Upgrade (Auro-3D)
Settings AUDIO OUT connectors
Height Speakers Dolby Speakers NOTE Layout HEIGHT1 HEIGHT2 SUBWOOFER2
4ch None
z 1
Front Height & Surr. Height Front Height Surround Height -
Front Height & Rear Height z 5
Front Height Rear Height -
5ch None
z 4
Front Height & Surr. Height Front Height Surround Height Top Surround
Front Height & Rear Height z 5
Front Height Rear Height Top Surround
z1
This can be selected when “Assign Mode” is set to “11.1ch” or “9.1ch” in the menu.
z4
This can be selected when “Assign Mode” is set to “11.1ch” in the menu.
z5
For the best Auro-3D experience Surround Height speakers are recommended, however you may substitute Rear Height speakers from a Dolby Atmos speaker setup
in place of Surround Height speakers.
