113
UD9004
8U-310002AZ VIDEO PWB UNIT ASSY
Ref. No.
Part No.
(for EUR)
Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC102 nsp nsp
PCA9539PW,188 *
IC104-106 nsp nsp
EN5322QI-T
IC108 nsp nsp EPM570F256C5N
IC202 nsp nsp TC7W241FU(TE12L)
IC203 nsp nsp sxT2LF-400(Realta)
IC204-209 nsp nsp K4D261638K-LC40
IC210 nsp nsp LP2995M
IC211,212 nsp nsp K4D261638K-LC40
IC213 nsp nsp IP ROM SUB ASSY
(S29GL064N90TFI040#)
*
IC214 nsp nsp
EN5336QI-T *
IC215 nsp nsp
EN5366QI-T *
IC501 nsp nsp
EPM570F256C5N
IC502 nsp nsp SII9134CTU
IC503 nsp nsp BD7820FP-E2
IC504 nsp nsp SII9134CTU
IC601 nsp nsp ABT2010 *
IC701 nsp nsp
EN5322QI-T *
IC702 nsp nsp
LP2996MX
IC703,704 nsp nsp K4T51163QG-HCE7 *
IC802 nsp nsp
ADV7344BSTZ *
IC803-805 nsp nsp
BD7820FP-E2
IC806 nsp nsp ABT1012 *
IC808 nsp nsp
ADV7340BSTZ
IC901 nsp nsp NJM2566AV
TR103-106 nsp nsp KRC104S-RTK/P (47K-47K)
TR202,203 nsp nsp KRC104S-RTK/P (47K-47K)
TR503 nsp nsp KTC3875S-GR-RTK/P
TR701 nsp nsp KRC104S-RTK/P (47K-47K)
TR802-804 nsp nsp 2SA1022-B +C
TR806,807 nsp nsp 2SA1022-B +C
TR821,822 nsp nsp KRC104S-RTK/P (47K-47K)
D101-103 nsp nsp RB521S-30TE61 +REF
D201,202 nsp nsp RB521S-30TE61 +REF
D501-503 nsp nsp KDS160-RTK/P
D504-508 nsp nsp ESD PROTECTOR(6802)
D509-516 nsp nsp AVRL161A1R1NTB
D517-521 nsp nsp ESD PROTECTOR(6802)
D522-529 nsp nsp AVRL161A1R1NTB
D701 nsp nsp RB521S-30TE61 +REF
D801-803 nsp nsp KDS160-RTK/P
ZD501,502 nsp nsp UDZS5.1B-TE17 +C
RESISTORS GROUP
R356,357 nsp nsp
RM73B--103FT +1608
R359,360 nsp nsp RM73B--103FT +1608
R725,726 nsp nsp RM73B--102FT +1608
R732,733 nsp nsp RM73B--102FT +1608
NOTE :
When update Firmware, please
confirm a last version in SDI.
Use the service board after
updating it.
