Speaker configuration and “Amp Assign” settings
This unit has a built-in 9-channel power amplifier. In addition to the basic 5.1-channel system, a variety of speaker systems can be configured by changing
the “Amp Assign” (v
p. 230) settings to suit the application, such as 7.1-channel systems, bi-amp connections and 2-channel systems for multi-zone
playback.
Perform “Amp Assign” settings to suit the number of rooms and speaker configuration to be installed.
(v
p. 230)
Playback speaker in each zone
“Amp Assign” settings
Connection
page
MAIN ZONE ZONE2 ZONE3
5.1-channel playback Not used Not used 7.1ch + ZONE2 (Default)
50
7.1-channel playback (surround back) Not used Not used 7.1ch + ZONE2 (Default) 51
9.1-channel playback Not used Not used 9.1ch
52
11.1-channel playback Not used Not used 11.1ch 53
7.1-channel playback (bi-amp connection of front speakers) Not used Not used 7.1ch (Bi-Amp)
54
9.1-channel playback + 2-channel speakers for stereo playback Not used Not used 9.1ch/2ch Front 55
7.1-channel playback + 2-channel bi-amp speakers for stereo
playback
Not used Not used 7.1ch/2ch Front (Bi-Amp)
56
7.1-channel playback + front speakers of second unit Not used Not used 7.1ch + Front B 57
7.1-channel playback 2-channel Not used 7.1ch + ZONE2 (Default)
58
7.1-channel playback Not used 2-channel 7.1ch + ZONE3 58
5.1-channel playback (bi-amp connection of front speakers) 2-channel Not used 5.1ch (Bi-Amp) + ZONE2
59
5.1-channel playback 2-channel 2-channel 5.1ch + ZONE2/3 60
7.1-channel playback 1-channel 1-channel 7.1ch + ZONE2/3-MONO
61
Dolby Atmos playback Not used Not used Dolby Atmos 62
