Marantz SR8000 - Page 43

67
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
R321 /U 482211190892 CHIP 0Ω ±5% 1/10W NI05000110
R322 /U 482211190892 CHIP 0Ω ±5% 1/10W NI05000110
R323 482211190918 CHIP 4.7kΩ ±5% NI05472110
R352 /N,/S 482211190896 CHIP 100kΩ ±5% 1/10W NI05104110
R353 /N,/S 482211710834 CHIP 47kΩ ±5% 1/10W NI05473110
R355 /N,/S 482211710833 CHIP 10kΩ ±5% 1/10W NI05103110
R502 482211711449 CHIP 2.2kΩ ±5% 1/10W NI05222110
R504 482211190918 CHIP 4.7kΩ ±5% 1/10W NI05472110
R505 482205120102 CHIP 1kΩ ±5% 1/10W NI05102110
R506 482205120102 CHIP 1kΩ ±5% 1/10W NI05102110
R507 482211190925 CHIP 68kΩ ±5% 1/10W NI05683110
R508 /K,/U 482211710834 CHIP 47kΩ ±5% 1/10W NI05473110
R509 482205120223 CHIP 22kΩ ±5% 1/10W NI05223110
R510 482211190918 CHIP 4.7kΩ ±5% 1/10W NI05472110
R511 482205120822 CHIP 8.2kΩ ±5% 1/10W NI05822110
R513 482211710833 CHIP 10kΩ ±5% 1/10W NI05103110
R515 482211710833 CHIP 10kΩ ±5% 1/10W NI05103110
R517 /N,/S 482211190892 CHIP 0Ω ±5% 1/10W NI05000110
RA01 482211710833 CHIP 10kΩ ±5% 1/10W NI05103110
RA02 482211190896 CHIP 100kΩ ±5% 1/10W NI05104110
RA03 /N 482211710833 CHIP 10kΩ ±5% 1/10W NI05103110
RA04 /N 482205120154 CHIP 150kΩ ±5% 1/10W NI05154110
RA06 /N 482211190896 CHIP 100kΩ ±5% 1/10W NI05104110
RA07 /N 482211710833 CHIP 10kΩ ±5% 1/10W NI05103110
RA08 /N 482205120154 CHIP 150kΩ ±5% 1/10W NI05154110
RA09 /N 482211711449 CHIP 2.2kΩ ±5% 1/10W NI05222110
RA10 /N 482211710833 CHIP 10kΩ ±5% 1/10W NI05103110
RA11 482210011351 TRIM. 10kΩ RH0638CJ4R RA01030780
RA12 /K,/S,/U 482211190892 CHIP 0Ω ±5% 1/10W NI05000110
RA13 /K,/S,/U 482211190892 CHIP 0Ω ±5% 1/10W NI05000110
RA14 /K,/S,/U 482211190892 CHIP 0Ω ±5% 1/10W NI05000110
P101-SEMICONDUCTORS
D201 482213033944 CHIP DIODE DAN202K HZ20002210
D202 996500003403 CHIP ZENER DIODE 02CZ9.1-X HZ30031050
D502 /N 996500003082 CHIP DIODE MA704WA
30V 30mA 1V
HZ20043020
D504 996500003401 CHIP DIODE RB425D HZ20030210
DA01 482212550416 VARICAP SVC342-L HD40009030
DA02 /N 996500003402 CHIP DIODE 1SS356-TW11 HZ21302210
DA03 /N 482212550416 VARICAP SVC342-L HD40009030
DA04 /N 996500003402 CHIP DIODE 1SS356-TW11 HZ21302210
DA05 996500003400 CHIP DIODE MA716 HZ20030020
Q201 996500001369 IC LA1837 FM AM IF MPX HC10384030
Q202 482213062294 TRS. 2SC1809S P
150MW 500MHz
HT318091P0
Q203 482213061227 DIG.TRS.
DTA114ES UN4111 10K 10K
BA10001000
Q204 482213042594 DIG.TRS.
DTC144ES UN4213 47K 47K
BA20002000
Q301 /K,/N,/S 482220983631 IC NJM4558MD HC10035090
Q351 /N,/S 482220916175 IC LC72720L RDS DECODER HC10385030
Q352 /N,/S 482213061227 DIG.TRS.
DTA114ES UN4111 10K 10K
BA10001000
Q353 /N,/S 482213060588 DIG.TRS.
