Marantz SR8000 - Page 50

74
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
R912 482211711449 CHIP 2.2kΩ ±5% 1/10W NI05222110
R913 996500003408 VAR. RK09D111 20kΩ B RK02031090
R914 482211710833 CHIP 10kΩ ±5% 1/10W NI05103110
R915 482211711449 CHIP 2.2kΩ ±5% 1/10W NI05222110
P904-SEMICONDUCTORS
Q901 482213061227 DIG.TRS.
DTA114ES UN4111 10K 10K
BA10001000
Q902 482213090347 PHOTO UNIT PC-817
PHOTO CUPLER 1PAIR
HW10006320
Q903 482213060588 DIG.TRS.
DTC114ES UN4211 10K 10K
BA20001000
Q904 482213061227 DIG.TRS.
DTA114ES UN4111 10K 10K
BA10001000
Q905 482213043233 TRS. 2SC2240 GR HT322401A0
Q906 482213060588 DIG.TRS.
DTC114ES UN4211 10K 10K
BA20001000
Q907 482213061227 DIG.TRS.
DTA114ES UN4111 10K 10K
BA10001000
Q908 482213043233 TRS. 2SC2240 GR HT322401A0
P904-MISCELLANEOUS
J902 996500003413 TERMINAL RCA 2P O F-G NI YT02021640
J903 996500003414 TERMINAL RCA 2P G F-G NI YT02021650
J904 996500003411 JACK LGY6501-0600 YJ01004670
J905 996500003411 JACK LGY6501-0600 YJ01004670
PB04-BACK UP
CIRCUIT BOARD FOR U
PB04-CAPACITORS
CB01 /U 482212233276 CER. DE7150 F 103M VA1 KC DK17103840
CB02 /U 482212230043 CER. 0.01µF Z 50V DK18103310
CB03 /U 482212230043 CER. 0.01µF Z 50V DK18103310
CB04 /U 482212441541 ELECT. 470µF M 35V RA-2 OA47703520
CB05 /U 482212230043 CER. 0.01µF Z 50V DK18103310
CB06 /U ELECT. 470µF M 35V EA47703510
CB07 /U 482212230043 CER. 0.01µF Z 50V DK18103310
CB08 532212421731 ELECT. 10µF M 50V RA-2 OA10605020
CB09 /U 482212230043 CER. 0.01µF Z 50V DK18103310
CB10 /U 482212440763 ELECT. 2.2µF M 50V RA-2 OA22505020
CB11 /U 482212230043 CER. 0.01µF Z 50V DK18103310
CB13 /U 482212490355 ELECT. 100µF M 50V RA-2 OA10705020
CB15 /U 482212480772 ELECT. 47µF M 35V RA-2 OA47603520
CB16 /U 482212441541 ELECT. 470µF M 35V OA47703520
PB04-RESISTORS
RB01 /U 2.2MΩ ±10% 1/2W FOR UL RC10225820
RB07 /U 482205310102 1kΩ ±5% 1W GA05102010
RB12 /U 482211710158 1Ω J 1/4W GG05010140
PB04-RESISTORS (COMMON)
/U CARBON FILM FIXED RES.
±5% 1/6W :
RB02-RB04 RB08 RB09
PB04-SEMICONDUCTORS
DB01
/U 482213082421 DIODE 1D3 1A 200V HD20002710
DB06
DB07 /U 482213010413 BRIDGE DIODE D2SBA20 HE20027290
DB08 /U 482213081247 DIODE WJ43 HD20031050
DB11
/U 482213082421 DIODE 1D3 1A 200V HD20002710
DB14
DB16 /U 482213080273 ZENER DIODE 8.2V HD30821000
DB17 /U JUMPER 75060501P0
QB01 /U 482213042949 TRS. 2SA970 GR OR BL HT109702A0
QB02 /U 482213060588 DIG.TRS.
