58
Connect
7.1-channel (Front wide speaker) connection
The illustration on the right shows a connection example for performing 7.1-channel playback using the
front wide speakers.
To perform 7.1-channel playback using the front wide speakers, set “Amp Assign” to “F.Wide” in steps 3
and 4 for “Set up “Amp Assign”” (vpage64).
NOTE
•For speaker cable connections, see C page 6 “Connecting the speakers”.
•For speaker impedance , see page57.
FL FR
C
SL
SR
SW
FWL
FWR
