POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
QX08 /K,/N,/S 482213061189 DIG.TRS.
DTC114TS UN4215 10K
BA20004000
QX09 /K,/N,/S 482213061227 DIG.TRS.
DTA114ES UN4111 10K 10K
BA10001000
QX10 482213041947 TRS. 2SC536SP ETC HT30001000
QX11 996500003391 IC NJM2264M JRC HC10077090
QX12 482213041947 TRS. 2SC536SP ETC HT30001000
PL54-MISCELLANEOUS
JX01 482226531302 TERMINAL 3P S-VIDEO NI YT02030350
JX01 996500001375 3P S-VIDEO JACK GOLD YT02030550
JX02 482226531302 TERMINAL 3P S-VIDEO NI YT02030350
JX02 996500001375 TERMINAL 3P S-VIDEO GOLD YT02030550
JX03 482226520725 TERMINAL 2P S-VIDEO NI YT02021320
JX03 996500001376 TERMINAL 2P S-VIDEO GOLD YT02021520
LX01 996500003404 CHIP INDUCTANCE 33µH LU15333010
LX02 482224273843 EMI FILTER DSS306-91-F-223Z FM12223010
XX01 482224280288 CRYSTAL 14.31818MHz JX14001260
XX02 /K,/N,/S 482224273903 CRYSTAL 17.31818MHz JX17001260
PL74-AUX INPUT
CIRCUIT BOARD
PL74-CAPACITORS
CL71 /S CER. 470pF K 50V DK16471300
CL73 /N,/S 482212231205 CER. 47pF J CH 50V BLK DD15470300
CL73 /S 482212231205 CER. 47pF J CH 50V BLK DD15470300
CL74 /N,/S 482212231205 CER. 47pF J CH 50V BLK DD15470300
CL74 /S 482212231205 CER. 47pF J CH 50V BLK DD15470300
CL75 532212421731 ELECT. 10µF M 50V RA-2 OA10605020
CL75 8000 532212421731 ELECT. 10µF M 50V RA-2 OA10605020
CL76 532212421731 ELECT. 10µF M 50V RA-2 OA10605020
CL76 8000 532212421731 ELECT. 10µF M 50V RA-2 OA10605020
CL77 482212230043 CER. 0.01µF Z 50V DK18103310
CL77 8000 482212230043 CER. 0.01µF Z 50V DK18103310
CL78 482212230043 CER. 0.01µF Z 50V DK18103310
CL78 8000 482212230043 CER. 0.01µF Z 50V DK18103310
CL81 482212490354 ELECT. 100µF M 16V RA-2 OA10701620
CL81 8000 482212490354 ELECT. 100µF M 16V RA-2 OA10701620
CL82 482212490354 ELECT. 100µF M 16V RA-2 OA10701620
CL91 532212421731 ELECT. 10µF M 50V RA-2 OA10605020
CL92 532212421731 ELECT. 10µF M 50V RA-2 OA10605020
CL93
JUMPER 75060501P0
CL96
PL74-CAPACITORS (COMMON)
HIGH DIELECTRIC CONSTANT
CER. CAPACITOR ±10% 50V :
CL71-CL72[/N,/S]
PL74-RESISTORS
RL71 8000 1kΩ ±5% 1/6W GD05102160
RL91 482211141355 75Ω ±5% 1/6W GD05750160
RL92 482211141355 75Ω ±5% 1/6W GD05750160
RL93 482211141355 75Ω ±5% 1/6W GD05750160
RL94 JUMPER 75060501P0
RL95 JUMPER 75060501P0
RL96 JUMPER 75060501P0
PL74-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W :
RL71-RL74 RL79 RL80
PL74-SEMICONDUCTOR
QL71 482220983631 IC NJM4558D-D HC10008090
PL74-MISCELLANEOUS
JL71 996500001347 RCA JACK 3P + S-TERMINAL BY04040030
PM01-HDAM CIRCUIT BOARD
[SR8000 ONLY]
PM01-RESISTORS (COMMON)
