Marantz SR5013 - Page 66

NJU72751A (INPUT : U4204, PREOUT : U5600)
No. Symbol Function Symbol Function
1 V+ positive power supply terminal 17 CLOCK IC control clock input
2 ADR0 Address selection pin 0 18 NC -
3 InA1 Ach input 1 19 OutB4 Bch output 4
4 InB1 Bch input 1 20 OutA4 Ach output 4
5 NC - 21 NC -
6 InA2 Ach input 2 22 OutB3 Bch output 3
7 InB2 Bch input 2 23 OutA3 Ach output 3
8 NC - 24 REF_B Bch reference potential terminal
9 NC - 25 REF_A Ach reference potential terminal
10 InA3 Ach input 3 26 OutB2 Bch output 2
11 InB3 Bch input 3 27 OutA2 Ach output 2
12 NC - 28 NC -
13 InA4 Ach input 4 29 OutB1 Bch output 1
14 InB4 Bch input 4 30 OutA1 Ach output 1
15 REF Reference potential terminal for BIAS 31 ADR1 Address selection pin 1
16 DATA IC control data input 32 V- negative power supply terminal
NJM2595MTE1 (VIDEO : U5001)
InA1 OutA1
InA2 OutA2
InA3 OutA3
InA4 OutA4
InB1 OutB1
InB2 OutB2
InB3 OutB3
InB4 OutB4
NJM2595
- 1 -
5-INPUT 3-OUTPUT VIDEO SWITCH
■ GENERAL DESCRIPTION ■ PACKAGE OUTLINE
■ FEATURES
● 5-input 3-output
● Operating Voltage ±4.0 to ±6.5V
● Operating current ±15mAtyp. at Vcc=±5V
● Crosstalk -65dBtyp.
● Internal 6dB Amplifier
● Internal 75Ω Driver
● Bipolar Technology
● Package Outline DIP16,DMP16
■ PIN CONFIGURATION and BLOCK DIAGRAM
13
9
7
5
3
20k
20k
20k
20k
16
10 14 2
1
15
11
81264
6dB
Amp
75Ω
Driver
S3
S2
S4
S1
20k
20k
20k
S5
S6
S7
Vin1
Vin2
Vin3
Vin4
Vin5
SW3 SW4
SW5SW1SW2V
+
GND V
-
Vout3
Vout2
Vout1
6dB
Amp
6dB
Amp
75
Ω
Driver
75
Ω
Driver
The NJM2595 is a 5-input 3-output video switch. Its switches
select one from five signals received from VTR,TV,DVD,
TV-GAME and others.
The NJM2595 is designed for audio items, such as AV amplifier
and others.
NJM2595D NJM2595M
NJM2586AVC3(VIDEO : U5002)
Ver.4
NJM2586
A
-
1
-
WIDE BAND 3-INPUT 1-OUTPUT 3-CIRCUIT VIDEO AMPLIFIER
QGENERAL DESCRIPTION QPACKAGE OUTLINE
The NJM2586A is a wide band 3-input 1-output 3-circuit video
amplifier. It is suitable for Y, Pb, and Pr signal because frequency
range is 50MHz.The NJM2586A is suitable for AV receiver, STB,
and other high quality AV systems.
Q FEATURES
O Operating Voltage ±4.5 to ±5.5V
O Wide frequency range 0dB at 50MHz typ.
O Internal 3 input-1output 3-circuit video switch
O Internal 6dB Amplifier
O Internal 75Ω Driver Circuit (2-system drive)
O Power Save Circuit
O Bipolar Technology
O Package Outline SDIP22, SSOP20-C3 (under development)
QBLOCK DIAGRAM
NJM2586AVC3 NJM2586AL
SDIP22
9
10
8
5
6
7
4
3
2
1
11 12
13
16
15
14
17
18
19
20
21
22
CH1 IN1
CH1 IN3
CH1 IN2
SW1
SW2
GND
CH1 OU
T
V
-
1
CH2 OU
T
CH3 IN2
CH3 IN3
V
+
2
CH2 IN3
CH2 IN1
CH3 OU
T
CH3 IN1
V
+
1
CH2 IN2
V
-
2
PS
75Ω
Driv er
Bias
Cont2
Cont1
Cont1
Cont2
Cont1
Cont2
6dB
A
mp
Bias
Bias
Bias
Bias
Bias
Bias
Bias
75Ω
Driv er
75Ω
Driv er
Bias
6dB
A
mp
6dB
A
mp
GNDGND
9
10
8
5
6
7
4
3
2
1
11
14
13
12
15
16
17
18
19
20
CH1 IN1
CH1 IN3
CH1 IN2
SW1
SW2
GND
CH1 OU
T
V
-
1
CH2 OU
T
CH3 IN2
CH3 IN3
V
+
2
CH2 IN3
CH2 IN1
CH3 OU
T
CH3 IN1
V
+
1
CH2 IN2
V
-
2
PS
75Ω
Dr iv er
Bias
Cont2
Cont1
Cont1
Cont2
Cont1
Cont2
6dB
A
mp
Bias
Bias
Bias
Bias
Bias
Bias
Bias
75Ω
Dr iv er
75Ω
Dr iv er
Bias
6dB
A
mp
6dB
A
mp
SSOP20-C3
