3. Remote Code Table
Marantz Remote Command Chart
X
This pink color's cell = New assigned code
Item: AV Pre/Processor, AV Receiver, Stereo Receiver
*... Note is placed at end of this chart.
Function description is located right end.
For search
For AMX Extension
Command(*7)
AV Receiver AV Receiver
Slim Line
AV Receiver
Slim Line
AV Receiver
Zone Command Name System
Command
Extension
SR6013 SR5013 NR1609 NR1509
Main Power
POWER ON/OFF 16 12 -
--
16 12 RCRC516012
X X X X
Zone
Control
POWER ON 16 12 01
16 12 01 RCRC51601201
X X X X
POWER OFF 16 12 02
16 12 02 RCRC51601202
X X X X
SYSTEM POWER OFF 16 12 13
16 12 13 RCRC51601213
X X X X
Volume
VOL + 16 16 ---
16 16 RCRC516016
X X X X
Control
VOL - 16 17 ---
16 17 RCRC516017
X X X X
Direct VOLUME 16 111 00-63
16 111 [00-63] RCRC516111 X X X X
Audio MUTE ON 16 13 00
16 13 00 RCRC51601300
X X X X
Audio MUTE OFF 16 13 01
16 13 01 RCRC51601301
X X X X
Audio MUTE (Toggle) 16 13 ---
16 13 RCRC516013
X X X X
Speaker
SPEAKER Sel. 16 29 ---
16 29 RCRC516029
X X X X
Output
SPEAKER-A ON/OFF 16 35 ---
16 35 RCRC516035
X X X X
SPEAKER-B ON/OFF 16 39 ---
16 39 RCRC516039
X X X X
Menu
OSD Menu On 16 82 ---
16 82 RCRC516082
X X X X
Control
MENU 16 82 60
16 82 60 RCRC51608260
X X X X
OPTION 16 82 11
16 82 11 RCRC51608211
X X X X
EXIT MENU 16 83 ---
16 83 RCRC516083
X X X X
ENTER (OK) 16 87 ---
16 87 RCRC516087
X X X X
Return 16 87 04
16 87 04 RCRC51608704
X X X X
CURSOR Up 16 80 ---
16 80 RCRC516080
X X X X
CURSOR Down 16 81 ---
16 81 RCRC516081
X X X X
CURSOR Left 16 85 ---
16 85 RCRC516085
X X X X
CURSOR Right 16 86 ---
16 86 RCRC516086
X X X X
Display /
Dimmer(Display) 16 15 00
16 15 00 RCRC51601500
X X X X
Video
Info. 16 15 08
16 15 08 RCRC51601508
X X X X
OSD Info. 16 15 ---
16 15 RCRC516015
X X X X
Status 16 15 07
16 15 07 RCRC51601507
X X X X
Video Select 16 15 50
16 15 50 RCRC51601550
X X X X
VIDEO OFF (V.OFF) 16 13 02
16 13 02 RCRC51601302
--- --- --- ---
Input
INPUT NEXT 16 00 13
16 00 13 RCRC51600013
X X X X
Source
INPUT BACK 16 00 14
16 00 14 RCRC51600014
X X X X
TUNER (TUNER,FM) 17 63 ---
17 63 RCRC517063
X X X X
Blu-ray(BD)(Code1) 07 63 00
07 63 00 RCRC50706300
X X X X
Blu-ray(BD)(Code2) 28 63 00
28 63 00 RCRC52806300
X X X X
Blu-ray/DVD 16 02 04
16 02 04 RCRC51600204
--- --- --- X
CD 20 63 ---
20 63 RCRC520063
X X X X
TV AUDIO 00 63 ---
00 63 RCRC500063
X X X X
DVD 16 00 10
16 00 10 RCRC51600010
X X X ---
MEDIAPLAYER 05 63 ---
05 63 RCRC505063
X X X X
CBL/SAT 06 63 ---
06 63 RCRC506063
X X X X
AUX1(AUX) 16 00 06
16 00 06 RCRC51600006
X X X X
AUX2 16 00 07
16 00 07 RCRC51600007
X X X ---
AUX3(Additional Source) 16 00 08
16 00 08 RCRC51600008
--- --- --- ---
AUX4(Additional Source) 16 02 00
16 02 00 RCRC51600200
--- --- --- ---
AUX5(Additional Source) 16 02 01
16 02 01 RCRC51600201
--- --- --- ---
AUX6(Additional Source) 16 02 02
16 02 02 RCRC51600202
--- --- --- ---
AUX7(Additional Source) 16 02 03
16 02 03 RCRC51600203
--- --- --- ---
