11.1-channel playback
This system, which is based on a 5.1-channel system, plays back up to 11.1-channels at the same time.
You can connect speakers for up to 13-channels for MAIN ZONE by using an external power amplifier. When you connect speakers for 12 or more
channels, the output speakers automatically switch according to the input signal and sound mode.
.
C
FL FR
SBL
SBR
SW
FWL
FWR
TRR
TRL
TFR
TFL
SL SR
.
TFR TFLSW
SBR SBL FWR FWLFR FL C SR SL
TRR
Power amplier
TRL
