Marantz SR4300 - Power Amplifier PCB Parts List (Part 5)

78
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
RM335
nsp nsp RES.
10:,1/6W RT13-10:-T26B
ERD16TJ100T
RM338
RM401 nsp nsp RES.
2.2k:,1/6W RT13-2.2K:-T26B
ERD16TJ222T
RM402 nsp nsp RES.
4.7k:,1/6W RT13-4.7K:-T26B
ERD16TJ472T
RM403 nsp nsp RES.
100:,1/6W RT13-100:-T26B
ERD16TJ101T
RM404 nsp nsp RES.
62k:,1/6W RT13-62K:-T26B
ERD16TJ623T
RM405 nsp nsp RES.
4.7k:,1/6W RT13-4.7K:-T26B
ERD16TJ472T
RM406 *RA001050R *RA001050R TRIMMING RES. PA0630-VA1-200 EVN2BF000B201
RM407 nsp nsp RES.
560:,1/6W RT13-560:-T26B
ERD16TJ561T
RM408 nsp nsp RES.
2.2k:,1/6W RT13-2.2K:-T26B
ERD16TJ222T
RM409 nsp nsp RES.
10k:,1/6W RT13-10K:-T26B
ERD16TJ103T
RM410 nsp nsp RES.
10k:,1/6W RT13-10K:-T26B
ERD16TJ103T
RM411 nsp nsp RES.
270:,1/6W RT13-270:-T26B
ERD16TJ271T
RM412 nsp nsp RES.
2.2k:,1/6W RT13-2.2K:-T26B
ERD16TJ222T
RM413 nsp nsp RES.
820:,1/6W RT13-820:-T26B
ERD16TJ821T
RM414 *RA001060R *RA001060R TRIMMING RES. PA0630-VA1-220 EVN2BF000B221
RM415 nsp nsp RES.
150:,1/6W RT13-150:-T26B
ERD16TJ151T
RM416 nsp nsp RES.
150:,1/6W RT13-150:-T26B
ERD16TJ151T
RM417 nsp nsp METAL FILM RES.
180:,1W M0-180:-J-1W
ERYC01J181B
RM418 nsp nsp RES.
0.25:, 5W RX27-6/B-5W-0.25:
ERBGR25J05
RM419 nsp nsp RES.
0.25:, 5W RX27-6/B-5W-0.25:
ERBGR25J05
RM420 nsp nsp RES.
62k:,1/6W RT13-62K:-T26B
ERD16TJ623T
RM421 nsp nsp RES.
1k:,1/6W RT13-1K:-T26B
ERD16TJ102T
RM422 nsp nsp RES.
10:,1/6W RT13-10:-T26B
ERD16TJ100T
RM423 nsp nsp RES.
1k:,1/6W RT13-1K:-T26B
ERD16TJ102T
RM424 nsp nsp RES.
22k:,1/6W RT13-22K:-T26B
ERD16TJ223T
RM425 nsp nsp RES.
390:,1/6W RT13-390:-T26B
ERD16TJ391T
RM426 nsp nsp METAL FILM RES.
8.2:,3W M0-8.2:-J-3W
ERYC03J8R2B
RM427 nsp nsp RES.
22k:,1/6W RT13-22K:-T26B
ERD16TJ223T
RM428 nsp nsp RES.
22k:,1/6W RT13-22K:-T26B
ERD16TJ223T
RM431 nsp nsp METAL FILM RES.
22:,1/2W M0-22:-J-T52B
ERYC12J220V
RM432 nsp nsp METAL FILM RES.
22:,1/2W M0-22:-J-T52B
ERYC12J220V
RM433
nsp nsp RES.
10:,1/6W RT13-10:-T26B
ERD16TJ100T
RM436
RM501 nsp nsp RES.
2.2k:,1/6W RT13-2.2K:-T26B
ERD16TJ222T
RM502 nsp nsp RES.
4.7k:,1/6W RT13-4.7K:-T26B
ERD16TJ472T
RM503 nsp nsp RES.
100:,1/6W RT13-100:-T26B
ERD16TJ101T
RM504 nsp nsp RES.
62k:,1/6W RT13-62K:-T26B
ERD16TJ623T
RM505 nsp nsp RES.
4.7k:,1/6W RT13-4.7K:-T26B
ERD16TJ472T
RM506 *RA001050R *RA001050R TRIMMING RES. PA0630-VA1-200 EVN2BF000B201
RM507 nsp nsp RES.
560:,1/6W RT13-560:-T26B
ERD16TJ561T
RM508 nsp nsp RES.
2.2k:,1/6W RT13-2.2K:-T26B
ERD16TJ222T
RM509 nsp nsp RES.
10k:,1/6W RT13-10K:-T26B
ERD16TJ103T
RM510 nsp nsp RES.
10k:,1/6W RT13-10K:-T26B
ERD16TJ103T
RM511 nsp nsp RES.
270:,1/6W RT13-270:-T26B
ERD16TJ271T
RM512 nsp nsp RES.
2.2k:,1/6W RT13-2.2K:-T26B
ERD16TJ222T
RM513 nsp nsp RES.
820:,1/6W RT13-820:-T26B
ERD16TJ821T
RM514 *RA001060R *RA001060R TRIMMING RES. PA0630-VA1-220 EVN2BF000B221
RM515 nsp nsp RES.
150:,1/6W RT13-150:-T26B
ERD16TJ151T
RM516 nsp nsp RES.
150:,1/6W RT13-150:-T26B
ERD16TJ151T
RM517 nsp nsp METAL FILM RES.
180:,1W M0-180:-J-1W
ERYC01J181B
RM518 nsp nsp RES.
0.25:, 5W RX27-6/B-5W-0.25:
ERBGR25J05
RM519 nsp nsp RES.
0.25:, 5W RX27-6/B-5W-0.25:
ERBGR25J05
RM520 nsp nsp RES.
62k:,1/6W RT13-62K:-T26B
ERD16TJ623T
RM521 nsp nsp RES.
1k:,1/6W RT13-1K:-T26B
ERD16TJ102T
RM522 nsp nsp RES.
10:,1/6W RT13-10:-T26B
ERD16TJ100T
RM523 nsp nsp RES.
1k:,1/6W RT13-1K:-T26B
ERD16TJ102T
RM524 nsp nsp RES.
22k:,1/6W RT13-22K:-T26B
ERD16TJ223T
RM525 nsp nsp RES.
390:,1/6W RT13-390:-T26B
ERD16TJ391T
RM526 nsp nsp METAL FILM RES.
8.2:,3W M0-8.2:-J-3W
ERYC03J8R2B
RM527 nsp nsp RES.
22k:,1/6W RT13-22K:-T26B
ERD16TJ223T
