Marantz SR8000 - Page 54

78
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
QL66 8000
/K,/S
482213061227 DIG.TRS.
DTA114ES/UN4111 10K 10K
BA10001000
QL67 8000 482213041947 TRS. 2SC2458 2SC1740S
2SC3199 ETC.
HT30001000
QL68 482220960328 IC NJM2244M 3INPUT VIDEO HC10160090
QY61 532220911532 IC 74HC4094 16PIN DIP HC709449B0
PL04-MISCELLANEOUS
JL01 996500003415 TERMINAL RCA 3P Y F-G NI YT02030590
JL01 8000 TERMINAL RCA 3P Y F-G AU YT02030600
JL02 996500003415 TERMINAL RCA 3P Y F-G NI YT02030590
JL02 8000 TERMINAL RCA 3P Y F-G AU YT02030600
JL03 482226511201 TERMINAL RCA 2P Y F-S NI YT02021470
JL03 8000 TERMINAL RCA 2P Y F-S AU YT02021630
JL04 PLUG SOCKET 12P YP06902090
JL05 PLUG SOCKET 12P YP06902090
LL01 996500003404 CHIP INDUCTANCE 33µH LU15333010
LL02 482224273843 EMI FILTER DSS306-91-F-223Z FM12223010
LL03 482224273843 EMI FILTER DSS306-91-F-223Z FM12223010
XL01 482224280288 CRYSTAL 14.31818MHz JX14001260
XL02 /K,/N,/S 482224273903 CRYSTAL 17.31818MHz JX17001260
XL62 8000
/K,/S
482224273903 CRYSTAL 17.31818MHZ JX17001260
PL54-S-VIDEO FUNCTION
CIRCUIT BOARD
PL54-CAPACITORS
CX01
532212421731 ELECT. 10µF M 50V RA-2 OA10605020
CX08
CX09 482212441796 ELECT. 22µF M 16V RA-2 OA22601620
CX10 996500001040 ELECT. 470µF M 6.3V RA-2 OA47700620
CX11 532212421731 ELECT. 10µF M 50V RA-2 OA10605020
CX12 532212421731 ELECT. 10µF M 50V RA-2 OA10605020
CX13 482212441796 ELECT. 22µF M 16V RA-2 OA22601620
CX14 996500001040 ELECT. 470µF M 6.3V RA-2 OA47700620
CX20 532212234098 CER. CHIP 0.01µF DK56103300
CX21 532212421731 ELECT. 10µF M 50V RA-2 OA10605020
CX22 532212234098 CER. CHIP 0.01µF DK56103300
CX23 532212234098 CER. CHIP 0.01µF DK56103300
CX24 532212234098 CER. CHIP 0.01µF DK56103300
CX25 532212421731 ELECT. 10µF M 50V RA-2 OA10605020
CX26 532212234098 CER. CHIP 0.01µF DK56103300
CX27 532212234098 CER. CHIP 0.01µF DK56103300
CX28 482212440763 ELECT. 2.2µF M 50V RA-2 OA22505020
CX29 482212441543 ELECT. 1µF M 50V RA-2 OA10505020
CX30 CER. CHIP 1200pF DK56122300
CX31 482212441543 ELECT. 1µF M 50V RA-2 OA10505020
CX32 532212234098 CER. CHIP 0.01µF DK56103300
CX33 482212490353 ELECT. 100µF M 10V RA-2 OA10701020
CX34 482212441543 ELECT. 1µF M 50V RA-2 OA10505020
CX35 482212490353 ELECT. 100µF M 10V RA-2 OA10701020
CX36 532212234098 CER. CHIP 0.01µF DK56103300
CX38 532212232658 CER. CHIP 22pF DD55220300
CX39 482212611591 CER. CHIP 24pF J CH 50V DD15240300
CX40 /K,/N,/S 482212233204 CER. CHIP 15pF DD55150300
CX40 /U 532212232658 CER. CHIP 22pF DD55220300
CX41 /K,/N,/S 482212233204 CER. CHIP 15pF DD55150300
CX41 /U 532212232658 CER. CHIP 22pF DD55220300
CX43 482212441543 ELECT. 1µF M 50V RA-2 OA10505020
CX44 532212234098 CER. CHIP 0.01µF DK56103300
CX45 482212441796 ELECT. 22µF M 16V RA-2 OA22601620
CX46 996500001040 ELECT. 470µF M 6.3V RA-2 OA47700620
CX47 532212421731 ELECT. 10µF M 50V RA-2 OA10605020
CX48 532212234098 CER. CHIP 0.01µF DK56103300
CX49 532212421731 ELECT. 10µF M 50V RA-2 OA10605020
