Marantz UD9004/U1B - Parts List of P.w.b. Unit

82
UD9004
PARTS LIST OF P.W.B. UNIT
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
U : North America model N : Europe model S : Singapore model R : Russia model
8U-37AK51000 AUDIO PWB UNIT ASSY
Ref. No.
Part No.
(for EUR)
Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
D801-804 00MHD20003710 00MHD20003710
! SCHOTTKY 1S100 1A 100V RECTRON
D805-808 00D2760401905 00D2760401905 1SS133T77 (TAPE)
D811,812 00MHD30021010 00MHD30021010 ZENER HZ6A3L(HITACHI)
DA01-04 00D2760401905 00D2760401905 1SS133T77 (TAPE)
DA05-12 00D2760401905 00D2760401905 1SS133T77 (TAPE)
DA13-16 00D2760401905 00D2760401905 1SS133T77 (TAPE)
DA17-19 00MHZ21005000 00MHZ21005000 1SS301 DAN202U UMT TYPE
DE01-04 00MHD20003710 00MHD20003710 ! SCHOTTKY 1S100 1A 100V RECTRON
DE05-06 00MHD20002710 00MHD20002710 1D3 1A/200V
DE07,15 00D2760401905 00D2760401905 1SS133T77 (TAPE)
DE08,09 00MHD20002710 00MHD20002710 1D3 1A/200V
DE13,14 00MHD20002710 00MHD20002710 1D3 1A/200V
DG01-08 00MHZ20018050 00MHZ20018050 1SS302 (TE85L F) (TOSHIBA)
DG09 00MHZ21005000 00MHZ21005000 1SS301 DAN202U UMT TYPE
DG11,12 00MHZ21005000 00MHZ21005000 1SS301 DAN202U UMT TYPE
DJ01 00MHZ20018050 00MHZ20018050 1SS302 (TE85L F) (TOSHIBA)
DJ03 00MHZ20018050 00MHZ20018050 1SS302 (TE85L F) (TOSHIBA)
DJ05 00MHZ20018050 00MHZ20018050 1SS302 (TE85L F) (TOSHIBA)
DJ07 00MHZ20018050 00MHZ20018050 1SS302 (TE85L F) (TOSHIBA)
DK01 00MHZ20018050 00MHZ20018050 1SS302 (TE85L F) (TOSHIBA)
DK03 00MHZ20018050 00MHZ20018050 1SS302 (TE85L F) (TOSHIBA)
DK05 00MHZ20018050 00MHZ20018050 1SS302 (TE85L F) (TOSHIBA)
DK07 00MHZ20018050 00MHZ20018050 1SS302 (TE85L F) (TOSHIBA)
DL02 00MHZ20018050 00MHZ20018050 1SS302 (TE85L F) (TOSHIBA)
DL04 00MHZ20018050 00MHZ20018050 1SS302 (TE85L F) (TOSHIBA)
DL06 00MHZ20018050 00MHZ20018050 1SS302 (TE85L F) (TOSHIBA)
DL08 00MHZ20018050 00MHZ20018050 1SS302 (TE85L F) (TOSHIBA)
DM01 00MHZ20018050 00MHZ20018050 1SS302 (TE85L F) (TOSHIBA)
DM03 00MHZ20018050 00MHZ20018050 1SS302 (TE85L F) (TOSHIBA)
DM05 00MHZ20018050 00MHZ20018050 1SS302 (TE85L F) (TOSHIBA)
DM07 00MHZ20018050 00MHZ20018050 1SS302 (TE85L F) (TOSHIBA)
DW02 00MHZ20018050 00MHZ20018050 1SS302 (TE85L F) (TOSHIBA)
DW04 00MHZ20018050 00MHZ20018050 1SS302 (TE85L F) (TOSHIBA)
DW06 00MHZ20018050 00MHZ20018050 1SS302 (TE85L F) (TOSHIBA)
DW08 00MHZ20018050 00MHZ20018050 1SS302 (TE85L F) (TOSHIBA)
DW12 00MHZ21005000 00MHZ21005000 1SS301 DAN202U UMT TYPE
DX09 00MHZ21005000 00MHZ21005000 1SS301 DAN202U UMT TYPE
DX11 00MHZ21005000 00MHZ21005000 1SS301 DAN202U UMT TYPE
DX12 00MHZ21005000 00MHZ21005000 1SS301 DAN202U UMT TYPE