Bluetooth 16 02 16
16 02 16 RCRC51600216
X X X X
16 00 62
16 00 62 RCRC51600062
X X X X
16 00 08
16 00 08 RCRC51600008
--- --- --- ---
PHONO 21 63 ---
21 63 RCRC521063
X X X X
24 63 01
24 63 01 RCRC52406301
--- --- --- ---
24 63 11
24 63 11 RCRC52406311
X (USB) X (USB) X (USB) X (USB)
HEOS Music(NETWORK) 24 63 10
24 63 10 RCRC52406310
X (HEOS Music) X (HEOS Music) X (HEOS Music) X (HEOS Music)
Internet Radio Select 27 63 20
27 63 20 RCRC52706320
X X X X
SIRIUSXM (*4)
27 63 29
27 63 29 RCRC52706329
--- --- --- ---
Media Server Select 27 63 24
27 63 24 RCRC52706324
--- --- --- ---
Pandora Select (*4)
27 63 26
27 63 26 RCRC52706326
--- --- --- ---
27 63 10
27 63 10 RCRC52706310
X (HEOS Music) X (HEOS Music) X (HEOS Music) X (HEOS Music)
27 63 11
27 63 11 RCRC52706311
X (HEOS Music) X (HEOS Music) X (HEOS Music) X (HEOS Music)
M-XPort 29 63 01
29 63 01 RCRC52906301
--- --- --- ---
7.1 (6.1)CH. Input ON 16 01 12
16 01 12 RCRC51600112
X X --- ---
Smart
Smart Select1 16 02 21
16 02 21 RCRC51600221
X X X X
Select
Smart Select2 16 02 22
16 02 22 RCRC51600222
X X X X
Smart Select3 16 02 23
16 02 23 RCRC51600223
X X X X
Smart Select4 16 02 24
16 02 24 RCRC51600224
X X X X
Smart Select5 16 02 25
16 02 25 RCRC51600225
X X X X
I/O
Input Mode Select 16 01 01
16 01 01 RCRC51600101
X X X X
Setting
INPUT MODE:AUTO 16 01 15
16 01 15 RCRC51600115
X X X X
INPUT MODE:HDMI 16 01 16
16 01 16 RCRC51600116
X X X X
INPUT MODE:DIGITAL 16 01 17
16 01 17 RCRC51600117
X X X X
INPUT MODE:ANALOG 16 01 18
16 01 18 RCRC51600118
X X X X
Bilingual (Audio Channel) 16 01 14
16 01 14 RCRC51600114
--- --- X ---
LIP SYNC.(Audio Delay) 16 10 01
16 10 01 RCRC51601001
X X X X
Resolution(Analog) 16 15 10
16 15 10 RCRC51601510
X X X ---
Resolution(HDMI) 16 15 11
16 15 11 RCRC51601511
X X X ---
Vertical Stretch ON 16 15 12
16 15 12 RCRC51601512
--- --- --- ---
Vertical Stretch OFF 16 15 13
16 15 13 RCRC51601513
--- --- --- ---
HDMI Audio Output Select (Toggle) 16 84 00
16 84 00 RCRC51608400
X X X X
HDMI Audio Output: Enable (Decode by AVR)
16 84 01
16 84 01 RCRC51608401
X X X X
HDMI Audio Output: Through (Decode by TV)
16 84 02
16 84 02 RCRC51608402
X X X X
COMPONENT-2 for MAIN 16 84 31
16 84 31 RCRC51608431
--- --- --- ---
COMPONENT-2 for MULTI-A 16 84 32
16 84 32 RCRC51608432
--- --- --- ---
Video Mode (Toggle) 16 84 50
16 84 50 RCRC51608450
X X X ---
Video Mode: Auto 16 84 51
16 84 51 RCRC51608451
X X X ---
Video Mode: Movie 16 84 52
16 84 52 RCRC51608452
X X X ---
Video Mode: Game 16 84 53
16 84 53 RCRC51608453
X X X ---
HDMI Output Select (Toggle) 16 120 00
16 120 00 RCRC51612000
X X --- ---
HDMI Out-1 16 120 01
16 120 01 RCRC51612001
X X --- ---
HDMI Out-2 16 120 02
16 120 02 RCRC51612002
X X --- ---
HDMI Out-Auto(Dual) 16 120 03
16 120 03 RCRC51612003
X X --- ---
GAME
USB
V02
14-Mar-18
Remote Code:
RC-5/ RC-5 Ex. Format
HEOS MUSIC
CEC
HDMI Control (CEC) ON 16 84 08
16 84 08 RCRC51608408
X X X X
HDMI Control (CEC) OFF 16 84 09