DTC114ES UN4211 10K 10K
BA20001000
Q354 /N,/S 482213041947 TRS. 2SC2458 2SC1740S
2SC3199 ETC
HT30001000
Q501 996500001370 IC LC72130 HC10394030
QA01 /N 482213041947 TRS. 2SC2458 2SC1740S
2SC3199 ETC.
HT30001000
QA02 /N 482213041947 TRS. 2SC2458 2SC1740S
2SC3199 ETC.
HT30001000
QA03 /N 482213061892 TRS. 2SD2144S U OR V HT421442A0
QA04 /N 482213061227 DIG.TRS.
DTA114ES UN4111 10K 10K
BA10001000
QA05 /N 482213061227 DIG.TRS.
DTA114ES UN4111 10K 10K
BA10001000
QA06 /N 482213060588 DIG.TRS.
DTC114ES UN4211 10K 10K
BA20001000
P101-MISCELLANEOUS
A101 996500003387 VHF TUNER
FM FRONT END EF415-G23
AV01202270
F201 /K,/N 482224270665 CER. FILTER SFE10.7MS3-A FF11070620
F201 /U 482224270911 CER. FILTER SFF10.7MA8-A FF11070610
F202 482224270665 CER. FILTER SFE10.7MS3-A FF11070620
FA01 CER. FILTER SFZ450JL3 451K FF10045410
J101 482229081632 TERMINAL YKD31-0215A
FM AM ANT PAL TYPE
YT03030020
J105 PLUG SOCKET 12P 12MQ-ST-L YP06902090
L201 482215763904 I.F.T. COIL FM DET
M292BEAS-5968Z
LI70376010
L301 482215771731 M.P.X. COIL LPF-V10-A1
19 38kHz
LS10293020
L302 482215771731 M.P.X. COIL LPF-V10-A1
19 38kHz
LS10293020
L350
/N,/S 482211190892 CHIP 0Ω ±5% 1/10W NI05000110
L356
L359 /N,/S 482211190892 CHIP 0Ω ±5% 1/10W NI05000110
L501
482211190892 CHIP 0Ω ±5% 1/10W NI05000110
L504
LA01 482215763084 MW ANT COIL 280µH LA10295170
LA02 482215770779 OSC. COIL MW LO70013010
LA03 /N 482215752714 LW ANT COIL FOR LA1267 LA10295160
LA04 /N 482215770781 OSC. COIL LW OSC LO70013020
LA05 482215753589 CHOKE COIL TL-8 393J LC23960710
LA06 482214881095 I.F.T. COIL AM IFT K7-H5
FOR SFP450D
LI70033510
S301 /K 482227721712 SLIDE SWITCH SSSS92 SS02021470
X351 /N,/S 482224210857 CRYSTAL 4.332MHz AT-49 JX04003260
X501 482224272333 CRYSTAL AD0618CTB 7.2MHz JX07001260
P604-DOLBY DTS DSP
CIRCUIT BOARD
P604-CAPACITORS
C601 482212611703 CER. CHIP 0.01µF DK98103300
C602 482212611703 CER. CHIP 0.01µF DK98103300
C603 482212490353 ELECT. 100µF 10V OA10701020
C607 482212611687 CER. CHIP 0.1µF DK98104200
C608 482212233761 CER. CHIP 22pF 50V DD95220300
C609 482212233761 CER. CHIP 22pF 50V DD95220300
C610 482212611687 CER. CHIP 0.1µF DK98104200
C611 482212490353 ELECT. 100µF 10V OA10701020
C612 482212142327 FILM FILM CAP DF15471350
C613 482212611687 CER. CHIP.1µF DK98104200
C614 482212611687 CER. CHIP 0.1µF DK98104200
C615 482212611687 CER. CHIP 0.1µF DK98104200
C616 532212611583 CER. CHIP 0.01µF 50V DK96103200
C617 482212611687 CER. CHIP 0.1µF DK98104200
C618 482212611687 CER. CHIP 0.1µF DK98104200
C619 482212490353 ELECT. 100µF 10V OA10701020
C620 482212490353 ELECT. 100µF 10V OA10701020
C621 482212611687 CER. CHIP 0.1µF DK98104200
C622 482212490353 ELECT. 100µF 10V OA10701020
C623 482212611687 CER. CHIP 0.1µF DK98104200
C624 482212611687 CER. CHIP 0.1µF DK98104200
C626 482212490353 ELECT. 100µF 10V OA10701020
C691 482212231765 CER. CHIP 100pF 50V DD95101300
C692 482212611687 CER. CHIP 0.1µF DK98104200
