJ623T
RM305 nsp nsp RES.
4.7k:,1/6W RT13-4.7K:-T26B
ERD16TJ472T
RM306 *RA001050R *RA001050R TRIMMING RES. PA0630-VA1-200 EVN2BF000B201
RM307 nsp nsp RES.
560:,1/6W RT13-560:-T26B
ERD16TJ561T
RM308 nsp nsp RES.
2.2k:,1/6W RT13-2.2K:-T26B
ERD16TJ222T
RM309 nsp nsp RES.
10k:,1/6W RT13-10K:-T26B
ERD16TJ103T
RM310 nsp nsp RES.
10k:,1/6W RT13-10K:-T26B
ERD16TJ103T
RM311 nsp nsp RES.
270:,1/6W RT13-270:-T26B
ERD16TJ271T
RM312 nsp nsp RES.
2.2k:,1/6W RT13-2.2K:-T26B
ERD16TJ222T
RM313 nsp nsp RES.
820:,1/6W RT13-820:-T26B
ERD16TJ821T
RM314 *RA001060R *RA001060R TRIMMING RES. PA0630-VA1-220 EVN2BF000B221
RM315 nsp nsp RES.
150:,1/6W RT13-150:-T26B
ERD16TJ151T
RM316 nsp nsp RES.
150:,1/6W RT13-150:-T26B
ERD16TJ151T
RM317 nsp nsp METAL FILM RES.
180:,1W M0-180:-J-1W
ERYC01J181B
RM318 nsp nsp RES.
0.25:, 5W RX27-6/B-5W-0.25:
ERBGR25J05
RM319 nsp nsp RES.
0.25:, 5W RX27-6/B-5W-0.25:
ERBGR25J05
RM320 nsp nsp RES.
62k:,1/6W RT13-62K:-T26B
ERD16TJ623T
RM321 nsp nsp RES.
1k:,1/6W RT13-1K:-T26B
ERD16TJ102T
RM322 nsp nsp RES.
10:,1/6W RT13-10:-T26B
ERD16TJ100T
RM323 nsp nsp RES.
1k:,1/6W RT13-1K:-T26B
ERD16TJ102T
RM324 nsp nsp RES.
22k:,1/6W RT13-22K:-T26B
ERD16TJ223T
RM325 nsp nsp RES.
390:,1/6W RT13-390:-T26B
ERD16TJ391T
RM326 nsp nsp METAL FILM RES.
8.2:,3W M0-8.2:-J-3W
ERYC03J8R2B
RM327 nsp nsp RES.
22k:,1/6W RT13-22K:-T26B
ERD16TJ223T
RM328 nsp nsp RES.
22k:,1/6W RT13-22K:-T26B
ERD16TJ223T
RM329 nsp nsp RES.
56k:,1/6W RT13-56K:-T26B
ERD16TJ563T
RM330 nsp nsp RES.
22k:,1/6W RT13-22K:-T26B
ERD16TJ223T
RM333 nsp nsp METAL FILM RES.
22:,1/2W M0-22:-J-T52B
ERYC12J220V
RM334 nsp nsp METAL FILM RES.
22:,1/2W M0-22:-J-T52B
ERYC12J220V