16 84 09 RCRC51608409
X X X X
Surround
SURROUND MODE (Toggle/NEXT) 16 37 ---
16 37 RCRC516037
X X X X
Mode
SURROUND MODE (Back) 16 64 15
16 64 15 RCRC51606415
X X X X
MOVIE SURROUND 16 37 29
16 37 29 RCRC51603729
X X X X
MUSIC SURROUND 16 37 53
16 37 53 RCRC51603753
X X X X
GAME SURROUND 16 64 18
16 64 18 RCRC51606418
X X X X
AUTO 16 37 45
16 37 45 RCRC51603745
X X X X
STEREO 16 37 30
16 37 30 RCRC51603730
X X X X
MONO 16 37 37
16 37 37 RCRC51603737
--- --- --- ---
MULTI-CH Stereo 16 37 57
16 37 57 RCRC51603757
X X X X
THX
THX 16 64 13
16 64 13 RCRC51606413
--- --- --- ---
THX CINEMA 16 37 36
16 37 36 RCRC51603736
--- --- --- ---
THX SURRUND EX 16 37 58
16 37 58 RCRC51603758
--- --- --- ---
THX ULTRA 2
16 64 07 RCRC51606407
--- --- --- ---
THX SELECT 2
16 64 07 RCRC51606407
--- --- --- ---
THX 5.1 MUSIC 16 64 04
16 64 04 RCRC51606404
--- --- --- ---
THX GAMES 16 64 14
16 64 14 RCRC51606414
--- --- --- ---
NEURAL 16 64 16
16 64 16 RCRC51606416
--- --- --- ---
Dolby
DOLBY 16 37 41
16 37 41 RCRC51603741
--- --- --- ---
PRO LOGIC 16 37 00
16 37 00 RCRC51603700
--- --- --- ---
PL IIx(z) Movie / PL II Movie 16 64 00
16 64 00 RCRC51606400
--- --- --- X
PL IIx(z) Music / PL II Music 16 64 01
16 64 01 RCRC51606401
--- --- --- X
PL IIx Game 16 64 12
16 64 12 RCRC51606412
--- --- --- ---
PL IIz 16 64 17
16 64 17 RCRC51606417
--- --- --- ---
DOLBY HEADPHONE 16 37 60
16 37 60 RCRC51603760
--- --- --- ---
EX/ES 16 37 61
16 37 61 RCRC51603761
--- --- --- ---
Dolby Atmos ON/OFF 16 64 25
16 64 25 RCRC51606425
X X X ---
dts
DTS Mode 16 64 08
16 64 08 RCRC51606408
--- --- --- ---
DTS 16 37 46
16 37 46 RCRC51603746
X X X X
DTS ES 16 64 03
16 64 03 RCRC51606403
--- --- --- ---
DTS Neo6 Cinema 16 64 05
16 64 05 RCRC51606405
--- --- --- X
DTS Neo6 Music 16 64 06
16 64 06 RCRC51606406
--- --- --- X
DTS NEO:X ON/OFF 16 64 22
16 64 22 RCRC51606422
--- --- --- ---
VIRTUAL 16 37 51
16 37 51 RCRC51603751
X X X X
Decoder Mode 16 01 20
16 01 20 RCRC51600120
--- --- --- ---
DSP MODE 16 37 63
16 37 63 RCRC51603763
--- --- --- ---
SOURCE(Pure) DIRECT (Toggle) 16 34 ---
16 34 RCRC516034
X X X X
PURE DIRECT (Toggle) 16 34 01
16 34 01 RCRC51603401
--- --- --- ---
Direct Mode 16 34 02
16 34 02 RCRC51603402
X X X X
Pure Direct 16 34 03
16 34 03 RCRC51603403
X X X X
All Zone Stereo ON/OFF 16 100 00
16 100 00 RCRC51610000
X X X ---
All Zone Stereo ON 16 100 01
16 100 01 RCRC51610001
X X X ---
All Zone Stereo OFF 16 100 02
16 100 02 RCRC51610002
X X X ---
Sound
Cinema EQ (HT-EQ)(Toggle) 16 64 11
16 64 11 RCRC51606411
X(Cinema EQ) X(Cinema EQ) X(Cinema EQ) X(Cinema EQ)
Effect
Loudness Management ON/OFF(Toggle) 16 64 19
16 64 19 RCRC51606419
X X X X
M-DAX 16 22 04
16 22 04 RCRC51602204
X X X X
M-DAX OFF 16 22 06
16 22 06 RCRC51602206
X X X X
M-DAX HIGH 16 22 07
16 22 07 RCRC51602207
X X X X
M-DAX LOW 16 22 08
16 22 08 RCRC51602208
X X X X
M-DAX MID 16 22 09
16 22 09 RCRC51602209
X X X X
Bass Sync UP 16 22 12
