121
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR9200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
CE69 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
CE70 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
CE71 9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CE73 4822 121 10792 FILM,APSV 221J,
220pF(TP) 100V PP
OF15221540
CE74 4822 121 10792 FILM,APSV 221J,
220pF(TP) 100V PP
OF15221540
CE75 9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CE91 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
CE92 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CE93 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
CE94 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CG01 4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CG02 4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CG03 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CG04 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CG05 9965 000 01344 FILM,100pF ±5% 100V APSV OF15101540
CG06 9965 000 01344 FILM,100pF ±5% 100V APSV OF15101540
CG07 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CG08 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CG09 4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CG10 4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CG11 9965 000 02015 ELECT.22µF ±20% 25V ARS OA22602540
CG12 9965 000 02015 ELECT.22µF ±20% 25V ARS OA22602540
CG13 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CG14 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CG15 9965 000 01344 FILM,100pF ±5% 100V APSV OF15101540
CG16 9965 000 01344 FILM,100pF ±5% 100V APSV OF15101540
CG17 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CG18 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CG19 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
CG20 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
CG21 9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CG22 9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CG23 4822 121 10792 FILM,APSV 221J,
220pF(TP) 100V PP
OF15221540
CG24 4822 121 10792 FILM,APSV 221J,
220pF(TP) 100V PP
OF15221540
CG25 9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CG26 9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CG41 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
CG42 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CG43 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
CG44 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CG51 4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CG52 4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CG53 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CG54 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CG55 9965 000 01344 FILM,100pF ±5% 100V APSV OF15101540
CG56 9965 000 01344 FILM,100pF ±5% 100V APSV OF15101540
CG57 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CG58 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CG59 4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CG60 4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CG61 9965 000 02015 ELECT.22µF ±20% 25V ARS OA22602540
CG62 9965 000 02015 ELECT.22µF ±20% 25V ARS OA22602540
CG63 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CG64 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CG65 9965 000 01344 FILM,100pF ±5% 100V APSV OF15101540
CG66 9965 000 01344 FILM,100pF ±5% 100V APSV OF15101540
CG67 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CG68 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CG69 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
CG70 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
CG71 9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CG72 9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CG73 4822 121 10792 FILM,APSV 221J,
220pF(TP) 100V PP
OF15221540
CG74 4822 121 10792 FILM,APSV 221J,
220pF(TP) 100V PP
OF15221540
CG75 9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CG76 9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CG91 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
CG92 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CG93 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
CG94 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CM01 4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CM02 4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CM03 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CM04 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CM07 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CM08 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CM09
4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CM12
CM13 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CM14 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CM17 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CM18 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CM19 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
CM20 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
CM23 4822 121 10792 FILM,APSV 221J,
220pF(TP) 100V PP
OF15221540
CM24 4822 121 10792 FILM,APSV 221J,
220pF(TP) 100V PP
OF15221540
CM31 4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CM32 4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CM33 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CM34 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CM37 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CM38 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CM39 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
CM40 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
CM61 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
CM62 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CM63 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
CM64 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
PG04-CAPACITORS(COMMON)
HIGH DIELECTRIC CONSTANT
CER.CAPACITOR ±10% 50V :
CE40 CE45-CE48 CE56 CE66
CE72 CE90 CG40 CG90 CM05
CM06 CM15 CM16 CM21 CM22
CM35 CM36 CM41 CM42 CM60
PG04- RESISTORS
RE01 4822 111 90919 CHIP,47k
Ω ±5% 1/10W NI05473110
RE02 4822 111 90919 CHIP,47k
Ω ±5% 1/10W NI05473110
