2-16
Basic Operation Mark Levinson
Detailed Status
Panel
The Detailed Status Panel provides a comprehensive summary of the
current Activity. To access the Detailed Status Panel, press the button.
The elements listed vary based upon the current Activity and its setup.
Thus there may be more than one page of information; the top right
corner of the menu identifies the number of pages. To access additional
pages, press the button.
Note The Detailed Status Panel is always shown on the front panel display and
cannot be disabled.
The bottom half of each Detailed Status Panel page contains a meter
diagram that indicates the input levels of each active channel. The meters
show live data as long as the source of the current Activity is playing.
To close the Detailed Status Panel, press the button until it closes.
Note If analog input clipping occurs, then the affected speaker in the meter section
is indicated in red.
