Marantz SR6010 - Page 221

o
Pre-out
When “Assign Mode” is set to “9.1ch”, selects the PRE OUT connect
the external power amplifier used in MAIN ZONE.
The PRE OUT connectors that can be selected differ depending on the
combination of “Floor” - “Layout” and “Height” - “Layout” settings
configured in the menu.
Surr. Back
(Default)：
The surround back left and right pre-amp
outputs are connected to an external
amplifier.
Front Wide:
The front wide left and right pre-amp
outputs are connected to an external
amplifier.
Front:
The front left and right pre-amp outputs
are connected to an external amplifier.
HEIGHT1
z
1:
The HEIGHT1 left and right pre-amp
outputs are connected to an external
amplifier.
HEIGHT2
z
2:
The HEIGHT2 left and right pre-amp
outputs are connected to an external
amplifier.
Surround Back &
HEIGHT2
z
2:
The surround back/HEIGHT2 left and
right pre-amp outputs are connected to
an external amplifier.
Front Wide & HEIGHT2
z
2:
The front wide/HEIGHT2 left and right
pre-amp outputs are connected to an
external amplifier.
HEIGHT1 & HEIGHT2
z
1
z
2:
The HEIGHT1/HEIGHT2 left and right
pre-amp outputs are connected to an
external amplifier.
Front & HEIGHT2
z
2:
The front/HEIGHT2 left and right pre-amp
outputs are connected to an external
amplifier.
Front & Front Wide :
The front/front wide left and right pre-amp
outputs are connected to an external
amplifier.
z1
The name of the speaker set for “HEIGHT1” is displayed in “Height” - “Layout”
in the menu.
z2
The name of the speaker set for “HEIGHT2” is displayed in “Height” - “Layout”
in the menu.
o
View Terminal Config.
This shows how to connect the speaker terminals and PRE OUT
connectors for your “Amp Assign” setting on the menu screen.
