SR8002/SR7002 RS-232C Control Specification Page: 15 / 32
Document Version [1.00]
Company Restricted
Command Reply from Slave
TOGGLE “CAT:0”
CH. UP “CAT:1”
CH. DOWN “CAT:2”
CAT. NEXT “CAT:3”
XM Category
(Main Room
Only)
CAT. PREV “CAT:4”
“CAT:yxx”
y= 1(un search), 2(in search)
xx= Category No. 00(none), 01 to 32
Command Reply from Slave
TOGGLE “MPW:0”
OFF “MPW:1”
Multi Room A
POWER
ON “MPW:2”
“MPW:1”, (OFF)
“MPW:2” (ON)
TOGGLE “MSP:0”
OFF “MSP:1”
Multi Room A
SPEAKER
ON “MSP:2”
“MSP:1”,(OFF)
“MSP:2” (ON)
TOGGLE “MAM:0”
OFF “MAM:1”
Multi Room A
AUDIO MUTE
ON “MAM:2”
“MAM:1”,
“MAM:2”
VALUE “MVL:0xxx”
UP “MVL:1”
Multi Room A
VOLUME
DOWN “MVL:2”
“MVL:xxx”
xxx = vol. value as “ 00” ~”-90”
VARIABLE “MVS:1” Multi Room A
VOLUME SET
FIXED “MVS:2”
“MVS:1”, ( VARIABLE)
“MVS:2” (FIXED)
TV “MSC:1”
DVD “MSC:2”
VCR1 “MSC:3”
DSS/VCR2 “MSC:5”
AUX1 “MSC:9”
AUX2 “MSC:A”
CD/CDR “MSC:C”
TAPE “MSC:E”
TUNER1 “MSC:F”
FM1 “MSC:G”
AM1 “MSC:H”
Multi Room A
SOURCE Select
XM1 “MSC:J”
“MSC:va”, (v ,a= ‘0’ – ‘Z’)
(v = video, a = audio.)
VALUE
“MSL:0xxx” (“xxx” = min) “MSL:xx” (xx = min)
Multi Room A
SLEEP
OFF “MSL:1”
“MSL:000”
TOGGLE “MST:0”
STEREO “MST:1”
Multi Room A
Stereo/Mono
MONO “MST:2”
“MST:0”( - ),
“MST:1”(STEREO),
“MST:2”(MONO)
Command Reply from Slave
VALUE “MSV:0xxx”
UP “MSV:1”
Multi RoomA Speaker
VOLUME
DOWN “MSV:2”
“MSV:xxx”
xxx = vol. value as +90 ~-90
VARIABLE “MSS:1” Multi RoomA Speaker
VOLUME SET
FIXED “MSS:2”
“MSS:1”,
“MSS:2”
TOGGLE “MSM:0”
OFF “MSM:1”
Multi RoomA Speaker
AUDIO MUTE
ON “MSM:2”
“MSM:1”,
“MSM:2”
To Next Page
