5.1-channel (bi-amp connection of front speakers)
This system plays back 5.1-channels. You can use the bi-amp connection for front speakers. Bi-amp connection is a method to connect separate
amplifiers to the tweeter terminal and woofer terminal of a speaker that supports bi-amplification. This connection enables back EMF (power returned
without being output) from the woofer to flow into the tweeter without affecting the sound quality, producing a higher sound quality.
.
SW
C
SL
SR
FL
(Bi-Amp)
FR
(Bi-Amp)
.
wqwq
(R) (L)
CSRSL
FLFR
SW
NOTE
0
When making bi-amp connections, be sure to remove the short-circuiting plate or wire between the speaker’s woofer and tweeter terminals.
