INSTALLING INSTRUCTION
Fix the rear camera on the rear
window.
Rear Camera
Each DVR model have different design. Below guide is just reference.
Connect the rear camera cable into
the rear camera.
(some cameras have already cable
fixed)
Adjust camera angle with angle adjustor.
Connect the rear camera cable
into the main unit.
R-cam the cable into window
aperture to make it invisible.
Check the rear cam view after
starting engine.
