71
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
QR08 482220933519 IC TC7W74F HC10381050
P604-MISCELLANEOUS
J691 PLUG SOCKET 12P 12MQ-ST-L YP06902090
JD01 PLUG SOCKET 12P 12MQ-ST-L YP06902090
JR01 482226510682 TERMINAL RCA 3P BLK NI YT02030420
JR01 8000 TERMINAL RCA 3P BLK AU YT02030610
JR04 482221811487 OPT. CONNECTOR GP1F32R
OPTICAL RECIVER
YJ15000150
JR05 482221811487 OPTICAL RECIVER GP1F32R YJ15000150
JR06 8000 482221811487 OPTICAL RECIVER GP1F32R YJ15000150
JR07 482226731729 TERMINAL RCA 1P BLK NI YT02010780
JR07 8000 482229081638 TERMINAL RCA 1P BLK NI YT02010790
JR08 482226731369 OPTICAL OUTPUT GP1F32T YJ15000090
L601 482224273843 EMI FILTER DSS306-91-F-223Z FM12223010
L691 482215710884 FERRITE INDUCTOR BLM11 FN31000010
L693
482215710884 FERRITE INDUCTOR BLM11 FN31000010
L697
LD01 482252610584 FERRITE ZBF-503D-00TA FC90090010
LD02 8000 482252610584 FERRITE ZBF-503D-00TA FC90090010
LD03 8000 482252610584 FERRITE ZBF-503D-00TA FC90090010
LD55 482224273843 EMI FILTER DSS306-91-F-223Z FM12223010
LD58 482224273843 EMI FILTER DSS306-91-F-223Z FM12223010
LH01 482252610584 FERRITE ZBF-503D-00TA FC90090010
LH02 482252610584 FERRITE ZBF-503D-00TA FC90090010
LK01 482252610584 FERRITE ZBF-503D-00TA FC90090010
LK02 482252610584 FERRITE ZBF-503D-00TA FC90090010
LK03 482252610584 FERRITE ZBF-503D-00TA FC90090010
LR01 482214260422 PULSE TRNSF.
TPS247MN-0386AN
TP41042030
LR02 482224273843 EMI FILTER DSS306-91-F-223Z FM12223010
X601 482224210851 CRYSTAL 12.288MHz AT-49 JX12013260
X691 482224281727 SERAMIC VIB.
CST10.0MTW-TF01 10.0MHz
FQ01005010
P704-5CH POWER AMP
CIRCUIT BOARD
P704-CAPACITORS
C701 482212422275 ELECT. 47µF M 10V RA-2 OA47601020
C702 482212422275 ELECT. 47µF M 10V RA-2 OA47601020
C705 /N 482212170437 FILM 1000pF J 100V APSV OF15102540
C706 /N 482212170437 FILM 1000pF J 100V APSV OF15102540
C707 482212422276 ELECT. 47µF M 50V RA-2 OA47605020
C708 482212422276 ELECT. 47µF M 50V RA-2 OA47605020
C709 482212231205 CER. 47pF J CH 50V BLK DD15470300
C710 482212231205 CER. 47pF J CH 50V BLK DD15470300
C711 /N 996500003406 FILM 150pF J 100V APSV OF15151540
C712 /N 996500003406 FILM 150pF J 100V APSV OF15151540
C713 482212490362 ELECT. 22µF M 50V RA-2 OA22605020
C714 482212490362 ELECT. 22µF M 50V RA-2 OA22605020
C715
482212423068 ELECT. 220µF 63V M RA-2 OA22706320
C718
C719 482212411533 ELECT. 1µF100V RA-2 OA10510020
C720 482212411533 ELECT. 1µF100V RA-2 OA10510020
C725
482212231211 CER. 100pF 500V DK16101550
C728
