PARTS LIST OF EXPLODED VIEW
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊
P.W.B. ASS'Y for which "nsp" is indicated on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts table and order replacement parts .
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
＊Part indicated with the mark " ★ " is not illustrated in the exploded view.
Note: The symbols in the column "Remarks" indicate the following destinations.
U : North America model N : Europe model S : Singapore model R : Russia model
Ref. No. Part No. Part Name Remarks Q'ty New
A nsp AUDIO PWB ASSY 1 *
z A-1 - AUDIO FRONT L/R PWB *
A-2 - AUDIO XLR PWB *
A-3 - AUDIO SUR_BACK/S_W PWB *
B nsp FRONT/AUDIO PWB ASSY 1 *
B-1 - FRONT PWB *
B-2 - SD CARD PWB *
B-3 - KEY PWB *
B-4 - STANDBY KEY LED PWB *
B-5 - AUDIO SUR/CENTER PWB *
B-6 - CONNECTOR PWB *
C nsp POWER PWB ASSY (8U-210048AZ) 1 *
z C-1 - POWR PWB ASSY *
C-2 - RS232C/REMOTE PWB ASSY *
D 8U-310002AZ VIDEO UNIT 1
E 8U-37AK550002 MAIN PWB ASSY for U 1 *
E 8U-37AK550003 MAIN PWB ASSY for N 1 *
E 8
U-37AK550004 MAIN PWB ASSY for S 1 *
E 8U-37AK550005 MAIN PWB ASSY f
or R 1 *
F 8M3041000100M BD MECHA UNIT FOR MARANTZ 1 *
F-1 - BD LORDING UNIT FOR MARANTZ *
F-2 - FE/SACD UNIT0
★ F-3
- FE REG PWB UNIT0
1 402410073003M FRONT AL PANEL BL UD9004 37AK 1 *
2 421410006004M
MARANTZ BADGE (AL) FOR M1 MODEL 1
3 421410011006M BADGE BD UD9004 37AK 1 *
4 441510036107M
FRONT MOLD CHASSIS BL UD9004 37AK 1 *
5 416510029004M WINDOW UD9004 37AK 1 *
6 nsp BUFFER DOOR UD9004 37AK 2 *
7 422510030009M
ESCUTCHEON INNER DOOR UD9004 37AK 1 *
8 00M271K305010 MAGNET 1
9 411510089001M
BUTTON AL CAP TRAY SIDE BL UD9004 37AK 4 *
10 411510087005M
BUTTON TRAY UNDER BL UD9004 37AK 2 *
11 411510088008M
BUTTON DOOR INNER BL UD9004 37AK 1 *
12 415410013007M DOOR AL PANEL BL UD9004 37AK 1 *
13 417510011105M HINGE DOOR L BL UD9004 37AK 1 *
14 417510012108M HINGE DOOR R BL UD9004 37AK 1 *
15 nsp
BRACKET DOOR MAGNET UD9004 37AK 1 *
16 nsp SHAFT DOOR UD9004 37AK 2 *
17 nsp
BRACKET DUMPER UD9004 37AK 1 *
18 474510007017M DAMPER NIFCO 001P E 3.9MN_M 1 *
19 404510023102M
SIDE ESCUTCHEON L BL UD9004 37AK 1 *
20 411510021005M BUTTON BL 1
21 481510003006M LENS 1
22 404510024105M
SIDE ESCUTCHEON R BL UD9004 37AK 1 *
23 nsp BUFFER 2
24 403310027004M
TOP COVER CENTER BL UD9004 37AK 1 *
s
s
s
s