16 22 12 RCRC51602212
--- --- --- ---
Bass Sync DOWN 16 22 22
16 22 22 RCRC51602222
--- --- --- ---
Tone /
TONE CONTROL ON/OFF (Toggle) 16 22 01
16 22 01 RCRC51602201
X X X X
Balance /
TONE CONTROL OFF 16 22 10
16 22 10 RCRC51602210
X X X X
Trim
TONE CONTROL ON 16 22 11
16 22 11 RCRC51602211
X X X X
BASS + 16 22 ---
16 22 RCRC516022
X X X X
BASS - 16 23 ---
16 23 RCRC516023
X X X X
TREBLE + 16 24 ---
16 24 RCRC516024
X X X X
TREBLE - 16 25 ---
16 25 RCRC516025
X X X X
TEST TONE 16 37 21
16 37 21 RCRC51603721
X X X X
Volume Reset 16 37 31
16 37 31 RCRC51603731
--- --- --- ---
CH. SELECT 16 37 33
16 37 33 RCRC51603733
X X X X
CH. LEVEL + 16 37 34
16 37 34 RCRC51603734
--- --- --- ---
CH. LEVEL - 16 37 35
16 37 35 RCRC51603735
--- --- --- ---
BALANCE RIGHT 16 26 ---
16 26 RCRC516026
--- --- --- ---
BALANCE LEFT 16 27 ---
16 27 RCRC516027
--- --- --- ---
Front L (A-TRIM) + (Up) 16 26 01
16 26 01 RCRC51602601
X X X X
Front L (A-TRIM) - (Down) 16 26 02
16 26 02 RCRC51602602
X X X X
Front R (B-TRIM) + (Up) 16 26 03
16 26 03 RCRC51602603
X X X X
Front R (B-TRIM) - (Down) 16 26 04
16 26 04 RCRC51602604
X X X X
Surround L + (Up) 16 26 05
16 26 05 RCRC51602605
X X X X
Surround L - (Down) 16 26 06
16 26 06 RCRC51602606
X X X X
Surround R + (Up) 16 26 07
16 26 07 RCRC51602607
X X X X
Surround R - (Down) 16 26 08
16 26 08 RCRC51602608
X X X X
Surround Back L + (Up) 16 26 09
16 26 09 RCRC51602609
X X X ---
Surround Back L - (Down) 16 26 10
16 26 10 RCRC51602610
X X X ---
Surround Back R + (Up) 16 26 11
16 26 11 RCRC51602611
X X X ---
Surround Back R - (Down) 16 26 12
16 26 12 RCRC51602612
X X X ---
Front Wide L + (Up) 16 26 13
17 26 13 RCRC51702613
--- --- --- ---
Front Wide L - (Down) 16 26 14
18 26 14 RCRC51802614
--- --- --- ---
Front Wide R + (Up) 16 26 15
19 26 15 RCRC51902615
--- --- --- ---
Front Wide R - (Down) 16 26 16
20 26 16 RCRC52002616
--- --- --- ---
Front Height L + (Up) 16 26 17
16 26 17 RCRC51602617
X X X ---
Front Height L - (Down) 16 26 18
16 26 18 RCRC51602618
X X X ---
Front Height R + (Up) 16 26 19
16 26 19 RCRC51602619
X X X ---
Front Height R - (Down) 16 26 20
16 26 20 RCRC51602620
X X X ---
Center + (Up) 16 37 11
16 37 11 RCRC51603711
X X X X
Center - (Down) 16 37 12
16 37 12 RCRC51603712
X X X X
Subwoofer + (Up) 16 37 49
16 37 49 RCRC51603749
X X X X
Subwoofer - (Down) 16 37 50
16 37 50 RCRC51603750
X X X X
Subwoofer 2 + (Up) 16 64 23
16 64 23 RCRC51606423
X --- --- ---
Subwoofer 2 - (Down) 16 64 24
16 64 24 RCRC51606424
X --- --- ---
Top Front L + (Up) 16 26 21
16 26 21 RCRC51602621
X X X ---
Top Front L - (Down) 16 26 22
16 26 22 RCRC51602622
X X X ---
Top Front R + (Up) 16 26 23
16 26 23 RCRC51602623
X X X ---
Top Front R - (Down) 16 26 24
16 26 24 RCRC51602624
X X X ---
Top Middle L + (Up) 16 26 25
16 26 25 RCRC51602625
X X X ---
Top Middle L - (Down) 16 26 26
16 26 26 RCRC51602626
X X X ---
64 0716
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
68
