Speaker configuration and “Amp Assign” settings
This unit has a built-in 7-channel power amplifier. In addition to the basic 5.1-channel system, a variety of speaker systems can be configured by changing
the “Amp Assign” settings to suit the application, such as 7.1-channel systems, bi-amp connections and 2-channel systems for multi-zone playback.
(v p. 216)
Perform “Amp Assign” settings to suit the number of rooms and speaker configuration to be installed. (v
p. 216)
Playback speaker in each zone
“Amp Assign” settings
Connection
page
MAIN ZONE ZONE2
5.1-channel playback
2-channel (Pre-out)
Can be set in all “Amp Assign” modes. 42
7.1-channel playback 7.1ch 43
9.1-channel playback 9.1ch 48
5.1-channel playback (bi-amp connection of front speakers) 5.1ch (Bi-Amp) 56
7.1-channel playback + 2-channel speakers for stereo playback 7.1ch/2ch Front 57
5.1-channel playback + second pair of front speakers 5.1ch + Front B 58
5.1-channel playback 2-channel
(Speaker out)
5.1ch + ZONE2 (Default) 59
The sound mode that can be selected varies according to the speaker configuration. See “Relationship between sound modes and channel output”
(v p. 286) for the sound modes that are supported.
The following pages provide basic connection examples.
