Marantz SR8002 User Manual

MULTICHANNEL SURROUND
THX Ultra II / Select II -/•
THX Surround EX •
DTS HD / DTS 5.1 / DTS ES / DTS
96/24
•/•/•/•
Dolby Digital Plus / Dolby
TrueHD / Dolby Digital EX / DPL
IIx
•/•/•/•
7.1 PCM 24bit/96kHz decoding for
BluRay and HD-DVD
•
Circle Surround II / Neural Surround •/•
Virtual Surround /
Multichannel Stereo
o(Dolby
VS)/•
HT-EQ / Re-EQ -/•
Dolby Headphone / TruSurround
Headphone
•/-
Compressed audio Enhancer (MP3,
WMA, ACC, iPod)
•
SOUND ENHANCEMENTS
Current Feedback Topology •
Pure Direct •
Power Transformer: Super
Ring/Toroidal/EI
-/•/-
High Grade Audio Components •
Chassis : (Die-cast / Copper plated /
Metal)
-/•/-
OTHERS
Auto speaker setup by
microphone
Audyssey
MultEQ
Front panel cursor control •
On Screen Display: main / multiroom •/•
Variable cross over 8
Lip sync control •
Video conversion (>
up, < down)
• (CVBS < > S < >
Comp >HDMI)
T.B.C. - time base correction •
Multiroom zones 2
Speaker A/B •
Bi-amp drive (5.1 ch setting) /
Speaker C
•/•
Tuner 1
Auto TV Switching (on/off) •
Discrete RC coding (Main- /
Multiroom)
•/•
RS232C (control / update) •/•
VIDEO
Composite In/Out 4/3
S-Video In/Out 4/3
Component In/Out 4/2
HDMI In/Out (version x.x) 4/2(V1.3)
HDMI V1.3 Deep ColorTM •
Multi-Room Video Out: CVBS /
S-Video / Component
•/-/•
AUDIO
Analogue In/Out 6/4
Digital Optical In/Out 3/1
Digital Coaxial In/Out 3/1
Digital audio by HDMI •
Multi-Room Audio Out 2
Pre Out / Main In (7.1ch) •/-
Multichannel in •
OTHER
Speaker Terminal: Gold plated screw /
regular screw (all)
-/•
Multi-Room Speaker Terminal •
Multi-Room D.Bus In/Out •
D.Bus In/Out •
IR Receiver In / Emitter Out 1/2
IR Flasher In 1
RS232C •
DC Triggers 2
Front Inputs: Audio / Composite /
S-Video / Digital (Opt)
•/•/•/•
I-Pod input (direct / docking station) -/•
SPECIFICATIONS
Power Output (8/4 Ohm RMS) 125/- W
Audio Signal to Noise Ratio 105 dB
FM Tuner 87.5 - 108.00 MHz
Component video frequency
response
5 to
80MHz
GENERAL
Available colors:
Platinum/Gold/Silver/Black
-/-/•/-
Metal Front Panel •
System Remote Control RC8001SR
Pre-programmed / Learnable /
Touch Screen
•/•/-
Multiroom remote (included /
optional)
RC101
(•/-)
Power Consumption 650W
Detachable Power Cable •
Maximum Dimensions (W x
D x H)
440x396x184
Weight 15.0kg
Design and specifications are subject
to change by Marantz without notice.
www.marantz.com

Marantz SR8002 Specifications

General

Channels	7.1
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Total Harmonic Distortion	0.08%
Input Sensitivity	200 mV
Signal-to-Noise Ratio	105 dB
HDMI Inputs	4
HDMI Outputs	2
Component Video Inputs	3
Component Video Outputs	1
Composite Video Inputs	5
Composite Video Outputs	2
Analog Audio Inputs	7
Phono Input	Yes
Multi-room Output	Yes
Headphone Output	Yes
AM/FM Tuner	Yes
Internet Radio	No
Network Audio Streaming	No
Bluetooth	No
Wi-Fi	No
Ethernet	No
USB Port	No
Audyssey MultEQ	Yes
Audyssey Dynamic Volume	No
Audyssey Dynamic EQ	Yes
Power Output	125 watts per channel (8 ohms, 20 Hz - 20 kHz, THD 0.08%)
Digital Audio Inputs	4 (2 Coaxial, 2 Optical)
Digital Audio Outputs	2 (1 Coaxial, 1 Optical)
Dolby Technologies	Dolby Digital, Dolby Pro Logic IIx
DTS Technologies	DTS, DTS-ES, DTS Neo:6
