Pin Pin Name Symbol I/O Pu/Pd STBY STOP
CEC
STBY
Function
127 VCC VCC
- - - -
Power supply pin
128 P70 HIGH_B_RL
O L L L
HIGH-B relay control pin
129 VSS VSS
- - - -
Ground pin
130 PE5/IRQ5/AN103 MAIN_POWER
O Pd L L L
Power supply control pin
131 PE4/AN102 CPU_POWER
O L L L
CPU power supply control pin
132 PE3/AN101
AIOS4_WAKE-
UP
O L L L
same as NET5V_POWER,NET3.3V_POWER (This port use
to control for Network Module standby mode in the
future(Low：Deep Standby, High：normal))
133
PE2/RXD12/IRQ7-
DS/AN100
AIOS4_STBY_
STATUS
I - I I I
Not used (This port use to detect for Network Module
standby status in the future (Low：normal, High：Deep
Standby))
134 PE1/TXD12 THERMAL_E
I SW3VPu I L I
Protection detect signal input pin (for Heat sink)
135 PE0/SCK12
NET3.3V_
POWER
O L L L
Ethernet power supply control(Net3.3V)
136 P64 D5V_POWER
O L L H
Digital 5V power supply control pin(3.3V and 1.8V gener-
ate from 5V)(When CEC standby mode3,set to Low)
137 P63 CEC_POWER
O L L H
CEC standby power supply
control(CEC5V,CEC3.3V,CEC1.8V)(When CEC standby
mode3,set to Low)
138 P62 DV_POWER1
O L L L
Digital video power supply (DV5V,DV3.3V) control pin
139 P61 DV_POWER2
O L L L
Digital video power supply (DV1.8V) control pin
140 VSS VSS
- - - -
Ground pin
141 P60 DIR_DIN
O L L L
DIR (PCM9211) control pin
142 VCC VCC
- - - -
Power supply pin
143 PD7/IRQ7/AN107 DIR_CE
O L L L
DIR (PCM9211) control pin
144 PG1 DIR_DOUT
I DA3.3Pu I I I
DIR (PCM9211) control pin
145 PD6/IRQ6/AN106 DIR_CLK
O L L L
DIR (PCM9211) control pin
146 PG0 DIR_RST
O L L L
DIR (PCM9211) control pin
147 PD5/IRQ5/AN113 788_2_HAINT
I CEC3VPu Z -
HDMI Rx (MN864788) audio interrupt signal det
148 PD4/IRQ4/AN112 SW_SDA
I_O DV3VPu O/L O/L L
HDMI TMDS switch I2C ccontrol pin for TMDS261B
149 P97
DE_RST
(NR1609 /
SR5013) /
NC (S940 /
X2500H)
O Pd Z L
Video decoder (ADV7180) reset control pin
150 PD3/IRQ3/AN111 788_1_HINT
I CEC3VPu Z -
HDMI Tx (MN864788) interrupt signal input pin
151 VSS VSS
- - - -
Ground pin
152 P96 788_1_RST
O Pd Z H
HDMI Tx (MN864788) reset control pin (When CEC
standby mode3,set to reset)
153 VCC VCC
- - - -
Power supply pin
154 PD2/IRQ2/AN110 788_2_HINT
I CEC3VPu Z -
HDMI Rx (MN864788) interrupt signal input pin
155 P95 788_2_RST
O Pd Z H
HDMI Rx (MN864788) reset control pin (When CEC
standby mode3,set to reset)
156 PD1/IRQ1/AN109 788_3_HINT
I CEC3VPu Z -
HDMI Rx (MN864788) interrupt signal input pin
157 P94 788_3_RST
O Pd Z H
HDMI Rx (MN864788) reset control pin (When CEC
standby mode3,set to reset)
158 PD0/IRQ0/AN108
A_TO_H /
NET (NR1609
/ SR5013)/
NC(S940/
X2500H)
O L L L
Video PLD control pin (Net GUI:High,A to H:Low)
159 P93/AN117 THERMAL_A
I SW3VPu I L I
Protection detect signal input pin (for power TR)
160 P92/RXD7/AN116 THERMAL_B
I SW3VPu I L I
Protection detect signal input pin (for power TR)
161 P91/AN115 SW_SCL
I_O DV3VPu O/L O/L L
HDMI TMDS switch I2C control pin for TMDS261B
162 VSS VSS
- - - -
Ground pin
163 P90/TXD7/AN114
TEMP_SEN-
SOR
I I L I
Temperature sensor input pin (for SRM)
164 VCC VCC
- - - -
Power supply pin
165
P47/IRQ15-DS/
AN007
788_3_HAINT
I CEC3VPu Z -
HDMI Rx (MN864788) audio interrupt signal det
166
P46/IRQ14-DS/
AN006
CURRENT_DET
I/O Pd I/L L/L I/L
Current level monitor pin (A/D converter)
Pin Pin Name Symbol I/O Pu/Pd STBY STOP
CEC
STBY
Function
167
P45/IRQ13-DS/
AN005
AMPSIGDET
I Pd I L I
Signal level monitor pin (AD converter)
168
P44/IRQ12-DS/
AN004
MODE
I I I I
Region setting pin
169
P43/IRQ11-DS/
AN003
KEY3
I M3VPu I I I
Key control signalinput pin (When standby mode,set to
inturrupt)
170
P42/IRQ10-DS/
AN002
KEY2
I M3VPu I I I
Key control signalinput pin (When standby mode,set to
inturrupt)
171
P41/IRQ9-DS/
AN001
KEY1
I M3VPu I I I
Key control signalinput pin (When standby mode,set to
inturrupt)
172 VREFL0 VREFL0
- - - -
Ground pin
173 P40 ADC_RST
O I L I
A/D convertor(AK5358) reset control pin
174 VREFH0 VREFH0
- - - -
Power supply pin
175 AVCC0 AVCC0
- - - -
Power supply pin
176 P07/IRQ15
COMP_
DET(NR1609/
SR5013)/
NC(S940/
X2500H)
I M3VPu I I I
Component video signal detect pin
