Marantz SR4300 - Power Amplifier PCB Parts List (Part 6)

79
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
RM528 nsp nsp RES.
22k:,1/6W RT13-22K:-T26B
ERD16TJ223T
RM531 nsp nsp METAL FILM RES.
22:,1/2W M0-22:-J-T52B
ERYC12J220V
RM532 nsp nsp METAL FILM RES.
22:,1/2W M0-22:-J-T52B
ERYC12J220V
RM533
nsp nsp RES.
10:,1/6W RT13-10:-T26B
ERD16TJ100T
RM536
RM601 nsp nsp RES.
2.2k:,1/6W RT13-2.2K:-T26B
ERD16TJ222T
RM602 nsp nsp RES.
4.7k:,1/6W RT13-4.7K:-T26B
ERD16TJ472T
RM603 nsp nsp RES.
100:,1/6W RT13-100:-T26B
ERD16TJ101T
RM604 nsp nsp RES.
62k:,1/6W RT13-62K:-T26B
ERD16TJ623T
RM605 nsp nsp RES.
4.7k:,1/6W RT13-4.7K:-T26B
ERD16TJ472T
RM606 *RA001050R *RA001050R TRIMMING RES. PA0630-VA1-200 EVN2BF000B201
RM607 nsp nsp RES.
560:,1/6W RT13-560:-T26B
ERD16TJ561T
RM608 nsp nsp RES.
2.2k:,1/6W RT13-2.2K:-T26B
ERD16TJ222T
RM609 nsp nsp RES.
10k:,1/6W RT13-10K:-T26B
ERD16TJ103T
RM610 nsp nsp RES.
10k:,1/6W RT13-10K:-T26B
ERD16TJ103T
RM611 nsp nsp RES.
270:,1/6W RT13-270:-T26B
ERD16TJ271T
RM612 nsp nsp RES.
2.2k:,1/6W RT13-2.2K:-T26B
ERD16TJ222T
RM613 nsp nsp RES.
820:,1/6W RT13-820:-T26B
ERD16TJ821T
RM614 *RA001060R *RA001060R TRIMMING RES. PA0630-VA1-220 EVN2BF000B221
RM615 nsp nsp RES.
150:,1/6W RT13-150:-T26B
ERD16TJ151T
RM616 nsp nsp METAL FILM RES.
180:,1W M0-180:-J-1W
ERYC01J181B
RM618 nsp nsp RES.
0.25:, 5W RX27-6/B-5W-0.25:
ERBGR25J05
RM619 nsp nsp RES.
0.25:, 5W RX27-6/B-5W-0.25:
ERBGR25J05
RM620 nsp nsp RES.
62k:,1/6W RT13-62K:-T26B
ERD16TJ623T
RM621 nsp nsp RES.
1k:,1/6W RT13-1K:-T26B
ERD16TJ102T
RM622 nsp nsp RES.
10:,1/6W RT13-10:-T26B
ERD16TJ100T
RM623 nsp nsp RES.
1k:,1/6W RT13-1K:-T26B
ERD16TJ102T
RM624 nsp nsp RES.
22k:,1/6W RT13-22K:-T26B
ERD16TJ223T
RM625 nsp nsp RES.
390:,1/6W RT13-390:-T26B
ERD16TJ391T
RM626 nsp nsp METAL FILM RES.
8.2:,3W M0-8.2:-J-3W
ERYC03J8R2B
RM627 nsp nsp RES.
22k:,1/6W RT13-22K:-T26B
ERD16TJ223T
RM628 nsp nsp RES.
22k:,1/6W RT13-22K:-T26B
ERD16TJ223T
RM629 nsp nsp RES.
56k:,1/6W RT13-56K:-T26B
ERD16TJ563T
RM630 nsp nsp RES.
22k:,1/6W RT13-22K:-T26B
ERD16TJ223T
RM632 nsp nsp RES.
150:,1/6W RT13-150:-T26B
ERD16TJ151T
RM633 nsp nsp METAL FILM RES.
22:,1/2W M0-22:-J-T52B
ERYC12J220V
RM634 nsp nsp METAL FILM RES.
22:,1/2W M0-22:-J-T52B
ERYC12J220V
RM635
nsp nsp RES.
10:,1/6W RT13-10:-T26B
ERD16TJ100T
RM639
RM701
nsp nsp RES.
56k:,1/6W RT13-56K:-T26B
ERD16TJ563T
RM706
6.1CH/PRE OUT PCB
CK101
nsp nsp CERAMIC CAP. 50V,220pF,SL CC1-50V-06a-SL-220pFJ ECCR1H221JY
CK108
CK109 nsp nsp CERAMIC CAP. 50V,100000pF,2F4 CT1-50V-06a-2F4-100000pFZ ECKR1H104Z06F
CK110 nsp nsp CERAMIC CAP. 50V,100000pF,2F4 CT1-50V-06a-2F4-100000pFZ ECKR1H104Z06F
CK201 OA10605020 OA10605020 ELECT. CAP. 10µF, 50V CD1101H100T5S0511 ECEA1HAE100MB
CK202 nsp nsp CERAMIC CAP. 50V,220pF,SL CC1-50V-06a-SL-220pFJ ECCR1H221JY
CK203 nsp nsp CERAMIC CAP. 50V,220pF,SL CC1-50V-06a-SL-220pFJ ECCR1H221JY
CK204 OA10605020 OA10605020 ELECT. CAP. 10µF, 50V CD1101H100T5S0511 ECEA1HAE100MB
CK205 OA10605020 OA10605020 ELECT. CAP. 10µF, 50V CD1101H100T5S0511 ECEA1HAE100MB
CK206 nsp nsp CERAMIC CAP. 50V,220pF,SL CC1-50V-06a-SL-220pFJ ECCR1H221JY
CK207 nsp nsp CERAMIC CAP. 50V,220pF,SL CC1-50V-06a-SL-220pFJ ECCR1H221JY
CK208 OA10605020 OA10605020 ELECT. CAP. 10µF, 50V CD1101H100T5S0511 ECEA1HAE100MB
CK209 OA10605020 OA10605020 ELECT. CAP. 10µF, 50V CD1101H100T5S0511 ECEA1HAE100MB
CK210 nsp nsp CERAMIC CAP. 50V,220pF,SL CC1-50V-06a-SL-220pFJ ECCR1H221JY
CK213 OA10605020 OA10605020 ELECT. CAP. 10µF, 50V CD1101H100T5S0511 ECEA1HAE100MB
CK214 nsp nsp CERAMIC CAP. 50V,220pF,SL CC1-50V-06a-SL-220pFJ ECCR1H221JY
CK215 nsp nsp CERAMIC CAP. 50V,220pF,SL CC1-50V-06a-SL-220pFJ ECCR1H221JY