8000 CARBON FILM FIXED RES.
±5% 1/6W : ALL
PM01-SEMICONDUCTORS
DM02
8000 482213032362 DIODE 1SS176 MA165 1SS254 HD20002000
DM05 30V 0.1A
QM01 8000 482213042839 TRS. 2SK369 BL
VGDS-40V PD0.4W
HF203690
QM02 8000 482213042839 TRS. 2SK369 BL
VGDS-40V PD0.4W
HF203690
QM03 8000 482213043233 TRS. 2SC2240 GR OR BL HT322402A0
QM04 8000 482213042949 TRS. 2SA970 GR OR BL HT109702A0
QM05 8000 482213042949 TRS. 2SA970 GR OR BL HT109702A0
QM06 8000 482213043233 TRS. 2SC2240 GR OR BL HT322402A0
PS04-AUDIO FUNCTION 1
CIRCUIT BOARD
PS04-CAPACITORS
CS01
532212421731 ELECT. 10µF M 50V RA-2 OA10605020
CS06
CS07 /K,/U 532212610794 CER. CHIP 220pF DK56221300
CS07 /N,/S 532212234099 CER. CHIP 470pF DK56471300
CS08 /K,/U 532212610794 CER. CHIP 220pF DK56221300
CS08 /N,/S 532212234099 CER. CHIP 470pF DK56471300
CS09 /K,/U 532212610794 CER. CHIP 220pF DK56221300
CS09 /N,/S 532212234099 CER. CHIP 470pF DK56471300
CS10 /K,/U 532212610794 CER. CHIP 220pF DK56221300
CS10 /N,/S 532212234099 CER. CHIP 470pF DK56471300
CS11 /K,/U 532212610794 CER. CHIP 220pF DK56221300
CS11 /N,/S 532212234099 CER. CHIP 470pF DK56471300
CS12 /K,/U 532212610794 CER. CHIP 220pF DK56221300
CS12 /N,/S 532212234099 CER. CHIP 470pF DK56471300
CS13 /K,/U 482212233204 CER. CHIP 15pF DD55150300
CS13 /N,/S 532212232452 CER. CHIP 47pF DD55470300
CS14 /K,/U 482212233204 CER. CHIP 15pF DD55150300
CS14 /N,/S 532212232452 CER. CHIP 47pF DD55470300
CS15 /K,/U 482212233204 CER. CHIP 15pF DD55150300
CS15 /N,/S 532212232452 CER. CHIP 47pF DD55470300
CS16 /K,/U 482212233204 CER. CHIP 15pF DD55150300
CS16 /N,/S 532212232452 CER. CHIP 47pF DD55470300
CS17 /K,/U 482212233204 CER. CHIP 15pF DD55150300
CS17 /N,/S 532212232452 CER. CHIP 47pF DD55470300
CS18 /K,/U 482212233204 CER. CHIP 15pF DD55150300
CS18 /N,/S 532212232452 CER. CHIP 47pF DD55470300
CS19
482212233127 CER. CHIP 2200pF DK56222300
CS22
CS23
532212234098 CER. CHIP 0.01µF DK56103300
CS28
CS29 482212240617 CER. 0.1µF +80%-20% 50V DC DD38104010
CS30 482212490354 ELECT. 100µF M 16V RA-2 OA10701620
CS31 482212490354 ELECT. 100µF M 16V RA-2 OA10701620
CS32 482212240617 CER. 0.1µF +80%-20% 50V DC DD38104010
CS33 482212240617 CER. 0.1µF +80%-20% 50V DC DD38104010
CS34 482212240617 CER. 0.1µF +80%-20% 50V DC DD38104010
CS51
482212480067 ELECT. 4.7µF M 50V RA-2 OA47505020
CS54
CS55 532212234098 CER. CHIP 0.01µF DK56103300
CS56 532212234098 CER. CHIP 0.01µF DK56103300
CS57 482212480067 ELECT. 4.7µF M 50V RA-2 OA47505020
CS58 482212480067 ELECT. 4.7µF M 50V RA-2 OA47505020
CS59 532212421731 ELECT. 10µF M 50V RA-2 OA10605020
