NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR9200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
C902 /N/S 4822 122 30043 CER.0.01µF Z 50V DK18103310
C903 /N 5322 124 21731 ELECT.10µF ±20% 50V RA-2 OA10605020
C903 /S ELECT.10µF ±20% 50V RA-2 OA10605020
C907
/N/S 4822 126 10364 CER.100pF UP050B101K-A DA16101110
C910
C912 /N 5322 124 21731 ELECT.10µF ±20% 50V RA-2 OA10605020
C912 /S ELECT.10µF ±20% 50V RA-2 OA10605020
C913 /N/S 4822 122 40586 CER.10000pF DA17103110
C914 /N/S 5322 122 32143 CER.22pF ±5% CH 50V BLK DD15220300
C915 /N/S 4822 122 30045 CER.27pF ±5% CH 50V BLK DD15270300
C951 /N 4822 124 80067 ELECT.4.7µF ±20% 50V RA-2 OA47505020
C951 /S ELECT.4.7µF ±20% 50V RA-2 OA47505020
C952 /N 4822 124 80067 ELECT.4.7µF ±20% 50V RA-2 OA47505020
C952 /S ELECT.4.7µF ±20% 50V RA-2 OA47505020
C955 /N 4822 124 80067 ELECT.4.7µF ±20% 50V RA-2 OA47505020
C955 /S ELECT.4.7µF ±20% 50V RA-2 OA47505020
C956 /N 4822 124 80067 ELECT.4.7µF ±20% 50V RA-2 OA47505020
C956 /S ELECT.4.7µF ±20% 50V RA-2 OA47505020
C957 /N 4822 124 80067 ELECT.4.7µF ±20% 50V RA-2 OA47505020
C957 /S/U ELECT.4.7µF ±20% 50V RA-2 OA47505020
C958 /N 4822 124 80067 ELECT.4.7µF ±20% 50V RA-2 OA47505020
C958 /S/U ELECT.4.7µF ±20% 50V RA-2 OA47505020
C959 /N/S 4822 122 30043 CER.0.01µF Z 50V DK18103310
C960 /N/S 4822 122 30043 CER.0.01µF Z 50V DK18103310
CM81
4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CM85
CT01 4822 126 10364 CER.100pF UP050B101K-A DA16101110
CT04 4822 126 10364 CER.100pF UP050B101K-A DA16101110
CT05 4822 126 10364 CER.100pF UP050B101K-A DA16101110
CT06 4822 126 10364 CER.100pF UP050B101K-A DA16101110
CT07 4822 122 30043 CER.0.01µF Z 50V DK18103310
CT08 4822 122 30043 CER.0.01µF Z 50V DK18103310
CT09 4822 124 90354 ELECT.100µF ±20% 16V RA-2 OA10701620
CW01 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CW02 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CW03 /N/S 4822 122 31205 CER.47pF ±5% CH 50V BLK DD15470300
CW04 /N/S 4822 122 31205 CER.47pF ±5% CH 50V BLK DD15470300
CW05 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CW06 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CW07 4822 122 30043 CER.0.01µF Z 50V DK18103310
CW08 4822 122 30043 CER.0.01µF Z 50V DK18103310
CW31 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CW32 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CW35 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CW36 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CW37 4822 122 30043 CER.0.01µF Z 50V DK18103310
CW38 4822 122 30043 CER.0.01µF Z 50V DK18103310
CY01 4822 122 30043 CER.0.01µF Z 50V DK18103310
PY04-CAPACITORS(COMMON)
HIGH DIELECTRIC CONSTANT
