Marantz SR8000 - Page 42

66
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
P101-FM AM TUNER
CIRCUIT BOARD
P101-CAPACITORS
C201 532212234098 CER. CHIP 0.01µF DK56103300
C202 532212234098 CER. CHIP 0.01µF DK56103300
C203 CER. CHIP 0.047µF B 50V DK56473300
C204 CER. CHIP 0.047µF B 50V DK56473300
C205 482212442182 ELECT. 3.3µF M 50V OA33505020
C206 532212421731 ELECT. 10µF M 50V RA-2 OA10605020
C207 482212490353 ELECT. 100µF M 10V RA-2 OA10701020
C208 CER. 0.047µF B 50V DK56473300
C209 532212421731 ELECT. 10µF M 50V RA-2 OA10605020
C210 532212234098 CER. CHIP 0.01µF DK56103300
C211 482212440763 ELECT. 2.2µF M 50V RA-2 OA22505020
C212 482212441543 ELECT. 1µF M 50V RA-2 OA10505020
C213 482212422273 ELECT. 0.47µF M 50V RA-2 OA47405020
C214 482212422698 ELECT. 47µF M 25V RA-2 OA47602520
C215 CER. 0.047µF B 50V DK56473300
C216 482212490354 ELECT. 100µF M 16V RA-2 OA10701620
C218 532212234098 CER. CHIP 0.01µF DK56103300
C219 532212421731 ELECT. 10µF M 50V RA-2 OA10605020
C220 482212233127 CER. CHIP 2200pF DK56222300
C222 532212610511 CER. CHIP 0.001µF DK56102300
C223 532212234098 CER. CHIP 0.01µF DK56103300
C225 532212234098 CER. CHIP 0.01µF DK56103300
C226 532212234098 CER. CHIP 0.01µF DK56103300
C227 /U 482212233127 CER. CHIP 2200pF DK56222300
C233 532212234098 CER. CHIP 0.01µF DK56103300
C234 482212480067 ELECT. 4.7µF M 50V RA-2 OA47505020
C235 532212234098 CER. CHIP 0.01µF DK56103300
C236 532212234098 CER. CHIP 0.01µF DK56103300
C237 532212234098 CER. CHIP 0.01µF DK56103300
C303 532212421731 ELECT. 10µF M 50V RA-2 OA10605020
C304 532212421731 ELECT. 10µF M 50V RA-2 OA10605020
C305 /K,/N,/S 482212480067 ELECT. 4.7µF M 50V RA-2 OA47505020
C306 /K,/N,/S 482212480067 ELECT. 4.7µF M 50V RA-2 OA47505020
C311 482212480067 ELECT. 4.7µF M 50V RA-2 OA47505020
C312 482212480067 ELECT. 4.7µF M 50V RA-2 OA47505020
C313 /K,/N,/S 482212422698 ELECT. 47µF M 25V RA-2 OA47602520
C314 /K,/N,/S 482212422698 ELECT. 47µF M 25V RA-2 OA47602520
C315 /K,/N,/S 532212234098 CER. CHIP 0.01µF DK56103300
C316 /K,/N,/S 532212234098 CER. CHIP 0.01µF DK56103300
C317 /K,/N,/S 532212232531 CER. CHIP 100pF DD55101300
C318 /K,/N,/S 532212232531 CER. CHIP 100pF DD55101300
C319 /K,/N,/S 482212480067 ELECT. 4.7µF M 50V RA-2 OA47505020
C320 /K,/N,/S 482212480067 ELECT. 4.7µF M 50V RA-2 OA47505020
C351 /N,/S 532212234098 CER. CHIP 0.01µF DK56103300
C352 /N,/S 532212421731 ELECT. 10µF M 50V RA-2 OA10605020
C353 /N,/S 482212233805 CER. CHIP 330pF DK56331300
C354 /N,/S 482212233137 CER. CHIP 560pF DK56561300
C355 /N,/S 532212234098 CER. CHIP 0.01µF DK56103300
C356 /N,/S 482212233204 CER. CHIP 15pF DD55150300
C357 /N,/S 482212233204 CER. CHIP 15pF DD55150300
C358 /N,/S 532212421731 ELECT. 10µF M 50V RA-2 OA10605020
C359 /N,/S 532212421731 ELECT. 10µF M 50V RA-2 OA10605020
C360 /N,/S 532212610511 CER. CHIP 0.001µF DK56102300
C361 /N,/S 532212232531 CER. CHIP 100pF DD55101300
C363 /N,/S 532212232531 CER. CHIP 100pF DD55101300
C364 /N,/S 532212232531 CER. CHIP 100Pf DD55101300
C365 /N,/S 482212422698 ELECT. 47µF M 25V RA-2 OA47602520
C367 532212232531 CER. CHIP 100pF DD55101300
C368 532212232531 CER. CHIP 100pF DD55101300
C370 532212232531 CER. CHIP 100pF DD55101300
C371 532212232531 CER. CHIP 100pF DD55101300
C372 532212232531 CER. CHIP 100pF DD55101300
