Marantz SR4300 - Page 60

80
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
CK216 OA10605020 OA10605020 ELECT. CAP. 10µF, 50V CD1101H100T5S0511 ECEA1HAE100MB
CK217
nsp nsp CERAMIC CAP. 50V,100000pF,2F4 CT1-50V-06a-2F4-100000pFZ ECKR1H104Z06F
CK220
JFK01 nsp nsp CONNECTOR 9Pin,2.0mm,UL PH09A-20E VJS09PH01E
JFK02 nsp nsp CONNECTOR 11Pin,2.0mm,UL PH11A-20E VJS11PH01E
JK01 nsp nsp JUMPER WIRE JPL0000
JK02 nsp nsp JUMPER WIRE JPL0000
JRK01 *YT002910R *YT002910R
TERMINAL 6P CINCH
AV6-8.4-13 VJJ01621
JRK03 *YT002890R *YT002890R
TERMINAL 4P CINCH
AV4-8.4-13 VJJ01408
JRK04 *YT002890R *YT002890R
TERMINAL 4P CINCH
AV4-8.4-13 VJJ01408
RK201
nsp nsp RES.
100:,1/6W RT13-100:-T26B
ERD16TJ101T
RK208
RK209
nsp nsp RES.
47k:,1/6W RT13-47K:-T26B
ERD16TJ473T
RK215
STAND-BY PCB
AW01 nsp nsp TERMINAL GND LAG FKV7.725.014
CW101 nsp nsp CERAMIC CAP. 50V,47000pF,2F4 CT1-50V-06a-2F4-47000pFZ ECKR1H473Z06F
CW102 nsp nsp CERAMIC CAP. 50V,47000pF,2F4 CT1-50V-06a-2F4-47000pFZ ECKR1H473Z06F
CW103 nsp nsp CERAMIC CAP. 50V,47000pF,2F4 CT1-50V-06a-2F4-47000pFZ ECKR1H473Z06F
CW104 OA33505020 OA33505020 ELECT. CAP. 3.3uF 50V CD1101H3R3T5S0511 ECEA1HAE3R3MB
CW106 OA22802520 OA22802520 ELECT. CAP. 2200µF,25V CD1101E222S7S1625 ECEA1EHJ222MS
CW107 nsp nsp CERAMIC CAP. 50V,100000pF,2F4 CT1-50V-06a-2F4-100000pFZ ECKR1H104Z06F
CW108 nsp nsp CERAMIC CAP. 50V,100000pF,2F4 CT1-50V-06a-2F4-100000pFZ ECKR1H104Z06F
CW109 OA10701620 OA10701620 ELECT. CAP. 100µF, 16V CD1101C101T5S0511 ECEA1CAE101MB
CW110 *DK100750R *DK100750R CERAMIC CAP. 103pF,250VAC,X1Y2 CS17-F2GA103MYNS ECDC103BMAGHF
CW111 nsp nsp CERAMIC CAP. 50V,100000pF,2F4 CT1-50V-06a-2F4-100000pFZ ECKR1H104Z06F
CW112 nsp nsp CERAMIC CAP. 50V,100000pF,2F4 CT1-50V-06a-2F4-100000pFZ ECKR1H104Z06F
DW101
*HD201700R *HD201700R DIODE 1N4002 ODI1N4002
DW106
DW107 nsp *HD201710R DIODE 1N4148 ODI1N4148
DW108 *HD302120R *HD302120R ZENER DIODE MTZJ777.5A ODIMTZJ75AT77
F1 /A/K/N *FS000980R *FS000980R FUSE 250V,4A ,L=21mm 50T 040H/618 004. VSF4R025001A
F1 /F/L/U *FS000990R FUSE 125V,8A ,L=21mm VSF8R012502C
F2 /F/N FS20200200 FS20200200 FUSE 2A, 250V FS20200201 VSF2R025012EB
F2 /L/U nsp JUMPER WIRE
ICW01 HC3890509F HC3890509F IC VOLTAGE REGULATOR 7805FA OICNJM7805FA
JW01
nsp nsp JUMPER WIRE JPL0000
JW10
JW101 nsp nsp CONNECTOR 2Pin,8mm,UL TH2A-80E VJS02TH01E
JW102 nsp nsp CONNECTOR 2Pin,8mm,UL TH2A-80E VJS02TH01E
JW103 nsp nsp CONNECTOR 2Pin,8mm,UL TH2A-80E VJS02TH01E
JW104 nsp nsp CONNECTOR 5Pin,2.5mm, UL XH5A-25E VJS05XH01E
QW101 HT317401L0 HT317401L0 TRANSISTOR 2SC1740STPR/2SC1740-R OTR2SC1740S
RE1 *LY000310R *LY000310R RELAY 12VDC JZC33F/012-HS VSY12JZC33FHS
RW101 nsp nsp RES.
4.7k:,1/6W RT13-4.7K:-T26B
ERD16TJ472T
RW102 nsp nsp RES.
22k:,1/6W RT13-22K:-T26B
ERD16TJ223T
RW104 nsp nsp RES.
1k:,1/6W RT13-1K:-T26B
ERD16TJ102T
RW105 nsp nsp RES.
10k:,1/6W RT13-10K:-T26B
ERD16TJ103T
RW106 /U *RC000030R Discharge path RES. 2.2M ±10% ERC12UGK225C ERC12UGK225C
TRW01 /A/N *TS001760R *TS001760R BUCKUP TRANSF. INPUT: 230VAC50Hz YKP02223 VTPAT5003
TRW01 /F *TS001790R BUCKUP TRANSF. INPUT: 100VAC60Hz SR4300-F1(Z11) S/B VTPAT5033
TRW01 /K *TS001770R BUCKUP TRANSF. INPUT: 220VAC50Hz SR4300-K1(Z11) S/B VTPAT5013
TRW01 /L *TS001800R BUCKUP TRANSF. INPUT: 220VAC60Hz SR4300-L1(Z11) S/B VTPAT5042
TRW01 /U *TS001780R BUCKUP TRANSF. INPUT: 120VAC60Hz SR4300-U1(Z11) S/B VTPAT5023
/N
*YJ002610R *YJ002610R CONNECTOR MAINS OUTLET YKE-31-0090 VJJ0911E
/F/L/U
*YJ002620R CONNECTOR MAINS OUTLET AC-182-UL-12V VJJ0921E
H/P OUT PCB
CH01 nsp nsp CERAMIC CAP. 50V,100000pF,2F4 CT1-50V-06a-2F4-100000pFZ ECKR1H104Z06F
