Mark Levinson 326S - Phono Module Specifications

Phono Module
Specifications
Unless otherwise specified, these specifications indicate nominal
values measured over a 20Hz to 20kHz bandwidth through
balanced (XLR) connections.
Gain
•
40 or 60dB @ 1kHz
Input Overload • >100mV @ 1kHz, 40dB gain
• >10mV @ 1kHz, 60dB gain
Input Impedance
Resistive
• 200Ω or 47kΩ (user-selectable)
Capacitive • 0 or 10nF (user-selectable)
Custom • Gold-plated, solder-less screw terminals are available for
user-installed load terminations.
THD + N • <0.02%
Frequency Response
•
±1dB (RIAA response)
Specifications are subject to change without notice.
