1-5
Nº502 Media Console Getting Started
First-Time Operation
Perform the following steps to unpack and power up the new Nº502
Media Console.
Unpacking
1. Position the box so that the top side is facing up.
2. Use a utility knife to slice open the box and lift the box sides
apart to reveal the inner box.
3. Carefully slice open the inner box and lift the box sides apart.
4. Remove the white accessory box and put it aside.
5. Remove the foam insert from the top of the Nº502 Media
Console.
6. Carefully lift the Nº502 out of the box.
7. Remove the antistatic bag from the Nº502.
Initial Power-Up
1. Connect all system speakers and amplifiers to the Audio Output
connectors on the rear panel of the Nº502.
2. Using an HDMI cable, connect a DVD player output to the
HDMI-1 input on the rear panel of the Nº502.
3. Using a second HDMI cable, connect the HDMI-1 output on the
Nº502 to the display input.
4. Plug the power cord into the rear panel AC Input connector of
the Nº502 and then connect to your wall outlet. Make sure that
the power rating listed on the rear panel of the Nº502 is less
than the power available at the wall outlet.
5. Press the Power button on the front panel. When the Nº502
completes its power-up cycle, it automatically enters Standby
mode. When the LED above the Standby button begins to
slowly blink, the Nº502 is ready.
6. Press the Standby button to take the Nº502 out of Standby
mode.
Note If the front panel display is not bright enough or is too bright, multiple
presses of the front panel Display Intensity button scrolls through the
different brightness levels.