C373 /N,/S 482212612061 CER. CHIP 0.1µF B 25V DK56104200
C501 532212232452 CER. CHIP 47pF CH DD55470300
C502 532212232452 CER. CHIP 47pF CH DD55470300
C503 482212490353 ELECT. 100µF M 10V RA-2 OA10701020
C504 532212234098 CER. CHIP 0.01µF DK56103300
C505 996500003389 ELECT. 2.2µF 50V BP EQ22505090
C507 532212234098 CER. CHIP 0.01µF DK56103300
C508 482212490354 ELECT. 100µF M 16V RA-2 OA10701620
C510 532212232531 CER. CHIP 100pF DD55101300
C511 532212234098 CER. CHIP 0.01µF DK56103300
C512 482212230043 CER. CHIP 0.01µF Z 50V DK18103310
C513 /N 482212610364 CER. 100pF UP050B101K-A DA16101110
CA01 482212550384 TRIM. VCT51E 20pF CT12000200
CA02 CER. CHIP 0.047µF B 50V DK56473300
CA03 482212233204 CER. CHIP 15pF DD55150300
CA04 482212142466 FILM CHIP 390pF 100V ECQ-P DF15391550
CA05 532212232452 CER. CHIP 47pF CH DD55470300
CA06 532212234098 CER. CHIP 0.01µF DK56103300
CA07 /N 532212234098 CER. CHIP 0.01µF DK56103300
CA08 /N 482212550384 TRIM. VCT51E 20pF CT12000200
CA09 /N 482212233204 CER. CHIP 15pF DD55150300
CA11 /N 482212233514 CER. CHIP 68pF DD55680300
CA12 /N 532212233538 CER. CHIP 150pF DD55151300
CA13 /N 532212234098 CER. CHIP 0.01µF DK56103300
CA14 /N 532212234098 CER. CHIP 0.01µF DK56103300
CA18 482212480067 ELECT. 4.7µF M 50V RA-2 OA47505020
P104-CAPACITORS (COMMON)
PLASTIC FILM CAPACITOR
±5% 50V : C217 C301 C302
C309-C310[/K]
P101-RESISTORS
R101 /U 482205021003 10kΩ ±5% 1/2W GG05103120
R201 /K,/N,/S 482205120101 CHIP 100Ω ±5% 1/10W NI05101110
R201 /U 482211190892 CHIP NI05000110
R202 482205120391 CHIP 390Ω ±5% 1/10W NI05391110
R203 482211711449 CHIP 2.2kΩ ±5% 1/10W NI05222110
R204 482211191192 CHIP 470Ω ±5% 1/10W NI05471110
R205 482205120331 CHIP 330Ω ±5% 1/10W NI05331110
R206 482211191139 CHIP 6.8kΩ ±5% 1/10W NI05682110
R207 482205021801 180Ω ±5% 1/4W GG05181140
R208 996500003405 CHIP 2.7kΩ ±5% 1/6W NI05272110
R209 482211190918 CHIP 4.7kΩ ±5% 1/6W NI05472110
R210 482205120332 CHIP 3.3kΩ ±5% 1/6W NI05332110
R211 /K,/N,/S 482210011352 TRIM. 22kΩ RH0638CJ4R RA02230780
R211 /U 482210011351 TRIM. 10kΩ RH0638CS3R RA01030780
R212 482210011351 TRIM. 10kΩ RH0638CS3R RA01030780
R213 482205120479 CHIP 47Ω ±5% 1/6W NI05470110
R214 482211710834 CHIP 47kΩ ±5% 1/6W NI05473110
R215 /K,/N,/S 482211190925 CHIP 68kΩ ±5% 1/6W NI05683110
R215 /U 482205120273 CHIP 27kΩ ±5% 1/6W NI05273110
R216 482211190892 CHIP 0Ω ±5% 1/6W NI05000110
R217 482205021801 180Ω ±5% 1/4W GG05181140
R220 482205120101 CHIP 100Ω ±5% 1/10W NI05101110
R301 /K,/N,/S 482205120479 CHIP 47Ω ±5% 1/10W NI05470110
R302 /K,/N,/S 482205120479 CHIP 47Ω ±5% 1/10W NI05470110
R303 /K,/N,/S 482211710833 CHIP 10kΩ ±5% 1/10W NI05103110
R304 /K,/N,/S 482211710833 CHIP 10kΩ ±5% 1/10W NI05103110
R307 482205120153 CHIP 220Ω ±5% 1/10W NI05221110
R308 482205120153 CHIP 220Ω ±5% 1/10W NI05221110
R309 482211710834 CHIP 47kΩ ±5% 1/10W NI05473110
R310 482211710834 CHIP 47kΩ ±5% 1/10W NI05473110
R313 /K,/N,/S 482211683929 220Ω ±5% 1/4W GG05221140
R314 /K,/N,/S 482211683929 220Ω ±5% 1/4W GG05221140
R315 996500003405 CHIP 2.7kΩ ±5% 1/10W NI05272110
R316 996500003405 CHIP 2.7kΩ ±5% 1/10W NI05272110
R317 /K,/N,/S 482211710834 CHIP 47kΩ ±5% 1/10W NI05473110
R318 /K,/N,/S 482211710834 CHIP 47kΩ ±5% 1/10W NI05473110
R319 /K,/N,/S 482205120153 CHIP 15kΩ ±5% 1/10W NI05153110
R320 /K,/N,/S 482205120153 CHIP 15kΩ ±5% 1/10W NI05153110
