Marantz SR8000 - Page 49

73
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
Q723 482213063119 TRS. 2SA1943 R OR O
230V 15A 150W
HT119432A0
Q724 482213063119 TRS. 2SA1943 R OR O
230V 15A 150W
HT119432A0
QP01
482213042949 TRS. 2SA970 GR OR BL HT109702A0
QP04
QP05 482213042999 TRS. 2SA1145 O OR Y HT111452A0
QP06 482213042999 TRS. 2SA1145 O OR Y HT111452A0
QP07 482213043233 TRS. 2SC2240 GR OR BL HT322402A0
QP08 482213043233 TRS. 2SC2240 GR OR BL HT322402A0
QP09 532213061728 TRS. 2SA1360 O OR Y HT113602A0
QP10 532213061728 TRS. 2SA1360 O OR Y HT113602A0
QP11 532213061737 TRS. 2SC3423 O OR Y HT334232A0
QP12 532213061737 TRS. 2SC3423 O OR Y HT334232A0
QP13 482213060117 TRS. 2SC3419 Y
40V 0.8A PC=1.2W 5W
HT334191Y0
QP14 482213060117 TRS. 2SC3419 Y
40V 0.8A PC=1.2W 5W
HT334191Y0
QP15 482213063635 TRS. 2SC4793 O Y HT347932A0
QP16 482213063635 TRS. 2SC4793 O Y HT347932A0
QP17 482213063634 TRS. 2SA1837 O Y HT118372A0
QP18 482213063634 TRS. 2SA1837 O Y HT118372A0
QP19 482213043233 TRS. 2SC2240 GR OR BL HT322402A0
QP20 482213043233 TRS. 2SC2240 GR OR BL HT322402A0
QP21 482213011486 TRS. 2SC5200 R OR O
230V 15A 150W
HT352002A0
QP22 482213011486 TRS. 2SC5200 R OR O
230V 15A 150W
HT352002A0
QP23 482213063119 TRS. 2SA1943 R OR O
230V 15A 150W
HT119432A0
QP24 482213063119 TRS. 2SA1943 R OR O
230V 15A 150W
HT119432A0
QT01 482213042949 TRS. 2SA970 GR OR BL HT109702A0
QT03 482213042949 TRS. 2SA970 GR OR BL HT109702A0
QT05 482213042999 TRS. 2SA1145 O OR Y HT111452A0
QT07 482213043233 TRS. 2SC2240 GR OR BL HT322402A0
QT09 532213061728 TRS. 2SA1360 O OR Y HT113602A0
QT11 532213061737 TRS. 2SC3423 O OR Y HT334232A0
QT13 482213060117 TRS. 2SC3419 Y
40V 0.8A PC=1.2W 5W
HT334191Y0
QT15 482213063635 TRS. 2SC4793 O Y HT347932A0
QT17 482213063634 TRS. 2SA1837 O Y HT118372A0
QT19 482213043233 TRS. 2SC2240 GR OR BL HT322402A0
QT21 482213011486 TRS. 2SC5200 R OR O
230V 15A 150W
HT352002A0
QT23 482213063119 TRS. 2SA1943 R OR O
230V 15A 150W
HT119432A0
K709 TRS. KIT 2SA1360 2SC3423
PAIR O OR Y
HK136019C0
K710 TRS. KIT 2SA1360 2SC3423
PAIR O OR Y
HK136019C0
K715 TRS. KIT 2SA1837 2SC4793
HFE SELECTED RANK
HK183719C0
K716 TRS. KIT 2SA1837 2SC4793
HFE SELECTED RANK
HK183719C0
K721 TRS. KIT 2SA1943 2SC5200
RR OR OO PAIR
HK194319C0
K722 TRS. KIT 2SA1943 2SC5200
RR OR OO PAIR
HK194319C0
KP09 TRS. KIT 2SA1360 2SC3423
PAIR O OR Y
HK136019C0
KP10 TRS. KIT 2SA1360 2SC3423
PAIR O OR Y
HK136019C0
KP15 TRS. KIT 2SA1837 2SC4793
HFE SELECTED RANK
HK183719C0
KP16 TRS. KIT 2SA1837 2SC4793
HFE SELECTED RANK
HK183719C0
