26
UD9004
Table 2: Error rate details
33 T57B BUF_ID_SVO_CRAM1 0x000000~0x0001FF CRAM1
34 T57C BUF_ID_SVO_CRAM2 0x000000~0x0001FF CRAM2
35 T57D BUF_ID_SVO_CRAM3 0x000000~0x0001FF CRAM3
36 T58A BUF_ID_SVO_ZRAM0 0x000000~0x0001FF ZRAM0
37 T58B BUF_ID_SVO_ZRAM1 0x000000~0x0001FF ZRAM1
38 T58C BUF_ID_SVO_ZRAM2 0x000000~0x0001FF ZRAM2
39 T58D BUF_ID_SVO_ZRAM3 0x000000~0x0001FF ZRAM3
40 T59 BUF_ID_EPRM 0x000000~0x000FFF EEPROM
41 T60 BUF_ID_PUCONT_LDD 0x000000~0x000007 LDD
42 T61 BUF_ID_SVRESULT 0x000000~0x0002C3 SvResult
43 T62 BUF_ID_LD_TIME 0x000000~0x00000D LD ON Time Integrated value
44 T63 BUF_ID_IOP 0x000000~0x000007 IOP(Stored value)
YY
Measurement
position
Error rate display details for each media type
BD DVD CD
Remarks
71 The inner
circumference of
1-layer
BIS error detection
signed number
It is invalid. It is invalid. When this is selected for DVD or CD,
it shifts to YY=73.
72 The inner
circumference of
1-layer
BIS error uncorrectable
signed numbe
It is invalid. It is invalid. When this is selected for DVD or CD,
it shifts to YY=73.
73 The inner
circumference of
1-layer
LDC error detection
signed number
PI error detection
number
C1 error
detection number
74 The inner
circumference of
1-layer
LDC error uncorrectable
signed numbe
PO uncorrectable
error number
C2 uncorrectable
error number
75 The central
circumference of
1-layer
BIS error detection
signed number
It is invalid. It is invalid. When this is selected for DVD or CD,
it shifts to YY=77.
76 The central
circumference of
1-layer
BIS error uncorrectable
signed numbe
It is invalid. It is invalid. When this is selected for DVD or CD,
it shifts to YY=77.
77 The central
circumference of
1-layer
LDC error detection
signed number
PI error detection
number
C1 error
detection number
78 The central
circumference of
1-layer
LDC error uncorrectable
signed numbe
PO uncorrectable
error number
C2 uncorrectable
error number
79 The outer
circumference of
1-layer
BIS error detection
signed number
It is invalid. It is invalid. When this is selected for DVD or CD,
it shifts to YY=81.
80 The outer
circumference of
1-layer
BIS error uncorrectable
signed numbe
It is invalid. It is invalid. When this is selected for DVD or CD,
it shifts to YY=81.
81 The outer
circumference of
1-layer
LDC error detection
signed number
PI error detection
number
C1 error
detection number
82 The outer
circumference of
1-layer
LDC error uncorrectable
signed numbe
PO uncorrectable
error number
C2 uncorrectable
error number
83 The inner
circumference of
2-layer
BIS error detection
signed number
It is invalid. It is invalid. When this is selected for 2-layer DVD, it
shifts to YY=85.
When this is selected for 1-layer DVD or
CD, it shifts to YY=73.
84 The inner
circumference of
2-layer
BIS error uncorrectable
signed number
It is invalid. It is invalid. When this is selected for DVD 2-layer, it
shifts to YY=85.
When this is selected for DVD 1-layer or
CD, it shifts to YY=73.
No. XXX Name Address range Meaning