CER.CAPACITOR ±10% 50V :
C904-C906[/N/S] C953[/N/S]
C954[/N/S] CM83 CM86 CT02
CT03
PY04- RESISTORS
R851 4822 050 21501 150
Ω ±5% 1/4W GG05151140
R852 4822 116 82805 1
Ω ±5% 1/6W GG05010160
PY04- RESISTORS(COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : R901-R904[/N/S]
R951-R958[/N/S] R959-R962
RM81 RM83-RM85 RT01 RT02
RW01-RW04 RW31-RW34
PY04- SEMICONDUCTORS
D851
4822 130 82421 DIODE,1D3 1A/200V HD20002710
D858
D859 4822 130 81247 DIODE,1GWJ43 HD20031050
D860 4822 130 82421 DIODE,1D3 1A/200V HD20002710
D861 4822 130 33057 DIODE,S2VB20 HE20011290
D862 4822 130 82421 DIODE,1D3 1A/200V HD20002710
D863 4822 130 82421 DIODE,1D3 1A/200V HD20002710
D864 4822 130 82421 DIODE,1D3 1A/200V HD20002710
D865 4822 130 81157 ZENER,MTZJ3.0B HD30301000
D866 4822 130 82421 DIODE,1D3 1A/200V HD20002710
D867 4822 130 82421 DIODE,1D3 1A/200V HD20002710
D868 4822 130 82421 DIODE,1D3 1A/200V HD20002710
DM81
4822 130 32362 DIODE,1SS176,MA165,1SS254
30V 0.1A
HD20002000
DM93
DT01 4822 130 82421 DIODE,1D3 1A/200V HD20002710
Q851 4822 209 83317 IC,NJM7815FA +15V 1A HC38915090
Q852 4822 209 31864 IC,NJM7915FA HC39915090
Q853 4822 209 31631 IC,NJM7805FA +5V HC38905090
Q854 4822 209 63179 IC,NJM7905FA HC39905090
Q855 4822 209 31631 IC,NJM7805FA +5V HC38905090
Q856 3141 018 50260 IC,BA033T +3.3V 1A TYPE HC36J33210
Q857 4822 130 63635 TRS.2SC4793 O,Y HT347932A0
Q858 4822 130 63635 TRS.2SC4793 O,Y HT347932A0
Q901 /N/S 9965 000 06293 IC,LC72722 RDS DECODER HC10404030
Q902 /N/S 4822 130 41947 TRS.C2458,C1740S,C3199,ETC HT30001000
Q903 /N/S 4822 130 60588 DIG.TRS.DTC114ES/UN4211
10K,10K
BA20001000
Q904 /N/S 4822 130 61227 DIG.TRS.DTA114ES/UN4111
10K,10K
BA10001000
Q951 /N/S 4822 209 83631 IC,NJM4558D-D HC10008090
QM81 5322 209 11532 IC,74HC4094 16PIN DIP HC709449B0
QM82 5322 209 11532 IC,74HC4094 16PIN DIP HC709449B0
QM83
4822 130 61227 DIG.TRS.DTA114ES/UN4111
10K,10K
BA10001000
QM88
QM89 4822 130 60588 DIG.TRS.DTC114ES/UN4211
10K,10K
BA20001000
QM90 4822 130 61227 DIG.TRS.DTA114ES/UN4111
10K,10K
BA10001000
QT02 4822 130 60588 DIG.TRS.DTC114ES/UN4211
10K,10K
BA20001000
QT03 /N 4822 209 70084 IC,NJM7812FA +12V HC38912090
QT03 /S/U IC,NJM7812FA +12V HC38912090
QT04 4822 130 61227 DIG.TRS.DTA114ES/UN4111
10K,10K
BA10001000
QW01 4822 209 73064 IC,NJM-2068-DD HC10053090
QW31 4822 209 83631 IC,NJM4558D-D HC10008090
QY01 9965 000 12340 IC,TC74HC368AP HC736805B0
PY04- MISCELLANEOUS
F851 /N/S 4822 071 52002 FUSE,T2.0A 250V TR5 FS20200200
F851 /U FUSE,T2A 250V TR5 NO.19374 FS20200210
F852 /N/S 4822 071 52002 FUSE,T2.0A 250V TR5 FS20200200
F852 /U FUSE,T2A 250V TR5 NO.19374 FS20200210
F853 /N/S 4822 071 52002 FUSE,T2.0A 250V TR5 FS20200200
