Marantz SR8000 - Page 48

72
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
RP09 482205022202 2.2kΩ ±5% 1/6W GG05222160
RP10 482205022202 2.2kΩ ±5% 1/6W GG05222160
RP13 482205022202 2.2kΩ ±5% 1/6W GG05222160
RP14 482205022202 2.2kΩ ±5% 1/6W GG05222160
RP27 482205210681 680Ω 1/6W GG05681160
RP28 482205210681 680Ω 1/6W GG05681160
RP29
482205026809 68Ω 1/6W GG05680160
RP32
RP37 996500001566 TRIM. VAR. 2.2kΩ VERT RA02220760
RP38 996500001566 TRIM. VAR. 2.2kΩ VERT RA02220760
RP39
482205022209 22Ω J 1/4W GG05220140
RP42
RP43
482205210101 100Ω 1/6W GG05101160
RP46
RP47
JUMPER 75060501P0
RP50
RP51 482205021801 180Ω J 1/4W GG05181140
RP52 482205021801 180Ω J 1/4W GG05181140
RP59 482205210122 1.2kΩ ±5% 1/6W GG05122160
RP60 482205210122 1.2kΩ ±5% 1/6W GG05122160
RP61 482211380612 FIXED 0.18Ω K 5W X2
RGC55 W/T.P
BZ10182020
RP62 482211380612 FIXED 0.18Ω K 5W X2
RGC55 W/T.P
BZ10182020
RP63 482211683929 220Ω J 1/4W GG05221140
RP64 482211683929 220Ω J 1/4W GG05221140
RP65 482205310109 10Ω ±5% 1W GA05100010
RP66 482205310109 10Ω ±5% 1W GA05100010
RP67 996500003407 TRIM. VAR. 22kΩ VERTICAL RA02230760
RP68 996500003407 TRIM. VAR. 22kΩ VERTICAL RA02230760
RP73
482205210478 4.7Ω ±5% 1/6W GG05047160
RP76
RT09 482205022202 2.2kΩ ±5% 1/6W GG05222160
RT13 482205022202 2.2kΩ ±5% 1/6W GG05222160
RT27 482205210681 680Ω 1/6W GG05681160
RT29 482205026809 68Ω 1/6W GG05680160
RT31 482205026809 68Ω 1/6W GG05680160
RT37 996500001566 TRIM. VAR. 2.2kΩ VERT RA02220760
RT39 482205022209 22Ω J 1/4W GG05220140
RT41 482205022209 22Ω J 1/4W GG05220140
RT43 482205210101 100Ω 1/6W GG05101160
RT45 482205210101 100Ω 1/6W GG05101160
RT47 JUMPER 75060501P0
RT49 JUMPER 75060501P0
RT51 482205021801 180Ω J 1/4W GG05181140
RT59 482205210122 1.2kΩ ±5% 1/6W GG05122160
RT61 482211380612 FIXED 0.18Ω K 5W X2
RGC55 W/T.P
BZ10182020
RT63 482211683929 220Ω J 1/4W GG05221140
RT65 482205310109 10Ω ±5% 1W GA05100010
RT67 996500003407 TRIM. VAR. 22K VERTICAL RA02230760
RT73 482205210478 4.7Ω ±5% 1/6W GG05047160
RT75 482205210478 4.7Ω ±5% 1/6W GG05047160
P74-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : R701-R708 R712
R712 R715-R726 R733-R736
R753-R772 RP01-RP08 RP11
RP12 RP15-RP26 RP33-RP36
RP53-RP72 RT01 RT03 RT05
RT11 RT15 RT17 RT19 RT21
RT23 RT25 RT33 RT35 RT53
RT55 RT57 RT69 RT71
P704-SEMICONDUCTORS
D701
482213032362 DIODE 1SS176 MA165 1SS254 HD20002000
D704 30V 0.1A
D705
482213080837 DIODE HSS81TD 150V 150mA HD20027010
D708
D709
482213083142 ZENER DIODE 6.2V HD30621000
D712
D713 482213080837 DIODE HSS81TD 150V 150mA HD20027010
D714 482213080837 DIODE HSS81TD 150V 150mA HD20027010
D715
482213032362 DIODE 1SS176 MA165 1SS254 HD20002000
D718 30V 0.1A
DP01
482213032362 DIODE 1SS176 MA165 1SS254 HD20002000
DP04 30V 0.1A
DP05
482213080837 DIODE HSS81TD 150V 150mA HD20027010
DP08
DP09
482213083142 ZENER DIODE 6.2V HD30621000
DP12
DP13 482213080837 DIODE HSS81TD 150V 150mA HD20027010
DP14 482213080837 DIODE HSS81TD 150V 150mA HD20027010
DP17 482213032362 DIODE 1SS176 MA165 1SS254 HD20002000
DP18 30V 0.1A
DT01 482213032362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DT03 482213032362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DT05 482213080837 DIODE HSS81TD 150V 150mA HD20027010
DT07 482213080837 DIODE HSS81TD 150V 150mA HD20027010
DT09 482213083142 ZENER DIODE 6.2V HD30621000
DT11 482213083142 ZENER DIODE 6.2V HD30621000
DT13 482213080837 DIODE HSS81TD 150V 150mA HD20027010
DT15 482213032362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DT17 482213032362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
Q701
482213042949 TRS. 2SA970 GR OR BL HT109702A0
Q704
Q705 482213042999 TRS. 2SA1145 O OR Y HT111452A0
Q706 482213042999 TRS. 2SA1145 O OR Y HT111452A0
Q707 482213043233 TRS. 2SC2240 GR OR BL HT322402A0
Q708 482213043233 TRS. 2SC2240 GR OR BL HT322402A0
Q709 532213061728 TRS. 2SA1360 O OR Y HT113602A0
Q710 532213061728 TRS. 2SA1360 O OR Y HT113602A0
Q711 532213061737 TRS. 2SC3423 O OR Y HT334232A0
Q712 532213061737 TRS. 2SC3423 O OR Y HT334232A0
Q713 482213060117 TRS. 2SC3419 Y
40V 0.8A PC=1.2W 5W
HT334191Y0
Q714 482213060117 TRS. 2SC3419 Y
40V 0.8A PC=1.2W 5W
HT334191Y0
Q715 482213063635 TRS. 2SC4793 O Y HT347932A0
Q716 482213063635 TRS. 2SC4793 O Y HT347932A0
Q717 482213063634 TRS. 2SA1837 O Y HT118372A0
Q718 482213063634 TRS. 2SA1837 O Y HT118372A0
Q719 482213043233 TRS. 2SC2240 GR OR BL HT322402A0
Q720 482213043233 TRS. 2SC2240 GR OR BL HT322402A0
Q721 482213011486 TRS. 2SC5200 R OR O
230V 15A 150W
HT352002A0
Q722 482213011486 TRS. 2SC5200 R OR O
230V 15A 150W
HT352002A0
