10
Remark : Bass signal output from Sub Woofer terminal for SR9200 / SR8200 / PS9200.
Sub woofer output is not active while all surround modes. Please refer to the following table.
SPK setup
ZR38601
SubWoofer Output by Surround mode
Sub Surr. Surr.B Bass CFG AUTO (PCM,Ana)
Woofer Front Center L/R (L/R) # DTS ES
THX Surr EX,
Stereo AUTO(AC-3,DTS) (AC-3:2ch,karaoke)
ON Large Large Large Large 1 LFE LFE none L+R LFE L+R
Small 14 LFE+Sb LFE
Small Large 3 LFE+SL+SR LFE+SL+SR none L+R LFE+SL+SR L+R
Small 16 LFE+SL+SR+Sb LFE+SL+SR
None (prohibit) 1 LFE LFE none L+R LFE L+R
Small Large Large 5 LFE+C LFE+C C L+R LFE+C L+R
Small 18 LFE+C+Sb LFE+C
Small Large 8 LFE+C+SL+SR LFE+C+SL+SR C L+R LFE+C+SL+SR L+R
Small 21 LFE+C+SL+SR+Sb LFE+C+SL+SR
None (prohibit) 5 LFE+C LFE+C C L+R LFE+C L+R
None Large Large 1 LFE LFE none L+R LFE L+R
Small 14 LFE+Sb LFE
Small Large 3 LFE+SL+SR LFE+SL+SR none L+R LFE+SL+SR L+R
Small 16 LFE+SL+SR+Sb LFE+SL+SR
None (prohibit) 1 LFE LFE none L+R LFE L+R
Small Large Large Large 12 LFE+L+R LFE+L+R L+R L+R LFE+L+R L+R
Small 25 LFE+L+R+Sb LFE+L+R
Small Large 11 LFE+L+R+SL+SR LFE+L+R+SL+SR L+R L+R LFE+L+R+SL+SR L+R
Small 24 LFE+L+R+SL+SR+Sb LFE+L+R+SL+SR
None (prohibit) 12 LFE+L+R LFE+L+R L+R L+R LFE+L+R L+R
Small Large Large 10 LFE+L+R+C LFE+L+R+C L+R+C L+R LFE+L+R+C L+R
Small 23 LFE+L+R+C+Sb
Small Large 0 LFE+L+R+C+SL+SR
LFE+L+R+C+SL+SR L+R+C L+R LFE+L+R+C+SL+SR L+R
Small 13
LFE+L+R+C+SL+SR+Sb
None (prohibit) 10 LFE+L+R+C LFE+L+R+C L+R+C L+R LFE+L+R+C L+R
None Large Large 12 LFE+L+R LFE+L+R L+R L+R LFE+L+R L+R
Small 25 LFE+L+R+Sb
Small Large 11 LFE+SL+SR LFE+SL+SR L+R L+R LFE+SL+SR L+R
Small 24 LFE+SL+SR+Sb
None (prohibit) 12 LFE+L+R LFE+L+R L+R L+R LFE+L+R L+R
OFF No output to subW
THX5.1, Dolby-D,
DTS
PL2, CS,
Neo6
