Paths to be conrmed Display Settings What to conrm
3
DIGITAL
(ZONE2)
g.A03a
g.A03b
A03Z2DIG
***.*dB
Input Source : HEOS Music
Input Mode : Auto
Sound mode : STEREO
Amp assign : ZONE2
MAIN ZONE : On
ZONE2 : On
・ Digital(PCM) input ⇒ Speaker output (Surround Back (ZONE2) L/R)
・ Digital(PCM) input ⇒ Pre OUT output (ZONE2 L/R)
4 HDMI
g.A04a
g.A04b
A05HDMI
***.*dB
Input Source : CBL/SAT
Input Mode : HDMI (xed)
Sound mode : STEREO
Amp assign : Surround Back
MAIN ZONE : On
ZONE2 : Off
・ HDMI input ⇒ Speaker output (Front L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
5
Analog AD
(MAIN ZONE)
g.A05a
g.A05b
A06AD
***.*dB
Input Source : CBL/SAT
Input Mode : Analog (xed)
Sound mode : MULTI CH STEREO
Vol 60(-20dB)
Amp assign : Surround Back
Speaker Cong ALL Speaker = Small/SW = Yes(2ch)
MAIN ZONE : On
ZONE2 : Off
・ Analog input ⇒ Speaker output (Front L/R, Center, Surround L/R, Surround Back L/R)
・ Analog input ⇒ Pre OUT output SW(20Hz)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume 60 is the value when Absolute settings are used. The value is -20 when Relative set-
tings are used)
6
Analog Amp Assign
(Amp Assign :
ZONE2)
g.A06
A07Z2ASS
***.*dB
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : STEREO
Z2 Source : Source
Vol 60(-20dB)
Amp assign : ZONE2
MAIN ZONE : On
ZONE2 : On
・ Analog input ⇒ Speaker output (Surround Back (ZONE2) L/R)
・ Analog input ⇒ Pre OUT output (ZONE2 L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume 60 is the value when Absolute settings are used. The value is -20 when Relative set-
tings are used)
1.6. Conrmation items for the video system
See the block diagram g.VXXth.
Paths to be conrmed Display Settings What to conrm
1 Analog Video pass g.V01
V01VIDEO
***.*dB
Input Source : CBL/SAT
MAIN ZONE : On
ZONE2 : On
・ CVBS input ⇒ CVBS output
・ Component input ⇒ Component output
(
b
The input source can be switched to any source except CBL/SAT.)
2
Video Convert
(Analog or HDMI ⇒
HDMI)
g.V02
V02CONV
***.*dB
Input Source : CBL/SAT
Video Conversion (IP Scaler) : ON, All sources
IP Scaler : "Analog & HDMI", All sources
Resolution : "Auto", All sources
MAIN ZONE : On
ZONE2 : Off
・ CVBS input ⇒ IP Scaler ⇒ HDMI output.
・ Component input ⇒ IP Scaler ⇒ HDMI output.
・ HDMI input (exept 4K60p) ⇒ IP Scaler ⇒ HDMI output (exept 4K60p)
・ HDMI input (4K60p) ⇒ HDMI output (4K60p) & Vol display
・ ETHERNET input ⇒ IP Scaler ⇒ HDMI output.
(
b
The input source can be switched to any source except CBL/SAT.)
3
HDMI pass
(MAIN ZONE)
g.V03
V03HDMI
***.*dB
Input Source : CBL/SAT
Video Conversion (IP Scaler) : OFF, All sources
MAIN ZONE : On
ZONE2 : Off
・ HDMI input (MAIN function) ⇒ HDMI output (MAIN)
(
b
The input source can be switched to any source except CBL/SAT.)
