[Tuner-1] 4 17 29 04
17 29 04 RCRC51702904
X X X ---
[Tuner-1] 5 17 29 05
17 29 05 RCRC51702905
X X X ---
[Tuner-1] 6 17 29 06
17 29 06 RCRC51702906
X X X ---
[Tuner-1] 7 17 29 07
17 29 07 RCRC51702907
X X X ---
[Tuner-1] 8 17 29 08
17 29 08 RCRC51702908
X X X ---
[Tuner-1] 9 17 29 09
17 29 09 RCRC51702909
X X X ---
[Tuner-1] FM 17 29 10
17 29 10 RCRC51702910
X X X ---
[Tuner-1] AM 17 29 11
17 29 11 RCRC51702911
X X X ---
[Tuner-1] PRESET Up + 17 29 13
17 29 13 RCRC51702913
X X X ---
[Tuner-1] PRESET Down - 17 29 14
17 29 14 RCRC51702914
X X X ---
[Tuner-1] FREQ.(tuning) Up + 17 29 15
17 29 15 RCRC51702915
X X X ---
[Tuner-1] FREQ.(tuning) Down - 17 29 16
17 29 16 RCRC51702916
X X X ---
[Tuner-1] T-MODE 17 29 17
17 29 17 RCRC51702917
X X X ---
BAND (FM/AM) 17 29 61
17 29 61 RCRC51702961
X X X ---
RDS/SEARCH 17 29 62
17 29 62 RCRC51702962
X X X ---
USB
Next 24 32 02
24 32 02 RCRC52403202
X X X ---
Previous 24 33 02
24 33 02 RCRC52403302
X X X ---
Random (Toggle) 24 41 01
24 41 01 RCRC52404101
--- --- --- ---
Random On 24 41 02
24 41 02 RCRC52404102
--- --- --- ---
Random Off 24 41 03
24 41 03 RCRC52404103
--- --- --- ---
Repeat(toggle) 24 42 01
24 42 01 RCRC52404201
--- --- --- ---
Repeat Off 24 42 02
24 42 02 RCRC52404202
--- --- --- ---
Repeat One 24 42 03
24 42 03 RCRC52404203
--- --- --- ---
Repeat All 24 42 04
24 42 04 RCRC52404204
--- --- --- ---
Pause 24 48 02
24 48 02 RCRC52404802
X X X ---
REW (Toggle) 24 50 02
24 50 02 RCRC52405002
--- --- --- ---
FF (Toggle) 24 52 02
24 52 02 RCRC52405202
--- --- --- ---
Play 24 53 02
24 53 02 RCRC52405302
X X X ---
Play/Pause 24 53 10
24 53 10 RCRC52405310
X X X ---
iPod Play 24 53 32
24 53 32 RCRC52405332
--- --- --- ---
27 53 32
27 53 32 RCRC52705332
--- --- --- ---
USB Direct Play 24 53 61
24 53 61 RCRC52405361
--- --- --- ---
Stop 24 54 02
24 54 02 RCRC52405402
X X X ---
Network
Network(DMP): Next 27 32 02
27 32 02 RCRC52703202
X X X ---
Network(DMP): Previous 27 33 02
27 33 02 RCRC52703302
X X X ---
JPEG Skip + (Next) 27 32 11
27 32 11 RCRC52703211
--- --- --- ---
JPEG Skip - (Previous) 27 33 11
27 33 11 RCRC52703311
--- --- --- ---
Network(DMP): Random (toggle) 27 41 01
27 41 01 RCRC52704101
--- --- --- ---
Network(DMP): Random Off 27 41 02
27 41 02 RCRC52704102
--- --- --- ---
Network(DMP): Random On 27 41 03
27 41 03 RCRC52704103
--- --- --- ---
Memory 27 41 52
27 41 52 RCRC52704152
--- --- --- ---
Network(DMP): Repeat (toggle) 27 42 01
27 42 01 RCRC52704201
--- --- --- ---
Network(DMP): Repeat Off 27 42 02
27 42 02 RCRC52704202
--- --- --- ---
Network(DMP): Repeat 1 27 42 03
27 42 03 RCRC52704203
--- --- --- ---
Network(DMP): Repeat All 27 42 04
27 42 04 RCRC52704204
--- --- --- ---
Network(DMP)/USB: REW 27 50 02
27 50 02 RCRC52705002
--- --- --- ---
Network(DMP)/USB: FF 27 52 02
27 52 02 RCRC52705202
--- --- --- ---
Network(DMP): Play(/Pause) 27 53 02
27 53 02 RCRC52705302
X X X ---
Internet Radio - Recent Played Station 27 53 51
