UD9004
PARTS LIST OF EXPLODED VIEW
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊
P.W.B. ASS'Y for which "nsp" is indicated on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts table and order replacement parts .
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Ref. No. Part No. Part Name Remarks Qty New
1A nsp FE/SACD UNIT
1 nsp MECHA BASE ASS'Y 1
2 8S3111000200M TRAY SUB ASSY UD9004 37AK 1 *
-TRAY 1
- TRAY BRACKET 1
-
3 × 5CBS-B
5
- TRAY CUSHION 1
3 nsp TRAVERSE FRAME 1
4 00D9KA2A761 1
-HOUSING 1
- BELT HOLDER 1
- SHUTTER 1
-
2 × 4CBS-B
1
-
2 × 6CFS-B
1
- BELT GUIDE 1
-
2 × 6CBTS(P)-Z
1
5 463510006106D TB CAM GEAR 1
6 00D4240280505 SLIDE CAM 1
7 00D9KA2G974 DOUBLE PULLY 1
9 00D4210845006 ROLLER 2
11 463510007000D TB WORM WHEEL 1
12 nsp TRAY HOLDER L 1
13 nsp TRAY HOLDER R 1
14 00D9KA2G969 BELT GEAR FRONT 1
15 00D9KA2G970 BELT GEAR REAR 1
16 00D9KA2G968 BELT FIRST 1
17 00D9KA2G971 BELT SECOND 1
18 466010001006D TIMING BELT CAM 1
19 8S4031001100M TOP PLATE SUB ASSY UD9004 37AK 1 *
-TOP PLATE 1
- CLAMPER MAGNET 2
- BACK YOKE 1
- CLAMPER BASE 1
-
3 × 5CBS-B
8
-SUB TOP 1
- DAMPER RING 8
20 nsp MOTOR BRACKET ASS'Y 1
22 nsp CAM HOLDER 1
24 nsp SW BRACKET 1
25 nsp REAR BRACKET ASS'Y 1
26 00D4630973105 CAM SPRING 1
27 nsp SWITCH SHEET 1
28 00D4630975006 SHAFT SPRING 6
30 00D4751179011 WASHER 1
32 nsp SLIDE SHAFT 1
33 nsp BD TRAVERSE UNIT 1
34 00D9KA2A762 LOADING MOTOR ASSY 1
-MOTOR PULLY 1
- LOADINGMOTOR BRACKET 1
- LOADING MOTOR 1
-
2.6 × 3CBS-B
2
