Upgrade (Auro-3D)
n
Example connection for the Auro-3D 10.1-channel system
This speaker configuration is optimized for Auro-3D playback.
.
FL FR
SW
SL SR
C
FHL FHR
SHL SHR
TS
0
Set “Height” - “Height Sp” to “5ch” in the menu when connecting in this
configuration. Next, set “Height” - “Layout” to “Front Height & Surr. Height”.
.
FR FL C SR SL
SW
HEIGHT 2
z
FHR FHL
HEIGHT 1
z
SHR SHL
TS
Power amplifier
z
You can change the combination of the HEIGHT1 and HEIGHT2 channels in the
settings. (v
p. 69)
