Example connection when using two sets of Dolby Atmos Enabled speakers
.
C
SW
SL SR
FL
FR
FDL FDR
SDL SDR
0
Set “Dolby Sp” to “4ch” in the menu when connecting in this configuration.
(v
p. 218)
.
SBR SBL
FR FL C SR SL
SW
HEIGHT 1
z
FDR FDL
SDR SDL
HEIGHT 2
z
Power amplifier
z
You can change the combination of the HEIGHT1 and HEIGHT2 channels in the
settings. (v p. 55)