CP01 482212422275 ELECT. 47µF M 10V RA-2 OA47601020
CP02 482212422275 ELECT. 47µF M 10V RA-2 OA47601020
CP07 482212422276 ELECT. 47µF M 50V RA-2 OA47605020
CP08 482212422276 ELECT. 47µF M 50V RA-2 OA47605020
CP09 482212231205 CER. 47pF J CH 50V BLK DD15470300
CP10 482212231205 CER. 47pF J CH 50V BLK DD15470300
CP13 482212490362 ELECT. 22µF M 50V RA-2 OA22605020
CP14 482212490362 ELECT. 22µF M 50V RA-2 OA22605020
CP15
482212423068 ELECT. 220µF 63V M RA-2 OA22706320
CP18
CP19 482212411533 ELECT. 1µF100V RA-2 OA10510020
CP20 482212411533 ELECT. 1µF100V RA-2 OA10510020
CP25
482212231211 CER. 100pF 500V DK16101550
CP28
CT01 482212422275 ELECT. 47µF M 10V RA-2 OA47601020
CT05 /N 482212170437 FILM 1000pF J 100V APSV OF15102540
CT07 482212422276 ELECT. 47µF M 50V RA-2 OA47605020
CT09 482212231205 CER. 47pF J CH 50V BLK DD15470300
CT11 /N 996500003406 FILM 150pF J 100V APSV OF15151540
CT13 482212490362 ELECT. 22µF M 50V RA-2 OA22605020
CT15 482212423068 ELECT. 220µF 63V M RA-2 OA22706320
CT17 482212423068 ELECT. 220µF 63V M RA-2 OA22706320
CT19 482212411533 ELECT. 1µF100V RA-2 OA10510020
CT25 482212231211 CER. 100pF 500V DK16101550
CT27 482212231211 CER. 100pF 500V DK16101550
P704-CAPACITORS (COMMON)
PLASTIC FILM CAPACITOR
±5% 50V : C703 C704
C705-C706[/K,/U]
C711-C712[/K,/U] CP03-CP06
CP11 CP12 CP21-CP24 CT03
CT05[/K,/U] CT11K,/U]
HIGH DIELECTRIC CONSTANT
CER. CAPACITOR ±10% 50V :
C721-C724 CT21 CT23
P704-RESISTORS
R709 482205022202 2.2kΩ ±5% 1/6W GG05222160
R710 482205022202 2.2kΩ ±5% 1/6W GG05222160
R713 482205022202 2.2kΩ ±5% 1/6W GG05222160
R714 482205022202 2.2kΩ ±5% 1/6W GG05222160
R727
482205026809 68Ω 1/6W GG05680160
R732
R737 996500001566 TRIM. VAR. 2.2kΩ VERT RA02220760
R738 996500001566 TRIM. VAR. 2.2kΩ VERT RA02220760
R739
482205022209 22Ω J 1/4W GG05220140
R742
R743
482205210101 100Ω 1/6W GG05101160
R746
R747
JUMPER 75060501P0
R750
R751 482205021801 180Ω J 1/4W GG05181140
R752 482205021801 180Ω J 1/4W GG05181140
R759 482205210122 1.2kΩ ±5% 1/6W GG05122160
R760 482205210122 1.2kΩ ±5% 1/6W GG05122160
R761 482211380612 FIXED 0.18Ω K 5W X2
RGC55 W/T.P
BZ10182020
R762 482211380612 FIXED 0.18Ω K 5W X2
RGC55 W/T.P
BZ10182020
R763 482211683929 220Ω J 1/4W GG05221140
R764 482211683929 220Ω J 1/4W GG05221140
R765 482205310109 10Ω ±5% 1W GA05100010
R766 482205310109 10Ω ±5% 1W GA05100010
R767 996500003407 TRIM. VAR. 22K VERTICAL RA02230760
R768 996500003407 TRIM. VAR. 22K VERTICAL RA02230760
R773
482205210478 4.7Ω ±5% 1/6W GG05047160
R776