27 53 51 RCRC52705351
X X X ---
Favorite Direct Play 27 53 62
27 53 62 RCRC52705362
--- --- --- ---
Network(DMP): Stop 27 54 02
27 54 02 RCRC52705402
X X X ---
Network(DMP): Pause 27 48 02
27 48 02 RCRC52704802
X X X ---
Network(DMP): Cursor Up 27 80 02
27 80 02 RCRC52708002
X X X ---
Network(DMP): Cursor Down 27 81 02
27 81 02 RCRC52708102
X X X ---
Network(DMP): Cursor Left 27 85 02
27 85 02 RCRC52708502
X X X ---
Network(DMP): Cursor Right 27 86 02
27 86 02 RCRC52708602
X X X ---
Network(DMP): Enter 27 87 02
27 87 02 RCRC52708702
X X X ---
Network(DMP): Page Previous 27 29 13
27 29 13 RCRC52702913
X X X ---
Network(DMP): Page Next 27 29 14
28 29 14 RCRC52802914
X X X ---
Network(DMP): Back(Return) 27 83 02
27 83 02 RCRC52708302
X (Return) X (Return) X (Return)
-
--
Network(DMP):HOME 27 84 02
27 84 02 RCRC52708402
--- --- --- ---
3rd Power
POWER ON/OFF (Toggle) 16 93 00
16 93 00 RCRC51609300
--- --- --- ---
Zone
Control
POWER ON 16 93 03
16 93 03 RCRC51609303
--- --- --- ---
(Multi
POWER OFF 16 93 04
16 93 04 RCRC51609304
--- --- --- ---
Zone B)
Volume
VOL. + 16 93 01
16 93 01 RCRC51609301
--- --- --- ---
Control
VOL. - 16 93 02
16 93 02 RCRC51609302
--- --- --- ---
Direct VOLUME 16 113 00-63
16 113 [00-63] RCRC516113[00-63]
--- ---
--- ---
MUTE (Toggle) 16 93 08
16 93 08 RCRC51609308
--- --- --- ---
Input
INPUT NEXT 16 92 03
16 92 03 RCRC51609203
--- --- --- ---
Source
INPUT BACK 16 92 04
16 92 04 RCRC51609204
--- --- --- ---
Source Call 16 92 10
16 92 10 RCRC51609210
--- --- --- ---
USB 16 92 11
16 92 11 RCRC51609211
--- --- --- ---
Blu-ray(BD) 16 92 12
16 92 12 RCRC51609212
--- --- --- ---
M-XPort 16 92 13
16 92 13 RCRC51609213
--- --- --- ---
Game 16 92 14
16 92 14 RCRC51609214
--- --- --- ---
PHONO 16 92 15
16 92 15 RCRC51609215
--- --- --- ---
Bluetooth 16 92 16
16 92 16 RCRC51609216
--- --- --- ---
CD 16 93 11
16 93 11 RCRC51609311
--- --- --- ---
TV AUDIO(TV) 16 93 15
16 93 15 RCRC51609315
--- --- --- ---
DVD 16 93 16
16 93 16 RCRC51609316
--- --- --- ---
MEDIAPLAYER(VCR1) 16 93 17
16 93 17 RCRC51609317
--- --- --- ---
VCR2 16 93 18
16 93 18 RCRC51609318
--- --- --- ---
CBL/SAT(SAT) 16 93 19
16 93 19 RCRC51609319
--- --- --- ---
AUX1(AUX) 16 93 20
16 93 20 RCRC51609320
--- --- --- ---
AUX2 16 93 21
16 93 21 RCRC51609321
--- --- --- ---
AUX3(Additional Source) 16 93 24
16 93 24 RCRC51609324
--- --- --- ---
AUX4(Additional Source) 16 93 25
17 93 25 RCRC51709325
--- --- --- ---
AUX5(Additional Source) 16 93 26
18 93 26 RCRC51809326
--- --- --- ---
AUX6(Additional Source) 16 93 27
19 93 27 RCRC51909327
--- --- --- ---
AUX7(Additional Source) 16 93 28
20 93 28 RCRC52009328
--- --- --- ---
HEOS Music(NETWORK) 16 93 23
16 29 23 RCRC516002923
--- --- --- ---
TUNER(TUNER 1,FM) 16 93 30
16 93 30 RCRC51609330
--- --- --- ---
TUNER-2 16 93 31
16 93 31 RCRC51609331
--- --- --- ---
Internet Radio 27 95 20
27 95 20 RCRC52709520
--- --- --- ---
