9
Fig.1
Fig.2
194548
72751
194548
72751 72752
You can connect this control box to the unoccupied 4-pin
socketonanexisting72751or72752controlbox(seeFig.2).
1
1
2
2
3
4
• Afterthat,inserttheotherplugintothe4-pinsocketon
the194548BaseStation(seeFig.1thatfollows).
! The cable that comes with the signal control box may not
be altered.
The 71054 connecting cable must be used to extend this
connectingcable(notincludedwiththesignalcontrolbox).
