Mark Levinson 326S - Configuration Instructions

Configuration The phono modules must be optimized to work with the associated
Instructions phono cartridge. Each phono module includes:
•1 adjustable resistive load jumper
•1 adjustable capacitive load jumper
•1 adjustable input gain jumper
•2 screw terminals that accommodate custom loads
These features are identified in the illustration shown below.
3
Nº326S Preamplifier Phono Modules Installation Instructions & Release Notes
JUMPER SETTINGS
OPEN
CLOSED
C
L
=0nF
C
L
=10nF
R
L
=200
R
L
=47K
G=60db
G=40db
CUSTOM
TERMINATION
P10
JUMPER SETTINGS
OPEN
CLOSED
C
L
=0nF
C
L
=10nF
R
L
=200
R
L
=47K
G=60db
G=40db
CUSTOM
TERMINATION
P10
Each jumper can be OPEN or CLOSED, depending on the needs of
the associated phono cartridge. Select one setting for each jumper.
Refer to the illustrations shown below for recommendations.
When the phono modules are shipped, all
jumpers are CLOSED as shown in the illustration
above. In general, it is recommended to leave
all jumpers CLOSED for most low-output,
moving-coil phono cartridges.
The numbered items in the phono module illustration shown above correspond with the
numbered items that begin on the next page. The left and right-channel phono modules
are identical.
In general, it is recommended to OPEN all
jumpers for most high-output, moving-magnet
phono cartridges.
JUMPER SETTINGS
OPEN
CLOSED
C
L
=0nF
C
L
=10nF
R
L
=200
R
L
=47K
G=60db
G=40db
CUSTOM
TERMINATION
No.326S PHONO
P10
1 2 3
4
