Marantz SR6005 Model Information

Front Panel With The Door Open (2 of 2)
HOME
MAIN DISPLAY
3
Headphones jack
When the headphones are plugged into this jack, audio will no longer be
output from the connected speakers or from the PRE OUT connectors.
NOTE: To prevent hearing loss, do not raise the volume level excessively
when using headphones.
SETUP MIC jack
iPod/USB port
DIGITAL connector
Cursor buttons ()
ENTER button
AUX1 INPUT connectors
SURROUND MODE button
22
AUTO button
DISPLAY button
STATUS button
MENU button
RETURN button
BAND button
ZONE SELECT button
ZONE2 ON/OFF button
PURE DIRECT button
11
12
13
14
10
18
19
20
21
15
16
17
FRONT PANEL (1 of 2)
26
23
24
25

Marantz SR6005 Specifications

General

Channels	7.1
Power Output	110W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
HDMI Inputs	6
HDMI Outputs	1
Dolby Technologies	Dolby TrueHD, Dolby Digital Plus, Dolby Pro Logic IIz
Networking	No
3D Support	Yes
Audio Return Channel (ARC)	Yes
Phono Input	Yes
Total Harmonic Distortion	0.08%
Signal-to-Noise Ratio	100 dB
Input Sensitivity	200 mV
USB Port	Yes
DTS Technologies	DTS-HD Master Audio, DTS Neo:6
Multi-room	Yes
Frequency Response	10Hz-100kHz
Video Upconversion	Yes
