5B-4 - MID-SECTION 90-824052R3 JUNE 2002

Power Trim Motor

REF

TORQUE

REF

NO.

QTY. DESCRIPTION lb.in. lb.ft. N·m

– 1 POWER TRIM MOTOR

1 1 BRUSH AND SEAL KIT

2 1 ARMATURE KIT

3 1 END FRAME (Complete)