CX50 532212234098 CER. CHIP 0.01µF DK56103300
CX51 532212234098 CER. CHIP 0.01µF DK56103300
CX52 532212234098 CER. CHIP 0.01µF Z 50V DK56103300
CX53 532212421731 ELECT. 10µF M 50V RA-2 OA10605020
CX54 532212421731 ELECT. 10µF M 50V RA-2 OA10605020
CX55 532212421731 ELECT. 10µF M 50V RA-2 OA10605020
CX56
482212490353 ELECT. 100µF M 10V RA-2 OA10701020
CX59
CX60 532212421731 ELECT. 10µF M 50V RA-2 OA10605020
CX61 532212234098 CER. CHIP 0.01µF DK56103300
CX62 532212421731 ELECT. 10µF M 50V RA-2 OA10605020
CX63 532212234098 CER. CHIP 0.01µF DK56103300
CX64 532212234098 CER. CHIP 0.01µF DK56103300
CX66
532212232452 CER. CHIP 47pF CH DD55470300
CX71
PL54-RESISTORS
RX01
482205120829 CHIP 82Ω ±5% 1/10W NI05820110
RX08
RX09 482205120759 CHIP 75Ω ±5% 1/10W NI05750110
RX10 482205120759 CHIP 75Ω ±5% 1/10W NI05750110
RX11 482205120829 CHIP 82Ω ±5% 1/10W NI05820110
RX12 482205120829 CHIP 82Ω ±5% 1/10W NI05820110
RX13 482205120759 CHIP 75Ω ±5% 1/10W NI05750110
RX14 482205120759 CHIP 75Ω ±5% 1/10W NI05750110
RX15
482211190892 CHIP 0Ω ±5% 1/10W NI05000110
RX19
RX20 482211710833 CHIP 10kΩ ±5% 1/10W NI05103110
RX21 482211710833 CHIP 10kΩ ±5% 1/10W NI05103110
RX22 482211190896 CHIP 100kΩ ±5% 1/10W NI05104110
RX23 482211710833 CHIP 10kΩ ±5% 1/10W NI05103110
RX24 482205120822 CHIP 8.2kΩ ±5% 1/10W NI05822110
RX25 482205120153 CHIP 220Ω ±5% 1/10W NI05221110
RX26 482205120153 CHIP 220Ω ±5% 1/10W NI05221110
RX27 482211710833 CHIP 10kΩ ±5% 1/10W NI05103110
RX28 482211710833 CHIP 10kΩ ±5% 1/10W NI05103110
RX29 482211190918 CHIP 4.7kΩ ±5% 1/10W NI05472110
RX30 482211190892 CHIP 0Ω ±5% 1/10W NI05000110
RX31 482205120105 CHIP 1MΩ ±5% 1/10W NI05105110
RX32 482211710834 CHIP 47kΩ ±5% 1/10W NI05473110
RX33 482211710833 CHIP 10kΩ ±5% 1/10W NI05103110
RX34 482211710833 CHIP 10kΩ ±5% 1/10W NI05103110
RX35 482211710833 CHIP 10kΩ ±5% 1/10W NI05103110
RX36 482205120332 CHIP 3.3kΩ ±5% 1/10W NI05332110
RX37 482211711449 CHIP 2.2kΩ ±5% 1/10W NI05222110
RX38 482211710833 CHIP 10kΩ ±5% 1/10W NI05103110
RX39 482205120153 CHIP 220Ω ±5% 1/10W NI05221110
RX41 482205120759 CHIP 75Ω ±5% 1/10W NI05750110
RX42 482205120759 CHIP 75Ω ±5% 1/10W NI05750110
RX43 /U JUMPER 75060501P0
RX44 482211190892 CHIP 0Ω ±5% 1/10W NI05000110
RX46 482205120332 CHIP 3.3kΩ ±5% 1/10W NI05332110
RX47 482211711449 CHIP 2.2kΩ ±5% 1/10W NI05222110
RX49 482211712521 CHIP 68Ω ±5% 1/10W NI05680110
RX50 482211712521 CHIP 68Ω ±5% 1/10W NI05680110
PL54-SEMICONDUCTORS
DX01 996500003401 CHIP DIODE RB425D HZ20030210
DX02 996500003401 CHIP DIODE RB425D HZ20030210
DX04 996500003401 CHIP DIODE RB425D HZ20030210
DX05 996500003401 CHIP DIODE RB425D HZ20030210
QX01 996500003394 IC NJM2296M HC10210090
QX02 996500003394 IC NJM2296M HC10210090
QX03 482220960327 IC NJM2234M HC10196090
QX04 482220960327 IC NJM2234M HC10196090
QX05 482213041947 TRS. 2SC536SP ETC HT30001000
QX06 482220915524 IC OSD LC74781 HC10377030
QX07 /K,/N,/S 482213061189 DIG.TRS.
DTC114TS UN4215 10K
BA20004000