KP21 TRS. KIT 2SA1943 2SC5200
RR OR OO PAIR
HK194319C0
KP22 TRS. KIT 2SA1943 2SC5200
RR OR OO PAIR
HK194319C0
KT09 TRS. KIT 2SA1360 2SC3423
PAIR O OR Y
HK136019C0
KT15 TRS. KIT 2SA1837 2SC4793
HFE SELECTED RANK
HK183719C0
KT21 TRS. KIT 2SA1943 2SC5200
RR OR OO PAIR
HK194319C0
P704-MISCELLANEOUS
L701 482215770022 AIR COIL SPK CHOCK ML08010030
L702 482215770022 AIR COIL SPK CHOCK ML08010030
LP01 482215770022 AIR COIL SPK CHOCK ML08010030
LP02 482215770022 AIR COIL SPK CHOCK ML08010030
LT01 482215770022 AIR COIL SPK CHOCK ML08010030
P754-SPK TERMINAL
IRCUIT BOARD
P754-CAPACITORS
CN51 /N 482212230103 CER. 0.022µF Z 50V DK18223310
CN52 /N 482212230103 CER. 0.022µF Z 50V DK18223310
CN53 482212240617 CER. 0.1µF 50V DD38104010
CN54 482212240617 CER. 0.1µF 50V DD38104010
CN55 /N 482212230103 CER. 0.022µF Z 50V DK18223310
CN56 /N 482212230103 CER. 0.022µF Z 50V DK18223310
CN57 482212240617 CER. 0.1µF 50V DD38104010
CN58 482212240617 CER. 0.1µF 50V DD38104010
CN59 /N 482212230103 CER. 0.022µF Z 50V DK18223310
CN60 482212240617 CER. 0.1µF 50V DD38104010
P754-MISCELLANEOUS
JN61 482226511199 TERMINAL SPK 6P YT01060020
JN62 482226511198 TERMINAL SPK 4P YT01040790
P904-RC-5 IN OUT
DC-CONTROL
CIRCUIT BOARD
P904-CAPACITORS
C901 532212234098 CER. CHIP 0.01µF DK56103300
C902 532212421731 ELECT. 10µF M 50V RA-2 OA10605020
C903 532212234098 CER. CHIP 0.01µF DK56103300
C904 482212441534 ELECT. 10µF M 25V RA-2 OA10602520
C905 532212234098 CER. CHIP 0.01µF DK56103300
C906 482211190892 CHIP CHIP 40Ω ±5% 1/10W NI05000110
C907 532212234098 CER. CHIP 0.01µF DK56103300
C908 532212234098 CER. CHIP 0.01µF DK56103300
C909 482211190892 CHIP CHIP 40Ω ±5% 1/10W NI05000110
C910 532212234098 CER. CHIP 0.01µF DK56103300
C911 482212441543 ELECT. 1µF M 50V RA-2 OA10505020
C912 532212234098 CER. CHIP 0.01µF DK56103300
C913 532212234098 CER. CHIP 0.01µF DK56103300
C914 482212441543 ELECT. 1µF M 50V RA-2 OA10505020
C915 532212234098 CER. CHIP 0.01µF DK56103300
P904-RESISTORS
R901 482205120479 CHIP 47Ω ±5% 1/10W NI05470110
R902 482211710833 CHIP 10kΩ ±5% 1/10W NI05103110
R903 482211711504 CHIP 270Ω ±5% 1/10W NI05271110
R904 482205120153 CHIP 220Ω ±5% 1/10W NI05221110
R905 482205120479 CHIP 47Ω ±5% 1/10W NI05470110
R906 482205120332 CHIP 3.3kΩ ±5% 1/10W NI05332110
R907 482211711449 CHIP 2.2kΩ ±5% 1/10W NI05222110
R908 996500003408 VAR. RK09D111 20kΩ B RK02031090
R909 482211710833 CHIP 10kΩ ±5% 1/10W NI05103110
R910 482211711449 CHIP 2.2kΩ ±5% 1/10W NI05222110
R911 482205120332 CHIP 3.3kΩ ±5% 1/10W NI05332110