SIRIUSXM (*4)
27 95 29
27 95 29 RCRC52709529
--- --- --- ---
Media Server 27 95 24
27 95 24 RCRC52709524
--- --- --- ---
Pandora (*4)
27 95 26
27 95 26 RCRC52709526
--- --- --- ---
Smart
Smart Select1 16 92 21
16 92 21 RCRC51609221
--- --- --- ---
Select
16 92 22 RCRC51609222
Smart Select3 16 92 23
16 92 23 RCRC51609223
--- --- --- ---
Smart Select4 16 92 24
16 92 24 RCRC51609224
--- --- --- ---
Smart Select5 16 92 25
16 92 25 RCRC51609225
--- --- --- ---
Control
Cursor Up 16 91 10
16 91 10 RCRC51609110
--- --- --- ---
Cursor Down 16 91 11
16 91 11 RCRC51609111
--- --- --- ---
Cursor Left 16 91 12
16 91 12 RCRC51609112
--- --- --- ---
Cursor Right 16 91 13
16 91 13 RCRC51609113
--- --- --- ---
Enter 16 91 14
16 92 14 RCRC51609214
--- --- --- ---
Return 16 91 15
16 91 15 RCRC51609115
--- --- --- ---
Memory 16 91 16
16 91 16 RCRC51609116
--- --- --- ---
Sleep
SLEEP (Toggle) 16 93 10
16 93 10 RCRC51609310
--- --- --- ---
SLEEP OFF 16 38 20
16 38 20 RCRC51603820
--- --- --- ---
Tuner
[Tuner-1] 0 17 93 00
17 93 00 RCRC51709300
--- --- --- ---
[Tuner-1] 1 17 93 01
17 93 01 RCRC51709301
--- --- --- ---
[Tuner-1] 2 17 93 02
17 93 02 RCRC51709302
--- --- --- ---
[Tuner-1] 3 17 93 03
17 93 03 RCRC51709303
--- --- --- ---
[Tuner-1] 4 17 93 04
17 93 04 RCRC51709304
--- --- --- ---
[Tuner-1] 5 17 93 05
17 93 05 RCRC51709305
--- --- --- ---
[Tuner-1] 6 17 93 06
17 93 06 RCRC51709306
--- --- --- ---
[Tuner-1] 7 17 93 07
17 93 07 RCRC51709307
--- --- --- ---
[Tuner-1] 8 17 93 08
17 93 08 RCRC51709308
--- --- --- ---
[Tuner-1] 9 17 93 09
17 93 09 RCRC51709309
--- --- --- ---
[Tuner-1] FM 17 93 10
17 93 10 RCRC51709310
--- --- --- ---
[Tuner-1] AM 17 93 11
17 93 11 RCRC51709311
--- --- --- ---
[Tuner-1] PRESET Up + 17 93 13
17 93 13 RCRC51709313
--- --- --- ---
[Tuner-1] PRESET Down - 17 93 14
17 93 14 RCRC51709314
--- --- --- ---
[Tuner-1] FREQ.(tuning) Up + 17 93 15
17 93 15 RCRC51709315
--- --- --- ---
[Tuner-1] FREQ.(tuning) Down - 17 93 16
17 93 16 RCRC51709316
--- --- --- ---
[Tuner-1] T-MODE 17 93 17
17 93 17 RCRC51709317
--- --- --- ---
BAND (FM/AM) 17 93 61
17 93 61 RCRC51709361
--- --- --- ---
RDS/SEARCH 17 93 62
17 93 62 RCRC51709362
--- --- --- ---
USB
Zone 3: USB: Next 24 32 03
24 32 03 RCRC52403203
--- --- --- ---
Zone 3: USB: Previous 24 33 03
24 33 03 RCRC52403303
--- --- --- ---
Zone 3: USB: Random Mode 24 44 01
24 44 01 RCRC52404401
--- --- --- ---
Zone 3: USB: Random Off 24 44 02
24 44 02 RCRC52404402
--- --- --- ---
Zone 3: USB: Random On 24 44 03
24 44 03 RCRC52404403
--- --- --- ---
Zone 3: USB: Repeat Mode 24 45 01
24 45 01 RCRC52404501
--- --- --- ---
Zone 3: USB: Repeat Off 24 45 02
24 45 02 RCRC52404502
--- --- --- ---
Zone 3: USB: Repeat One 24 45 03
24 45 03 RCRC52404503
--- --- --- ---
Zone 3: USB: Repeat All 24 45 04
24 45 04 RCRC52404504
--- --- --- ---
Zone 3: USB: Pause 24 48 03
24 48 03 RCRC52404803
--- --- --- ---
Zone 3: USB: REW 24 50 03
