Nº326S Preamplifier Phono Modules Installation Instructions & Release Notes
The table below indicates all Set Inputs menu parameters available
for the phono input.
Default Possible
Parameter Setting Settings
Name PHONO PHONO, PH/MC, unused
Gain* +12dB +0dB, +6dB, +12dB, +18dB
Offset* 0.0dB –20.0 to +20.0dB
Bal 0.0 0.0 to 6.0 (left or right)
Rec.Out* NONE NONE, #1, #2, BOTH
* These parameters continue to function as described in the Nº326S Owner’s Manual.
Name Determines the name of the phono input connector (7). The
PHONO, PH/MC, unused factory-default input name is PHONO. Two methods are available
for customizing input names: the custom names list and the
character list.
Custom Names List When the phono modules are not installed, the phono input
does not have access to the same custom input names as the other
stereo inputs. The custom names list shown at the left provides
convenient access to the three custom input names available for
the phono input. The table below indicates the intended use of
these custom input names.
Custom Name Description
PHONO Indicates that the phono input connector is
associated with a moving-magnet phono
cartridge.
PH/MC Indicates that the phono input connector is
associated with a moving-coil phono
cartridge.
Unused Indicates that the phono input connector is
not in use, removing it from select knob or
select ± button scrolling.
PHONO
PH/MC
unused
