i DISPLAY BUTTON
When this button is pressed while a station name is being displayed,
the display is switched to the frequency display.
Pressing the button again returns to the station name display; if no
station name has been stored for the station being received. “NO
NAME” is displayed when the button is pressed.
o ST-NAME BUTTON
Press before manual input of station name.
For details, refer to “NANUAL INPUT OF STATION NAMES”.
!0 PRESET BUTTON
For switching the GYRO CONTROL ring to the preset mode.
!1 TUNING BUTTON
For switching the GYRO CONTROL ring to the tuning mode.
!2 AUTO BUTTON
For switching the GYRO CONTROL ring to the auto tuning mode.
!3 GYRO CONTROL RING
Used for dialing control of tuning up/down, preset up/down, station
name character display and PTY selection.
!4 DISPLAY
å MEMORY – This indicator lights up for about 5 seconds after the
MEMO button has been pressed.
∫ PRESET – This indicator lights up when the PRESET button is
pressed.
ç STEREO – This indicator lights up when an FM stereo broadcast
is being received.
∂ AUTO TUNING – This indicator lights up when the AUTO TUNING
mode.
é TUNING – This indicator lights up when the MANUAL TUNING
mode.
ƒ TUNED – This indicator lights up when a station is tuned.
© FREQUENCY/STATION NAME – This indicator shows frequencies
in MHz (FM) or kHz (MW, LW), (RDS) station name, radio text or
names you have assigned.
˙ MONO – This indicator lights up in the MONO mode, which is
initiated when the MONO button is pressed.
G AC POWER CONNECTION
The correct voltage for operating your tuner is indicated on the rear
panel. Be sure the POWER switch is off before plugging the AC
mains lead into an electrical outlet.
H SCAN-STEP SELECTION
Changes the step when the tuner searches for the next station up or
down the scale. In Europe this swich should be set to 9 kHz steps in
AM.
CAUTION
THE UNIT MUST BE TURNED OFF BEFORE CHANGING
THE SCAN-STEP SELECTOR SWITCH POSITION.
WHEN THIS SWITCH IS SET TO OFF, THE CONTENTS OF
THE PRESET MEMORY AND STATION NAME ARE
ERASED AT THAT TIME, STORE THE CONTENTS AGAIN.
I FM DE-EMPHASIS SWITCH
This models are equipped with switchable de-emphasis.
The de-emphasis switch works in conjuction with this scan-step
selector switch.
The de-emphasis set to 50˚s when delivered from the factory.
EQUIPMENT FRONT PANEL
CONNECTIONS AND CONTROLS
(Figure 2)
q POWER SWITCH
Press to switch the power ON. Press again to switch to power OFF.
The mains switch is secondary connected and does not disconnect
the entire set from the mains.
w ANTENNA BUTTON
This button is only operable when the FM band is selected.
This button selects FM ANTENNA A and FM ANTENNA B.
The selected side’s LED will light.
e IF BAND BUTTON
This button is only operable when the FM band is selected.
This button selects the IF band’s WIDE or NARROW setting.
The selected side’s LED will light.
WIDE: High quality audio can be listened to.
NARROW: Ability to select neighboring stations is improved.
r IR SENSOR
Receives the infrared remote control signal.
t MONO BUTTON
Press to switch the receiving mode between the auto stereo mode
and more mode.
When the button is pressed into the in position, the receiving mode
becomes the mono mode.
When the button is pressed again, the receiving mode becomes the
auto stereo mode.
y BAND BUTTON
Use this button to select FM or AM (MW/LW) wave bands.
u MEMO BUTTON
Press to preset a receiving frequency in the memory. The MEMORY
indicator lights up for about 5 seconds when this button is pressed. It
is only during this period that a frequency can be preset in the
memory.
