Height Layout
Select the height channel used.
This can be selected when the “Speakers for 2ch” setting is “FRONT
WIDE/HEIGHT2” or “SURROUND BACK”.
AUDIO OUT connectors
Select items
HEIGHT1
None No height channels are used.
Front Height
(Default)
Front Height
Top Front Top Front
Top Middle Top Middle
Top Rear Top Rear
Rear Height Rear Height
Front Dolby Front Dolby
Surround Dolby Surround Dolby
o
Detailed settings when “Assign Mode” is set to
“7.1ch + Front B”
When “Assign Mode” is set to “7.1ch + Front B”, set the following
items.
n
Speakers for Front B
Select the speaker terminals used for the front speakers of the second
unit.
FRONT WIDE/
HEIGHT2
(Default):
Connect the front speakers of the second unit to
the FRONT WIDE/HEIGHT2 speaker terminals.
HEIGHT1:
Connect the front speakers of the second unit to
the HEIGHT1 speaker terminals.
SURROUND
BACK:
Connect the front speakers of the second unit to
the SURROUND BACK speaker terminals.