DTC114ES UN4211 10K 10K
BA20001000
QB03 /U 482220973674 IC NJM7806FA +6W 1A HC38906090
QB04 /U 482220914883 IC S-806C HC10075530
PB04-MISCELLANEOUS
FB01 /U FUSE 8A 125V SM8 UL CSA FS10800540
JB05 /U JACK 2P AC OUTLET
CCT1304-0212
YJ04002040
LB01 /U MAINS TRANSF. EI48-20T
120V 60Hz
TS14831010
LB02 /U 482228080773 RELAY VS24MB-NR
TV-8 SEMKO LISTED
LY10240240
PB54-BACK UP
CIRCUIT BOARD FOR K N S
PB54-CAPACITORS
CB51 /K,/N,/S 482212233276 CER. DE7150 F 103M VA1 KC DK17103840
CB52 /K,/N,/S 482212230043 CER. 0.01µF Z 50V DK18103310
CB53 /K,/N,/S 482212230043 CER. 0.01µF Z 50V DK18103310
CB54 /K,/N,/S 482212441541 ELECT. 470µF M 35V RA-2 OA47703520
CB55 /K,/N,/S 482212230043 CER. 0.01µF Z 50V DK18103310
CB56 /K,/N,/S 482212441541 ELECT. 470µF M 35V RA-2 OA47703520
CB57 /K,/N,/S 482212230043 CER. 0.01µF Z 50V DK18103310
CB58 /K,/N,/S 532212421731 ELECT. 10µF M 50V RA-2 OA10605020
CB59 /K,/N,/S 482212230043 CER. 0.01µF Z 50V DK18103310
CB60 /K,/N,/S 482212440763 ELECT. 2.2µF M 50V RA-2 OA22505020
CB61 /K,/N,/S 482212230043 CER. 0.01µF Z 50V DK18103310
CB63 /K,/N,/S 482212490355 ELECT. 100µF M 50V RA-2 OA10705020
CB65 /K,/N,/S 482212480772 ELECT. 47µF M 35V RA-2 OA47603520
CB66 /K,/N,/S 482212441541 ELECT. 470µF M 35V OA47703520
PB54-RESISTORS
RB57 /K,/N,/S 482205310102 1kΩ ±5% 1W GA05102010
RB62 /K,/N,/S 482211710158 1Ω J 1/4W GG05010140
PB54-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W :
RB52-RB54 RB58 RB59
PB54-SEMICONDUCTORS
DB51
/K,/N,/S 482213082421 DIODE 1D3 1A 200V HD20002710
DB56
DB57 /K,/N,/S 482213010413 BRIDGE DIODE D2SBA20 HE20027290
DB58 /K,/N,/S 482213081247 DIODE WJ43 HD20031050
DB61
/K,/N,/S 482213082421 DIODE 1D3 1A 200V HD20002710
DB64
DB66 /K,/N,/S 482213080273 ZENER DIODE 8.2V HD30821000
DB67 /K,/N,/S JUMPER 75060501P0
QB51 /K,/N,/S 482213042949 TRS. 2SA970 GR OR BL HT109702A0
QB52 /K,/N,/S 482213060588 DIG.TRS.
DTC114ES UN4211 10K 10K
BA20001000
QB53 /K,/N,/S 482220973674 IC NJM7806FA +6W 1A HC38906090
QB54 /K,/N,/S 482220914883 IC S-806C HC10075530
PB54-SEMICONDUCTORS
FB51 /K,/N,/S 482207033152 FUSE T3.15A 250V BS LISTED FS10315850
JB55 /N 482226731952 JACK AC OUTLET 2P N YJ04002080
LB51 /K,/N,/S MAINS TRANSF.
EI48-20T 220V 50Hz
TS14831020
LB52 /K,/N,/S 482228080773 RELAY VS24MB-NR
TV-8 SEMKO LISTED
LY10240240
PB74-POWER SW
CIRCUIT BOARD FOR N.K.S
CB71 /K,/N,/S 482212233276 CER. SPERK KILLER 0.01µF DK17103840
SB71 /K,/N,/S 996500001361 PUSH SWITCH SDDLB1
POWER SW TV-5
SP01012470
