Advanced connections
n
9.1-channel playback
This system, which is based on a 5.1-channel system, plays back up to 9.1-channels at the same time.
You can connect speakers for up to 11-channels for MAIN ZONE. When you connect speakers for 10 or more channels, the output speakers
automatically switch according to the input signal and sound mode.
.
FHL
FL
SW
C
SL
SBL
FHR
FR
SR
SBR
FWL
FWR
.
SW
SBR SBL FWR FWL FHR FHLFR FL C SR SL