24 50 03 RCRC52405003
--- --- --- ---
Zone 3: USB: FF 24 52 03
24 52 03 RCRC52405203
--- --- --- ---
Zone 3: USB: Play/Pause 24 53 03
24 53 03 RCRC52405303
--- --- --- ---
Zone 3: iPod Play 24 53 33
24 53 33 RCRC52405333
--- --- --- ---
Zone 3: USB: Stop 24 54 03
24 54 03 RCRC52405403
--- --- --- ---
Zone 3: USB Direct Play 24 53 62
24 53 62 RCRC52405362
--- --- --- ---
Network
Network(DMP): Next Track(file) 27 32 03
27 32 03 RCRC52703203
--- --- --- ---
Network(DMP): Previous Track(file) 27 33 03
27 33 03 RCRC52703303
--- --- --- ---
Network: Jpeg Skip + 27 32 12
27 32 12 RCRC52703212
--- --- --- ---
Network: Jpeg Skip - 27 33 12
27 33 12 RCRC52703312
--- --- --- ---
Network(DMP): Repeat (toggle) 27 45 01
27 45 01 RCRC52704501
--- --- --- ---
Network(DMP): Repeat Off 27 45 02
27 45 02 RCRC52704502
--- --- --- ---
Network(DMP): Repeat 1 27 45 03
27 45 03 RCRC52704503
--- --- --- ---
Network(DMP): Repeat All 27 45 04
27 45 04 RCRC52704504
--- --- --- ---
Network(DMP): Pause 27 48 03
27 48 03 RCRC52704803
--- --- --- ---
Network(DMP): REW 27 50 03
27 50 03 RCRC52705003
--- --- --- ---
Network(DMP): FF 27 52 03
27 52 03 RCRC52705203
--- --- --- ---
Network(DMP): Play/Pause 27 53 03
27 53 03 RCRC52705303
--- --- --- ---
iPod Direct Play 27 53 33
27 53 33 RCRC52705333
--- --- --- ---
Internet Radio Recent Played Station 27 53 52
27 53 52 RCRC52705352
--- --- --- ---
Network: Favorite Direct Play 27 53 63
27 53 63 RCRC52705363
--- --- --- ---
Network(DMP): Stop 27 54 03
27 54 03 RCRC52705403
--- --- --- ---
Network(DMP): Cursor Up 27 80 03
27 80 03 RCRC52708003
--- --- --- ---
Network(DMP): Cursor Down 27 81 03
27 81 03 RCRC52708103
--- --- --- ---
Network(DMP): Cursor Left 27 85 03
27 85 03 RCRC52708503
--- --- --- ---
Network(DMP): Cursor Right 27 86 03
27 86 03 RCRC52708603
--- --- --- ---
Network(DMP): Enter 27 87 03
27 87 03 RCRC52708703
--- --- --- ---
Network(DMP): Back(Return) 27 83 03
27 83 03 RCRC52708303
--- --- --- ---
Network(DMP):HOME 27 88 02
27 88 02 RCRC52708802
--- --- --- ---
Page Previous 27 93 13
27 93 13 RCRC52709313
--- --- --- ---
Page Next 27 93 14
27 93 14 RCRC52709314
--- --- --- ---
Notes: Specifications subject to change without prior notice.
X
The command is available for the model.
--- The command is NOT available for the model.
* 1 Main room commands work as Multi room commands when the Multi room RC-IN input was used.
These commands are recognized as for Main room(zone) commands when they are received via Front IR receiver or Rear Remote Control In.
These commands are recognized as for Multi room(zone) commands when they are received via Rear Multi room Remote In.
*2 Need an input assign to the input in Menu in advance the use
*4 /U1x version (for North America) model only
*5 /N1x version (for Europe) model only
*6 /U1x (for North America), /N1x version (for Europe) model only
*7 The RC code can be sent using RS-232C/IP Serial protocol commands
